Lenovo Legion 5a (15", Gen 11) 15AGP11 vs Lenovo Legion 5i (15", Gen 11) 15IAX11

A

Product A: Lenovo

Legion 5a (15", Gen 11) 15AGP11

125 of 179 known

Change Lenovo Legion 5a (15", Gen 11) 15AGP11

Compare the Lenovo Legion 5i (15", Gen 11) 15IAX11 with

Search laptops

B

Product B: Lenovo

Legion 5i (15", Gen 11) 15IAX11

99 of 179 known

Change Lenovo Legion 5i (15", Gen 11) 15IAX11

Compare the Lenovo Legion 5a (15", Gen 11) 15AGP11 with

Search laptops

All 179 fields

Every value links to where we found it.

Only differences

ALenovo Legion 5a (15", Gen 11) 15AGP11

BLenovo Legion 5i (15", Gen 11) 15IAX11

General

4 of 9 differ

Series

Legion 51Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Product family Legion 5. Press release names it Legion 5a (15 inch, 11).

Legion 54Maker product pagelenovo.com/hk/en/p/laptops/legion-laptops/legion-series/legion-5i-gen-11-15-inch-intel-laptop/len101g0053Read 5 October 2026Maker marketed Legion 5i Gen 11 page, reached through the launch article maker link. Page text is partially rendered in text access, exact specs use fully rendered PSREF.

Model numbersiMaker identifiers for this exact model and its listed variants. Excludes sibling models and other generations.

83Q6000BMH3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026Product number manufacturer 83Q6000BMH: Ryzen AI 7 450, 32 GB (2 x 16 GB) DDR5, 1 TB SSD, RTX 5060 8 GB, 15.3 inch WQXGA OLED, Windows 11 Home.

83VK0029HH1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Live exact Model Configurations table rendered in browser. Hong Kong 83VK0029HH factory configuration only. Retailer upgrades to 32 GB RAM or 2 TB storage are excluded.

GTIN / EAN

Not available

1992764178001Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

AnnouncediThe maker's first announcement of this model. This is separate from first retail availability.

6 January 20262Press releasenews.lenovo.com/pressroom/press-releases/lenovo-levels-up-ces-with-legion-gaming-devicesRead 11 October 2026Press release dated 6 January 2026 announces the Legion 5a (15 inch, 11) with AMD Ryzen AI 400 Series, estimated from $1,499 with expected availability from April 2026.

Not available

Status

Available4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Review last updated 2 October 2026 says the Legion 5a series is widely available in most markets.

Not available

PredecessoriThe model this one directly replaced, in the same line, tier and size, as the maker or a trusted review names it.

Not available

Lenovo Legion 5i (15", Gen 10) 15IRX106Reviewnotebookcheck.com/Lenovo-Legion-5-launcht-mit-Nvidia-GeForce-RTX-5070-12GB-und-165Hz-OLED.1338245.0.htmlRead 23 October 2026Notebookcheck's news article calls the Legion 5 15IAX11 the successor of the older Legion 5 15IRX10.7Reviewnotebookcheck.net/Lenovo-Legion-5-15IAX11-review-Optimized-for-1440p-gaming.1380978.0.htmlRead 23 October 2026Notebookcheck's review compares the Legion 5 15IAX11 with last year's Legion 5 15IRX10.

SuccessoriThe model that directly replaced this one, in the same line, tier and size. A revision such as a Slim or OLED model does not count when a next generation exists.

Not available

Not available

Launch price (US)iThe maker's US launch MSRP for the stated configuration, excluding tax. Current store prices and later discounts do not qualify.

Not available

Not available

Launch price (EU)iThe maker's euro launch price for the stated configuration, including VAT as published. Current store prices and later discounts do not qualify.

Not available

Not available

MarketsiISO country or region codes where this exact model or variant is sold. A source page's language does not establish availability.

Not available

HK1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

ColoursiThe maker's own colour names

Eclipse Black, Glacier White1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Case Color options: Eclipse black and Glacier white.

Eclipse Black1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Segment

Gaming1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026AI PC Category: AI-Powered Gaming PC, with NVIDIA GeForce RTX graphics.

Gaming4Maker product pagelenovo.com/hk/en/p/laptops/legion-laptops/legion-series/legion-5i-gen-11-15-inch-intel-laptop/len101g0053Read 5 October 2026Producer title identifies an AI-accelerated gaming laptop.

Form factor

Clamshell1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Non-touch display and no pen support. PSREF lists no hinge angle or detachable screen.

Clamshell3Owner's manualgzhls.at/blob/ldb/3/5/9/1/15a8186490d45cc41e5a295ea9f59000445b.pdfRead 5 October 2026Front/base/side views on pages 1-10 show a standard hinged clamshell.

Chassis

2 of 6 differ

DimensionsiClosed laptop body size. Minimum and maximum thickness describe the front and rear or other points stated by the maker.

Width344Depth244.5Thickness (min)18.95Thickness (max)19.95mm(13.5 × 9.6 × 0.7 to 0.8 in)1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026344 x 244.5 x 18.95-19.95 mm. Footnote 2: the height does not include the 1.45 mm bump.

Width344Depth244.5Thickness (min)18.95Thickness (max)19.95mm(13.5 × 9.6 × 0.7 to 0.8 in)1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact Dimensions row: 344 x 244.5 x 18.95-19.95 mm. Platform page 5 footnote excludes the bump from height. The size is the published closed chassis profile, not an independently measured maximum including the bump.

Weight (published)iPublished laptop weight without the charger. A starting weight is identified in the source note and may vary with configuration.

