Sonos Ray vs Yamaha SR-B30A

A

Product A: Sonos

Ray

55 of 98 known

Change Sonos Ray

Compare the Yamaha SR-B30A with

Search soundbars

B

Product B: Yamaha

SR-B30A

45 of 98 known

Change Yamaha SR-B30A

Compare the Sonos Ray with

Search soundbars

All 98 fields

Every value links to where we found it.

Only differences

ASonos Ray

BYamaha SR-B30A

Audio system

10 of 17 differ

System channel configurationiMaker-stated channel layout of the exact package, such as 5.1.2. This can include virtual channels. It is not a count of physical drivers. Optional speakers do not count.

3.015Maker product pagesonos.com/en-us/shop/beam-ultraRead 8 October 2026Which Sonos soundbar is right for you comparison lists Ray as 3.0 with Dolby Digital. This is a maker-advertised layout. Ray has no discrete center driver, and its four drivers share dialogue duties.

Not available

Physical drivers in the packageiCount of physical active speaker drivers across the supplied bar, subwoofer and rear speakers. Passive radiators, microphones and virtual channels do not count. A coaxial driver, such as KEF Uni-Q, counts once, as makers count it.

42Owner's manualsonos.com/en-us/guides/rayRead 8 October 2026Standalone reference package has no supplied external subwoofer or rear enclosures. Same active drivers as the bar.

83Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Physical drivers in the bariCount of physical active speaker drivers in the soundbar alone. Passive radiators and virtual channels do not count. A coaxial driver, such as KEF Uni-Q, counts once, as makers count it.

42Owner's manualsonos.com/en-us/guides/rayRead 8 October 2026Active drivers only. Passive radiators and bass-reflex ports are excluded.

83Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Up-firing drivers in the packageiPhysical active drivers explicitly firing upwards across the supplied package. Virtual height channels and passive radiators do not count. A driver that fires upwards only when the bar is wall mounted is not counted.

013Reviewwhathifi.com/reviews/sonos-rayRead 8 October 2026Features section explicitly describes all four drivers as forward-facing.

Not available

Driver layoutiPublished physical driver layout for the supplied components. A row names one driver type in one component. Do not translate channel count into driver count.

ASonos Ray

Component	Driver type	Count	Orientation
Soundbar	Tweeter	2	Forward-facing
Soundbar	Midwoofer	2	Forward-facing

Source2Owner's manualsonos.com/en-us/guides/rayRead 8 October 2026Manual and product-page Audio specifications. No driver diameters published.

BYamaha SR-B30A

Component	Driver type	Count	Diameter (mm)
Soundbar	Full-range cone (front left and right)	4	46
Soundbar	Dome tweeter	2	25
Soundbar	Built-in subwoofer cone	2	75

Source3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Specifications: front L/R 4.6 cm cone x 4, 2.5 cm dome tweeter x 2 and subwoofer 7.5 cm cone x 2, bass reflex, all in the one bar body. Converted from the published cm.

Separate subwoofer includediA separate powered subwoofer is supplied with the reference package. A built-in woofer does not count.

No1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Complete standalone-bar box contents. Separate Sonos subwoofers are optional.

No3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026The bar has built-in subwoofers. An external subwoofer with its own amplifier can be connected to the SUBWOOFER OUT jack. No separate subwoofer is supplied.

Included subwoofer connectioniAudio link used by the supplied separate subwoofer. Wireless subwoofers can still require an AC power cable.

Not available

Not available

Included subwoofer driver diameteriPublished diameter of an active driver in the supplied separate subwoofer. Do not use enclosure size or passive radiator size.

Not available

Not available

Rear speakers includediCount of separate rear speaker enclosures supplied with the reference package. Detachable bar ends count when usable as rears. Optional rear speakers do not count.

01Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Complete standalone-bar box contents. Rear speakers are optional.

03Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Included rear speaker connectioniAudio link to the supplied rear speaker enclosures. Their power connection is separate.

Not available

Not available

Detachable rear speakersiThe bar has supplied detachable end sections usable as separate rear speakers.

Not available

Not available

Compatible optional subwoofersiMaker-named compatible additional subwoofer models. These do not contribute to the reference package layout, dimensions or measurements.

Sub (Gen 1), Sub (Gen 2), Sub (Gen 3), Sub 4, Sub Mini10Maker product pagesupport.sonos.com/en-us/article/set-up-your-sonos-subRead 8 October 2026Sub 1/2/3 support all home theater speakers. Sub 4 supports all except Playbar/Playbase. Sub Mini has separate support list. Arc Ultra dual-Sub setup requires two Sub 4/Gen 3 units, not Gen 1/2.11Maker product pagesupport.sonos.com/en-us/article/sonos-products-that-support-sub-miniRead 8 October 2026Home Theater list explicitly includes Arc Ultra, Beam (Gen 2) and Ray for Sub Mini.

Not available

Compatible optional rear speakersiMaker-named compatible additional rear speaker models. These do not contribute to the reference package layout, dimensions or measurements.