1.87kg(4.1 lb)1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Starting at 1.87 kg. PSREF says the weight is approximate and varies by configuration.

1.93kg(4.3 lb)1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Starting at 1.93 kg. Approximate laboratory claim, not exact retail-unit measured weight.

Lid material

Aluminium1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Case Material: aluminium (top), PC-ABS (bottom).

Aluminium1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Bottom material

Plastic1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Plastic1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Max hinge angle

180°4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Extras: clamshell format with 180-degree screen angle.

Not available

MIL-STD-810 testing (claimed)iManufacturer claim of MIL-STD-810 testing. The revision and tested procedures belong in the source note. This is not proof of every standard test.

Yes1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Mil-Spec Test: MIL-STD-810H military test passed. The list of procedures is not published.

Yes1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026MIL-STD-810H military test passed. No claim to every procedure.

Display

2 of 25 differ

Screen sizeiDiagonal of the main built-in display. Rounded-corner displays may be measured as a full rectangle.

15.3in(38.9 cm)1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Display table, single option: 15.3 inch WQXGA 2560x1600 OLED, non-touch, glossy, 16:10, 500 nits SDR typical, 1000 nits HDR peak, 100% DCI-P3, 165 Hz.

15.3in(38.9 cm)1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Native resolution

2560 × 1600px1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

2560 × 1600px1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Pixel density

197.3ppi=CalculatedFrom Screen size and Native resolution

197.3ppi=CalculatedFrom Screen size and Native resolution

Panel typeiDell's WVA means wide viewing angle and names no panel technology, so it is stored as IPS only when Dell or a review names IPS.

OLED1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

OLED1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Backlight

None (self-emissive)1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

None (self-emissive)2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Page 4 OLED is self-emissive, without a separate backlight.

Dimming zonesiIndependently controlled backlight zones, not the number of LEDs or screen pixels.

Not available

Not available

Panel part numberiPanel part number identified in a matching review unit. Suppliers may vary within the same laptop configuration.

Not available

Not available

Screen surfaceiSurface of the stored display configuration. Anti-reflective coatings do not by themselves make a glossy display matte. A matte finish of the chassis is not the screen surface.

Glossy1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Glossy1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Touchscreen

No1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

No1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Stylus

None1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

None1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Refresh rate modesiHighest confirmed operating refresh rate of the built-in display at each resolution. Add a second row only for a documented dual-mode panel, not an ordinary supported timing.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Width (px)	Height (px)	Maximum operating refresh (Hz)	VRR
2560	1600	165	Yes

Source1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

BLenovo Legion 5i (15", Gen 11) 15IAX11

Width (px)	Height (px)	Maximum operating refresh (Hz)
2560	1600	165

Source1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Max refresh rate

165Hz=CalculatedFrom Refresh rate modes

165Hz=CalculatedFrom Refresh rate modes

Adaptive synciNamed variable refresh technologies for the built-in display. Manual switching between 60Hz and 120Hz is not VRR.

G-SYNC1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Display key features: DisplayHDR True Black 1000, NVIDIA G-SYNC, Advanced Optimus. Footnote: G-SYNC and Advanced Optimus need the latest NVIDIA driver.

G-SYNC1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Gray-to-gray response time (claimed)iManufacturer claim for a gray-to-gray pixel transition. Do not use generic response times, black-to-white values, or motion-picture response times.

Not available

Not available

Native panel colour depthiPhysical panel colour depth per channel. Do not infer native bit depth or FRC from the number of supported colours.

10bits4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Test line: 2.5K 2560 x 1600 px, 10-bit, 165 Hz.

Not available

Brightness (SDR, claimed)iManufacturer typical SDR luminance. Outdoor maxima and an unspecified peak are not typical SDR brightness.

500nits1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

500nits1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact 500 nits typical. Platform panel table explicitly identifies SDR typical.

Peak brightness (SDR outdoors, claimed)iManufacturer maximum SDR luminance explicitly claimed for outdoor use. Ambient light, automatic brightness and other stated conditions belong in the source note. Not typical SDR or HDR brightness.

Not available

Not available

Sustained brightness (HDR, claimed)iManufacturer explicitly sustained HDR luminance. Screen area, duration, temperature and other stated conditions belong in the source note. Not a brief peak or SDR luminance.

Not available

Not available

Peak brightness (HDR, claimed)iManufacturer peak luminance explicitly measured or claimed in HDR. Window size and duration belong in the source note.

1,000nits1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

1,000nits2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Page 4 HDR peak 1000 nits, SDR typical 500 nits. Window size and duration unstated. This corrects the press launch article 1100-nit claim.

sRGB coverage (claimed)iManufacturer stated sRGB gamut percentage. The source note identifies coverage, volume, or an unspecified maker gamut claim.

Not available

Not available

DCI-P3 coverage (claimed)iManufacturer stated DCI-P3 gamut percentage. The source note identifies coverage, volume, or an unspecified maker gamut claim.

100%1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Color Gamut column: 100% DCI-P3. Coverage or volume is not stated.

100%1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact Display row: 100% DCI-P3. Measurement method unstated.

Adobe RGB coverage (claimed)iManufacturer stated Adobe RGB gamut percentage. The source note identifies coverage, volume, or an unspecified maker gamut claim.

Not available

Not available

HDR certification

DisplayHDR True Black 10001Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

DisplayHDR True Black 10001Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Factory calibratediThe maker explicitly states factory colour calibration. Certification alone does not establish calibration.

Yes1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Color Calibration: X-Rite factory color calibration.

Yes1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact Color Calibration row: X-Rite Factory Color Calibration.

Second display

Not available

Not available

Processor

12 of 14 differ

Processor

AMD Ryzen AI 7 4501Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Intel Core Ultra 7 251HX1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Processor brand

AMD1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Intel1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Core configurationiProcessor core groups using the chip maker's names. MediaTek Big, Apple Super and AMD Zen architecture labels remain distinct from Intel P and E labels.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Core type	Count	Core	Base clock (GHz)	Max clock (GHz)
Zen 5	4	Zen 5	2	5.1
Zen 5c	4	Zen 5c	Not available	3.6

Source4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Ryzen AI 7 450 is a hybrid design with 4 Zen 5 and 4 Zen 5c cores. The review unit is the 32 GB, 1 TB, RTX 5060 configuration of 15AGP11 in Glacier White. Its exact model number is not given.5Maker product pageamd.com/en/products/processors/laptop/ryzen/ai-400-series/amd-ryzen-ai-7-450.htmlRead 11 October 2026Architecture 4x Zen 5 and 4x Zen 5c, 8 cores, 16 threads. Max boost up to 5.1 GHz, max Zen 5c clock up to 3.6 GHz, base clock 2 GHz.

BLenovo Legion 5i (15", Gen 11) 15IAX11

Core type	Count	Base clock (GHz)	Max clock (GHz)
Performance	6	2.9	5.1
Efficiency	12	2.5	4.5

Source2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Page 2 exact 251HX row: six P cores and twelve E cores, separately stated base and max clocks.

CPU cores

8=CalculatedFrom Core configuration

18=CalculatedFrom Core configuration

Cores labelled performanceiCounts only rows classified as performance. Other labels, including Big, Super and AMD Zen architecture rows, are not included.

0=CalculatedFrom Core configuration

6=CalculatedFrom Core configuration

Cores labelled efficiencyiCounts only efficiency and low-power-efficiency rows. AMD Zen 5c and Apple super cores are not included.

0=CalculatedFrom Core configuration

12=CalculatedFrom Core configuration

ThreadsiMaximum hardware threads of the processor, including simultaneous multithreading where supported.

161Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

181Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Max boost clock

5.1GHz=CalculatedFrom Core configuration

5.1GHz=CalculatedFrom Core configuration

L3 cacheiL3 cache only. Do not copy a combined L2 plus L3 cache total. Qualcomm's total cache, such as 30 MB on Snapdragon X, is not L3, even when a laptop maker labels it L3.

16MB1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Ryzen AI 7 450 row: 8MB L2 / 16MB L3.

30MB1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

ProcessiProcess size class of the processor compute die in nm, as on CPUs: TSMC N3B is 3, Intel 7 is 10, Intel 4 is 7 and Intel 18A is 1.8. Marketing process names and other chiplet processes belong in the source note.

4nm5Maker product pageamd.com/en/products/processors/laptop/ryzen/ai-400-series/amd-ryzen-ai-7-450.htmlRead 11 October 2026Processor technology for CPU cores: TSMC 4nm FinFET.

Not available

Sustained CPU power (configured)iThis laptop's sustained configured CPU power limit, such as PL1. A chip manufacturer's generic base power is not the laptop setting.

80W4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Legion Space profile table, Performance profile: CPU PL1/PL2 80/95 W. Custom is 90/95 W, Balance 65/80 W, Quiet 45/50 W.

Not available

Peak CPU power (configured)iThis laptop's configured short-duration CPU limit, such as PL2. Do not substitute generic processor maximum turbo power.

95W4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Performance profile PL2 of 95 W.

Not available

Combined CPU and GPU poweriMaker stated simultaneous CPU plus discrete-GPU budget for the exact configuration and power mode.

Not available

Not available

NPU performanceiNPU-only claimed operations per second. Excludes combined CPU, GPU and platform AI throughput. Precision belongs in the source note.

50TOPS1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Integrated AMD Ryzen AI, up to 50 TOPS. Overall up to 66 TOPS is not stored.

13TOPS1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Graphics

5 of 9 differ

Discrete GPUiA separate dedicated graphics processor is installed. Integrated or unified-memory graphics do not qualify.

Yes1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Yes1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

GPU

NVIDIA GeForce RTX 5060 Laptop GPU1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

NVIDIA GeForce RTX 5070 Laptop GPU1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

GPU brand

NVIDIA1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

NVIDIA1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

VRAMiDedicated video memory of the installed discrete GPU. Shared system memory is excluded.

8GB1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

12GB1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact Graphics row specifies RTX 5070 12 GB GDDR7, distinct from older 8 GB RTX 5070 and RTX 5070 Ti configurations.

Max GPU power (TGP)iMaximum configured discrete-GPU power including Dynamic Boost. Mode and any maker qualification belong in the source note.

115W1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Graphics table: RTX 5060 Laptop GPU, 8GB GDDR7, TGP 115W. The 5050 and 5070 options are not stored.

115W1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact Graphics row: 115 W TGP. Dynamic Boost portion is unstated and omitted.

Dynamic BoostiMaximum additional GPU power shifted from the CPU through NVIDIA Dynamic Boost. This is part of maximum TGP, not extra to it. A figure written as "up to 115W Dynamic Boost" is the total, so it goes in gpu_tgp_max_w.

Not available

Not available

GPU boost clockiHighest maker configured GPU boost clock, including factory overclock where explicitly stated. Mode belongs in the source note.

2,497MHz1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Graphics table: RTX 5060 boost clock 2497 MHz.

2,347MHz1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

GPU switchingiExplicit GPU display-routing or power-sharing features. Advanced Optimus includes hardware display multiplexing.

MUX switch, Advanced Optimus1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Display key features name Advanced Optimus, which includes a hardware MUX. The reviewer also confirms a MUX switch.4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Spec line: with MUX, Advanced Optimus, G-Sync.

Advanced Optimus2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Page 4 only 2560 x 1600 165 Hz OLED row explicitly lists Advanced Optimus.

Integrated GPU

AMD Radeon 860M1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Ryzen AI 7 450 row: AMD Radeon 860M.

Intel Graphics2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Page 2 251HX Processor Graphics: Intel Graphics.

Memory

4 of 9 differ

Installed RAMiTotal installed RAM in this product configuration, not the maximum purchase option.

32GB3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026RAM: 32 GB, memory layout 2 x 16 GB DDR5-5600, two SO-DIMM slots.

16GB1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

RAM type

DDR51Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Memory Type DDR5-5600. Two DDR5 SODIMM slots, dual-channel capable.

DDR51Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

RAM speediConfigured memory data rate in transfers per second. Do not treat the DRAM clock in MHz as the data rate.

5,600MT/s1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

5,600MT/s1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Memory channelsiActive memory channels of the installed configuration, not the number of RAM modules or slots. One installed module is one channel. This holds for DDR5 too, whose two 32-bit subchannels on one module do not count as two channels. Soldered LPDDR memory counts in 64-bit units, so a 128-bit bus is 2 channels, even when a maker calls it quad-channel.

23Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026

Not available

RAM upgradeiWhether the installed RAM is soldered, socketed in slots, or a mixture. Purchase-time configurations are not upgrades.

Slots1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Slots1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Memory slotsiPhysical replaceable RAM module sockets grouped by type and occupancy. Clocked SO-DIMM uses CSODIMM. Soldered memory is excluded.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Slot	Count	Occupied	Module size (GB)
SO-DIMM	2	Yes	16

Source3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026

BLenovo Legion 5i (15", Gen 11) 15IAX11

Slot	Count	Occupied	Module size (GB)
SO-DIMM	1	Yes	16
SO-DIMM	1	No	Not available

Source1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact single 16 GB SODIMM and two physical sockets. Second socket empty. Dual-channel capable does not establish active channels for this single-module configuration.

RAM slots

2=CalculatedFrom Memory slots

2=CalculatedFrom Memory slots

Free RAM slots

0=CalculatedFrom Memory slots

1=CalculatedFrom Memory slots

Maximum supported RAMiManufacturer supported maximum RAM, including purchase-time soldered options. Does not imply post-purchase upgradeability.

32GB1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Up to 32GB DDR5-5600 offering, based on current Lenovo memory offerings.

32GB1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Up to 32 GB DDR5-5600 offering based on current Lenovo tested offerings.

Storage

3 of 7 differ

Installed storageiTotal advertised installed storage in decimal GB. Convert 1TB to 1000GB, without changing an explicitly published 512GB value.

1TB3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026

1TB1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact installed 1 TB converted to decimal 1000 GB.

Storage type

NVMe SSD1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

NVMe SSD1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Installed drive PCIe generationiPCIe generation of the installed drive. This may be lower than the slot capability.

41Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

41Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Installed SSD row says PCIe 4.0 x4, distinct from PCIe 5.0 slot capability.

Storage slotsiPhysical storage connectors grouped by capability and occupancy. A slot accepting several drive lengths is one slot, not one per length.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Form factor	Interface	PCIe generation	PCIe lanes	Count
M.2 2280	PCIe NVMe	4	4	1
M.2 2280	PCIe NVMe	4	2	1

Source1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026One M.2 2280 PCIe 4.0 x4 slot and one M.2 2280 PCIe 4.0 x2 slot. Occupancy is left out because PSREF does not say which slot holds the factory drive.

BLenovo Legion 5i (15", Gen 11) 15IAX11

Form factor	Interface	PCIe generation	PCIe lanes	Count	Occupied
M.2 2242	PCIe NVMe	5	4	1	Yes
M.2 2280	PCIe NVMe	4	4	1	No

Source1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026One 2242 PCIe 5.0 x4 socket occupied by documented 2242 SSD, one 2280 PCIe 4.0 x4 socket empty. No extra connector is created by alternate drive lengths.

M.2 slots

2=CalculatedFrom Storage slots

2=CalculatedFrom Storage slots

Free storage slots

Not available

1=CalculatedFrom Storage slots

Maximum slot PCIe generation

4=CalculatedFrom Storage slots

5=CalculatedFrom Storage slots

Ports

2 of 7 differ

PortsiPhysical laptop connectors grouped by type, protocol capability and side. One connector with several protocols is counted once.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Type	Version	Count	Side	Maximum data rate (Gbps)	Thunderbolt or USB4	DP Alt Mode	Maximum charging input (W)	Maximum peripheral power (W)
USB-C	USB4 40Gbps	2	Left	40	USB4	Yes	140	15
Ethernet (RJ45)	Not available	1	Left	1	Not available	Not available	Not available	Not available
USB-A	USB 3.2 Gen 1	1	Right	5	Not available	Not available	Not available	4.5
3.5 mm audio	Not available	1	Right	Not available	Not available	Not available	Not available	Not available
USB-A	USB 3.2 Gen 1	1	Rear	5	Not available	Not available	Not available	4.5
USB-A	USB 3.2 Gen 1	1	Rear	5	Not available	Not available	Not available	10
HDMI	HDMI 2.1	1	Rear	Not available	Not available	Not available	Not available	Not available
DC in	Not available	1	Rear	Not available	Not available	Not available	Not available	Not available

Source1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Standard Ports: 2x USB-C USB4 40Gbps with USB PD 65-100W input and 15W output and DisplayPort 1.4, 3x USB-A 5Gbps (one Always On with 10W output, two with 4.5W output), HDMI 2.1, combo jack, RJ-45, slim tip power connector. The 140 W (20V/7A) figure is the Lenovo protocol and needs a unique Lenovo adapter. Overview diagram numbers the rear right USB-A as Always On, while the Ultrabookreview unit places it on the right edge. Sides come from the diagram.

BLenovo Legion 5i (15", Gen 11) 15IAX11

Type	Version	Count	Side	Maximum data rate (Gbps)	Thunderbolt or USB4	DP Alt Mode	Maximum charging input (W)	Maximum peripheral power (W)
USB-C	USB 10Gbps / DisplayPort 2.1	1	Left	10	Not available	Yes	140	15
USB-C	Thunderbolt 4 / USB4 / DisplayPort 2.1	1	Left	40	Thunderbolt 4	Yes	140	15
Ethernet (RJ45)	Not available	1	Left	1	Not available	Not available	Not available	Not available
USB-A	USB 5Gbps	1	Right	5	Not available	Not available	Not available	4.5
3.5 mm audio	Not available	1	Right	Not available	Not available	Not available	Not available	Not available
USB-A	USB 5Gbps	1	Rear	5	Not available	Not available	Not available	4.5
USB-A	Not available	1	Rear	Not available	Not available	Not available	Not available	10
HDMI	HDMI 2.1	1	Rear	Not available	Not available	Not available	Not available	Not available
DC in	Not available	1	Rear	Not available	Not available	Not available	Not available	Not available

Source1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact port table establishes quantities, outputs and protocols. Rear Always On USB-A data rate is omitted because exact PSREF says 5 Gbps while January user guide specifically claims 10 Gbps for 15IAX11 rear Always On.2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Pages 5-6 footnotes [2]/[3] confirm both USB-C ports accept Lenovo proprietary 140 W (20 V x 7 A) with unique Lenovo adapter. Standard USB PD remains 65-100 W. Supplied main adapter is 245 W Slim Tip.3Owner's manualgzhls.at/blob/ldb/3/5/9/1/15a8186490d45cc41e5a295ea9f59000445b.pdfRead 5 October 2026Printed pages 5/7/8 place USB-C pair and RJ45 left, USB-A and audio right, two USB-A/HDMI/Slim Tip rear. Page 13 confirms both USB-C maximum 140 W proprietary, standard PD 100 W, output 5 V x 3 A. Rear Always On 5/10 Gbps contradiction is intentionally left unknown.

USB-C ports

2=CalculatedFrom Ports

2=CalculatedFrom Ports

Thunderbolt

No=CalculatedFrom Ports

Yes=CalculatedFrom Ports

Highest HDMI version

HDMI 2.1=CalculatedFrom Ports

HDMI 2.1=CalculatedFrom Ports

Card reader

No=CalculatedFrom Ports

No=CalculatedFrom Ports

Ethernet speed

1Gbps=CalculatedFrom Ports

1Gbps=CalculatedFrom Ports

Maximum USB-C charging inputiHighest confirmed charging power accepted by a USB-C port. This is separate from adapter rating and power delivered to peripherals.

140W=CalculatedFrom Ports

140W=CalculatedFrom Ports

Wireless

1 of 5 differ

Wi-Fi

Wi-Fi 73Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026Wi-Fi standard: Wi-Fi 7 (802.11be), 2x2.

Wi-Fi 71Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Wi-Fi bandsiSupported radio frequency bands. Availability may be restricted by country or regulatory configuration.

Not available

Not available

Wi-Fi module

Realtek 8922AE4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Spec line: WiFi 7 (Realtek 8922AE) 2x2 with Bluetooth 5.4.

Not available

BluetoothiThe version as a number with one decimal, such as 5.4 or 6.0. A qualifier such as or above goes in the source note.

5.43Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 20264Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Bluetooth 5.4.

5.41Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact hardware design 5.4, effective version can depend on OS/driver.

Cellular

No1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026WWAN: No support.

No1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Keyboard and touchpad

0 of 8 differ

Keyboard layoutsiDocumented layouts of the retained regional SKUs. Do not infer a layout solely from the sales country.

English3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026Keyboard language: English, layout QWERTY.

English1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Key switches

Not available

Not available

Keyboard backlightiA maker-confirmed backlight with no published type uses backlit_unspecified. Do not infer white lighting, a single colour or RGB from backlit alone. A single-zone RGB backlight is RGB zones.

RGB zones1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Keyboard Backlight options: 1-Zone RGB or 24-Zone RGB. The exact model 83Q6000BMH is 1-zone RGB (Paradigit).3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026Backlight colour: 1-zone RGB.

RGB zones1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

NumpadiDedicated physical numeric keypad. A virtual touchpad number pad is not counted.

Yes1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Yes2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Page 5 keyboard explicitly lists numeric keypad.

Key traveliPhysical key travel distance, not actuation distance.

1.6mm1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

1.6mm2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026Page 5 keyboard: key travel 1.6 mm.

Pointing stickiDedicated stick pointing device such as TrackPoint. A touchpad does not qualify.

Not available

Not available

Touchpad size

Width120Height75mm(4.7 × 3 in)1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 202675 x 120 mm buttonless Mylar surface touchpad.

Width120Height75mm(4.7 × 3 in)1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Touchpad mechanismiA clickpad or glass touchpad that clicks when pressed down is mechanical. Haptic needs a source that says haptic or force feedback.

Not available

Not available

Camera and audio

0 of 7 differ

Webcam

5.0MP1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Camera options: 5.0MP + IR with E-shutter, or 5.0MP with E-shutter. IR is not confirmed for 83Q6000BMH.

5.0MP1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

IR face loginiAn infrared camera suitable for Windows Hello face authentication. An ordinary webcam or fingerprint sensor does not qualify.

Not available

Not available

Webcam privacy

Electronic kill switch1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026E-shutter listed under Other Security.

Electronic kill switch3Owner's manualgzhls.at/blob/ldb/3/5/9/1/15a8186490d45cc41e5a295ea9f59000445b.pdfRead 5 October 2026Printed page 7 camera switch enables or disables built-in camera. Electronic kill switch, not a physical lens cover.

Built-in speaker driversiIndividual built-in acoustic drivers, including separate tweeters and woofers. Do not count audio channels or infer driver count from speaker assemblies.

21Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

21Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Total speaker poweriCombined published power of the built-in speaker drivers. RMS or peak classification belongs in the source note.

4W1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Stereo speakers, 2W x2. RMS or peak is not stated.

4W1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Audio features

Audio by HARMAN, Nahimic Audio1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Audio by HARMAN, Nahimic Audio1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

MicrophonesiPhysical built-in microphones, not beamforming channels or microphone modes.

21Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

21Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Battery and power

2 of 5 differ

Battery energyiPublished nominal energy capacity of the installed internal battery in watt-hours. Separate from measured runtime and charger output.

80Wh1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

80Wh1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Claimed battery lifeiManufacturer maximum runtime for each explicitly named test. Display brightness, configuration and other conditions belong in the source note. Wireless streaming preserves an unnamed content type and does not imply video or audio. Video conferencing requires an explicit calling test, with application and participant setup in the source note. MobileMark versions use different workloads, so compare only rows of the same version.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Use case	Hours (h)
MobileMark 30	10.8
Video playback	13.8

Source1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026MobileMark 30 at 250 nits: 10.8 hr. Local 1080p video playback at 150 nits: 13.8 hr.

BLenovo Legion 5i (15", Gen 11) 15IAX11

Not available

Adapter rated outputiNominal rated output of the documented supplied or recommended adapter. A temporary dynamic maximum belongs in the source note. Not the laptop charging-input limit.

245W1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Power adapter options: 245W slim tip (3-pin) or no adapter.

245W1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Laptop charging connectoriConnector at the laptop end of the documented main charging cable, not the wall plug or adapter-end connector. HP's AC smart pin is a round DC plug, so it is barrel.

Proprietary1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Proprietary1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Charge 0 to 50 % (claimed)iManufacturer time to charge an empty battery to 50%. Adapter and powered-off conditions belong in the source note.

30min1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Rapid Charge Pro: charge up to 50% in 30 min. Adapter and start state are not stated.

Not available

Cooling

2 of 4 differ

FansiPhysical cooling fans inside the laptop. Excludes fans in external coolers and the power adapter.

24Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Cooling module has two fans, two heatsinks and three heat pipes.

Not available

Vapor chamberiA vapor-chamber heat spreader is installed. Ordinary heatpipes alone do not qualify.

Not available

Not available

Liquid metaliComponents where the maker confirms liquid-metal thermal material. Ordinary thermal paste is excluded.

Not available

Not available

Power modesiPublished laptop operating modes and configured power limits. Do not place observed runtime power measurements in this table.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Name	CPU power (W)	GPU power (W)
Quiet	45	60
Balance	65	75
Performance	80	105
Custom	90	115

Source4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Reviewer-reported profile settings. Cells are PL1 CPU power and maximum GPU TGP: Quiet 45/60 W, Balance 65/75 W, Performance 80/105 W, Custom 90/115 W.

BLenovo Legion 5i (15", Gen 11) 15IAX11

Not available

Security

0 of 4 differ

Fingerprint

None1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

None1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

TPM

2.01Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Firmware TPM 2.0 integrated in SoC.

2.01Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Remote management

Not available

Not available

Security lock slotiA dedicated built-in physical security-cable slot. Security locks that occupy a USB-C port do not qualify.

Not available

Not available

Software

0 of 3 differ

Operating system

Windows 11 Home3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026Operating system: Windows 11 Home.

Windows 11 Home1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

OS family

Windows3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026

Windows1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Security updates untiliPublished end date of OS/security updates promised for the exact device model. Preserve the source precision. Do not calculate it from years or substitute a generic OS-version lifecycle. Unknown when no device-specific promise is published.

Not available

Not available

Measured display

4 of 12 differ

Brightness (measured, centre)iReviewer center-point SDR luminance for the matching display configuration. Do not substitute a review average or unspecified measurement.

504.12nits4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026X-Rite i1 Display Pro, maximum brightness in the middle of the screen, on mains power: 504.12 cd/m2.

Not available

Brightness (measured, average)iReviewer mean luminance across a documented display grid, normally nine points.

Not available

Not available

Contrast ratio (measured)iMeasured by a reviewer, not claimed by the maker

Not available

Not available

HDR peak brightness (measured)iMeasured by a reviewer, not claimed by the maker

Not available

Not available

sRGB coverage (measured)iReviewer measured sRGB coverage, not gamut volume. Instrument and method belong in the source note.

100%4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026X-Rite i1 Display Pro coverage: 100% sRGB, also 94.3% Adobe RGB.

Not available

DCI-P3 coverage (measured)iReviewer measured DCI-P3 coverage, not gamut volume. Display P3 measurements are identified in the source note.

99.9%4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026X-Rite i1 Display Pro coverage: 99.9% DCI-P3.

Not available

Colour accuracy (measured Delta E)iReviewer colour error before calibration. Delta-E formula, colour space and picture mode belong in the source note.

Not available

Not available

PWM flicker foundiWhether a reviewer detected pulse-width-modulation flicker under the documented test conditions. False does not prove all frequency ranges were tested.

Yes4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026PWM: Yes, under 100% brightness. The review prints the frequency as 1.3 GHz, which is not plausible, so no frequency is stored.

Not available

PWM frequency (measured)iDetected PWM frequency at the brightness setting stated by the reviewer.

Not available

Not available

PWM at or below brightnessiHighest display brightness setting at or below which the documented PWM is detected.

Not available

Not available

Response black to white (measured)iReviewer combined rise and fall response for black-to-white-to-black, with test conditions in the source note.

Not available

Not available

Response grey to grey (measured)iReviewer combined rise and fall response between specified grey levels. State the levels in the source note.

Not available

Not available

Measured performance

7 of 8 differ

Cinebench 2024 single-coreiMeasured by a reviewer, not claimed by the maker

117points4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Performance profile, GPU in Hybrid mode, native 2560 x 1600, laptop on a stand. Cinebench 2024 single core 117 points.

Not available

Cinebench 2024 multi-coreiMeasured by a reviewer, not claimed by the maker

958points4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Same Performance profile suite. Cinebench 2024 CPU 958 points, 10 minute run.

Not available

Geekbench 6 single-coreiMeasured by a reviewer, not claimed by the maker. Geekbench 6 only. Geekbench 5 and 7 use other scales, so their scores are not stored.

2,900points4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Performance profile suite. Geekbench 6.6.0 single-core 2900.

Not available

Geekbench 6 multi-coreiMeasured by a reviewer, not claimed by the maker. Geekbench 6 only. Geekbench 5 and 7 use other scales, so their scores are not stored.

13,799points4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Performance profile suite. Geekbench 6.6.0 multi-core 13799.

Not available

3DMark Time Spy graphicsiMeasured by a reviewer, not claimed by the maker. Graphics score, not the overall score. A score the review does not label as graphics is left out.

12,650points4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Performance profile suite. 3DMark Time Spy graphics score 12650 (overall 12315).

Not available

3DMark Steel NomadiMeasured by a reviewer, not claimed by the maker

2,776points4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Performance profile suite. 3DMark Steel Nomad 2776.

Not available

SSD sequential read (measured)iMeasured by a reviewer, not claimed by the maker

Not available

Not available

Game frame ratesiMatching review-unit game results. Resolution, preset, upscaling, frame generation and ray tracing are stated only when documented.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Game	Width (px)	Height (px)	Preset	Upscaling	Ray tracing	Average FPS	1 % low FPS
Black Myth: Wukong	2560	1600	Cinematic	TSR 55, frame generation off	No	34	22
Cyberpunk 2077	2560	1600	Ultra	Not available	No	37	24
Horizon Forbidden West	2560	1600	Very High, TAA	Not available	Not available	48	34
Red Dead Redemption 2	2560	1600	Ultra Optimized, TAA	Not available	Not available	78	60
Shadow of the Tomb Raider	2560	1600	Highest, TAA	Not available	Not available	100	78
Cyberpunk 2077	2560	1600	Ultra, RT Overdrive, Ray Reconstruction, path tracing	DLSS 4 Balanced, Multi Frame Generation 2x	Yes	62	26
Cyberpunk 2077	2560	1600	Ultra, RT Overdrive, Ray Reconstruction, path tracing	DLSS 4 Balanced, Multi Frame Generation 4x	Yes	104	23

Source4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Performance profile, dGPU mode, about 105 W TGP, Game Ready driver 610.88, native 2560 x 1600, laptop on a stand. Black Myth, Cyberpunk and Horizon recorded with MSI Afterburner in campaign mode, RDR2 and Tomb Raider with the built-in benchmarks. Black Myth rows use TSR 55 with frame generation off. Cyberpunk Overdrive rows use DLSS 4 Balanced, Ray Reconstruction and path tracing.

BLenovo Legion 5i (15", Gen 11) 15IAX11

Not available

Measured noise and temperature

3 of 9 differ

Fan noise per modeiReviewer sound-pressure readings for the matching configuration and mode. Measurement distance and workload belong in the source note.

ALenovo Legion 5a (15", Gen 11) 15AGP11

Power mode	Load	Noise (dB(A))
Balance	Gaming	38
Performance	Gaming	45
Custom	Max load	52

Source4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Noise measured at head level while gaming on the stated profile. The Custom row is the full-speed fan figure of about 52 dBA stated in the profile table. Distance is not given in centimetres.

BLenovo Legion 5i (15", Gen 11) 15IAX11

Not available

Max fan noiseiMeasured by a reviewer, not claimed by the maker

52dB(A)=CalculatedFrom Fan noise per mode

Not available

Fan noise while gamingiMeasured by a reviewer, not claimed by the maker

45dB(A)=CalculatedFrom Fan noise per mode

Not available

Top surface under loadiMeasured by a reviewer, not claimed by the maker

Not available

Not available

Bottom surface under loadiMeasured by a reviewer, not claimed by the maker

Not available

Not available

Palm rest under loadiMeasured by a reviewer, not claimed by the maker

Not available

Not available

CPU temperature in stress testiMeasured by a reviewer, not claimed by the maker

Not available

Not available

CPU clock in stress testiMeasured by a reviewer, not claimed by the maker

Not available

Not available

GPU temperature while gamingiMeasured by a reviewer, not claimed by the maker

Not available

Not available

Measured battery and power

2 of 10 differ

Battery runtime per testiReviewer runtime for the exact test and configuration. Mixed browsing, video and graphics workloads are classified as mixed use.

Not available

Not available

Wi-Fi browsing runtimeiMeasured by a reviewer, not claimed by the maker

Not available

Not available

Video runtimeiMeasured by a reviewer, not claimed by the maker

Not available

Not available

Full charge time (measured)iMeasured by a reviewer, not claimed by the maker

Not available

Not available

Power draw idleiHighest reviewer idle AC power reading for the matching configuration and test conditions.

Not available

Not available

Power draw gamingiReviewer AC power draw during the named game and settings. Not GPU-only power.

Not available

Not available

Power draw maxiMaximum reviewer AC input power during the documented load or stress test. Not the adapter rating.

Not available

Not available

Sustained CPU power (measured)iObserved sustained CPU package power during the documented test. Not the configured PL1 limit.

85W4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Cinebench R15 loop on the Performance profile: 85 W sustained TDP.

Not available

GPU power while gaming (measured)iObserved GPU-only power while running the documented game and settings.

Not available

Not available

Weight (measured)iReviewer measured laptop mass without its power adapter unless the source note explicitly states otherwise.

1.91kg(4.2 lb)4Reviewultrabookreview.com/76635-lenovo-legion-5a-reviewRead 11 October 2026Reviewer spec line: weight 1.91 kg, charger and cables 0.72 kg, EU version. Whether it was weighed is not stated.

Not available

Certifications

4 of 6 differ

Intel EvoiManufacturer certification of the exact configuration as Intel Evo. Processor support alone does not establish certification.

Not available

Not available

Copilot+ PCiManufacturer identifies the configuration as Copilot+ PC. A Copilot keyboard key alone is insufficient.

Yes1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026AI PC Category lists Copilot+ PC.

Not available

Colour certifications

Pantone Validated, Pantone SkinTone Validated1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Other Certifications: Pantone SkinTone Validated and Pantone Validated.

Pantone Validated, Pantone SkinTone Validated1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

ENERGY STAR

Yes1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026ENERGY STAR 9.0, only on models with a preloaded OS.3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026Certification: ENERGY STAR, EPEAT Gold, RoHS.

Not available

EPEAT

Gold1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026EPEAT Gold Registered, only on models with a preloaded OS.3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026

Not available

Other certifications

TÜV Rheinland Flicker Free, TÜV Rheinland High Gaming Performance, TÜV Rheinland Low Blue Light (Hardware Solution), ErP Lot 6/26, RoHS compliant1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Certifications list.

ErP Lot 6/26, RoHS compliant, TÜV Rheinland Flicker Free, TÜV Rheinland High Gaming Performance, TÜV Rheinland Low Blue Light (Hardware Solution)1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

In the box

1 of 2 differ

In the boxiAccessories confirmed for this exact SKU. Do not combine mutually exclusive regional bundles into one box.

Not available

245 W Slim Tip power adapter (3-pin)1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Only exact selected main power adapter retained. Bundled Accessories row says None. Retailer mouse/bag gifts are excluded.

Power adapter includediWhether a power adapter is included with this exact regional SKU. A supported or recommended adapter does not prove inclusion.

Yes3Retailer pageparadigit.ie/lenovo-legion-5-15agp11-83q6000bmh/21872345/productRead 11 October 2026Includes a power adapter (245 W).

Yes1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact configured SKU Power Adapter row selects 245 W Slim Tip 3-pin, distinct from family No power adapter option.

Warranty

0 of 2 differ

Manufacturer warranty (source market)iThe maker's warranty period for the exact SKU or configuration and market named in the source note. It applies only to that stated market, not every regional variant. Statutory consumer rights are excluded. The base term is stored. An extension that needs registration goes in the source note.

1year1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026Base Warranty: 1-year courier or carry-in service. 2-year and 3-year options exist and are not stored.

1year1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact Hong Kong base warranty: one year courier or carry-in. Included 3Y Legion Ultimate Support -IPMAIN (ESS) is separate, not added to base period.

Warranty serviceiDocumented manufacturer warranty service for the named market. Included paid service upgrades belong in the source note.

Collect and return, Carry-in1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

Collect and return, Carry-in1Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026Exact base service is courier or carry-in, with named bundled Legion Ultimate Support noted separately.

Links

Not compared

Product page

psref.lenovo.com/Product/Legion/Legion_5_15AGP111Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026PSREF product page that hosts this spec sheet. The page itself is a script-rendered shell, so the PDF was read instead.

psref.lenovo.com/Detail/Legion_5_15IAX111Maker product pagepsref.lenovo.com/Detail/Legion_5_15IAX11Read 5 October 2026

Spec sheet

psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdf1Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AGP11/Legion_5_15AGP11_Spec.pdfRead 11 October 2026

psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdf2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15IAX11/Legion_5_15IAX11_Spec.pdfRead 5 October 2026

Manual

Not available

support.lenovo.com/docs/legion_5_153Owner's manualgzhls.at/blob/ldb/3/5/9/1/15a8186490d45cc41e5a295ea9f59000445b.pdfRead 5 October 2026Original Lenovo January 2026 user guide read in full. Scope table names Legion 5 15IAX11 and machine type 83VK. Other AGP/AHP/IPH variants are not used for configuration facts.

EPREL registration numberiId in the EU energy label database. Each size or model of a series has its own id, so it is per variant.

Not available

Not available

Both are also in the API. Back to all laptops.