One, One SL, Era 10012Maker product pagesonos.com/en-us/blog/guide-to-rayRead 8 October 2026Guide names optional One and One SL surrounds. Current product page offers a Ray plus two Era 100 set.

Not available

Total RMS audio output poweriMaker-stated RMS or rated continuous amplifier output for the exact supplied package. Peak or unspecified maximum claims do not qualify. Distortion, load and rating conditions belong in the source note. Power consumption is separate.

Not available

Not available

Total peak audio output poweriMaker-stated peak or maximum amplifier output for the exact supplied package. This is separate from RMS or continuous output and from electrical consumption. Rating conditions belong in the source note.

Not available

120W3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Maker lists maximum rated output power 30 W x 2 channels for the front L/R and 60 W for the subwoofers. The Yamaha USA specs page totals 120 W. Rating conditions are not stated.

Published frequency response lower limitiMaker-published lower limit for the exact supplied package. Tolerance and test conditions belong in the source note. Reviewer extension measurements are separate.

Not available

54Hz3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Built-in subwoofer 54 Hz to 240 Hz. The maker publishes ranges per driver group and no single system figure.

Published frequency response upper limitiMaker-published upper limit for the exact supplied package. Tolerance and test conditions belong in the source note.

Not available

22kHz3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Front L/R 240 Hz to 22 kHz. Tweeter 9 kHz to 22 kHz. Per driver group, no tolerance stated.

Audio formats

8 of 9 differ

Dolby AtmosiExplicit support for Dolby Atmos playback. Transport codec and connection restrictions belong in source notes.

No13Reviewwhathifi.com/reviews/sonos-rayRead 8 October 2026Price and Features sections state no Dolby Atmos decoding.

Yes2Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/specs.htmlRead 13 October 2026Specs page lists Dolby Atmos as the sound technology. DTS Digital Surround is No.

DTS:XiExplicit support for DTS:X playback. Virtual surround processing alone does not establish DTS:X decoding.

Not available

Not available

Supported audio formatsiAudio formats explicitly decoded by the device. Codec and connection restrictions belong in source notes. Bluetooth codecs and music-file formats are separate.

Stereo PCM, Dolby Digital, DTS Digital Surround4Maker product pagesupport.sonos.com/en-us/article/supported-home-theater-audio-formatsRead 8 October 2026Current Sonos app. Dolby TrueHD, multichannel PCM and MAT require eARC. DTS Digital Surround is not an indication of a licensed decoder.

Linear PCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Audio formats by connectioniExplicitly supported audio decoding combinations. Max input channels counts decoded input audio channels, including LFE. A 5.1 layout has 6 channels and 7.1 has 8. Output speaker layouts and Atmos objects do not count. Atmos over Dolby Digital Plus and over Dolby TrueHD are separate rows. Format support on one input does not prove support on another.

ASonos Ray

Connection	Format
Optical	Stereo PCM
Optical	Dolby Digital
Optical	DTS Digital Surround

Source4Maker product pagesupport.sonos.com/en-us/article/supported-home-theater-audio-formatsRead 8 October 2026Ray has an optical audio input. ARC/eARC combinations are stated for Arc Ultra and Beam (Gen 2). Optical adapter paths for the HDMI bars are not treated as native optical ports.

BYamaha SR-B30A

Connection	Format	Max input channels
HDMI eARC	Linear PCM	8
HDMI eARC	Dolby Digital	Not available
HDMI eARC	Dolby Digital Plus	Not available
HDMI eARC	Dolby TrueHD	Not available
HDMI eARC	Dolby Atmos	Not available
HDMI ARC	Linear PCM	2
HDMI ARC	Dolby Digital	Not available
HDMI ARC	Dolby Digital Plus	Not available
HDMI ARC	Dolby Atmos	Not available
Optical	Linear PCM	2
Optical	Dolby Digital	Not available

Source3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Supported digital audio signal formats tables. eARC: 2-channel PCM, multichannel PCM up to 7.1 channels (8), and Dolby Digital, TrueHD, Digital Plus and Atmos bitstreams. ARC: 2-channel PCM, Dolby Digital, Digital Plus and Atmos. Optical: 2-channel PCM and Dolby Digital. The tables do not state Atmos transport per format.

Music file formatsiPublished local or network music-file playback formats. Playback route and app restrictions belong in source notes.

MP3, MP4, M4A, WMA, AAC, HE-AAC, OGG, FLAC, ALAC, AIFF, WAV5Maker product pagesupport.sonos.com/en-us/article/supported-audio-formats-for-sonos-music-libraryRead 8 October 2026Local network music-library playback through the current Sonos app. Mono or stereo files. This is separate from HDMI/optical theater formats.

Not available

Max wired audio sample rateiHighest explicitly published supported sample rate for decoded wired audio input. Name the exact HDMI, ARC, eARC or optical connection and codec in source notes. This is the published route limit, not proof of a device-wide maximum across all inputs. Local or network music-file limits and Bluetooth do not qualify. A chipset limit is not device evidence.

Not available

96kHz3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026PCM over HDMI eARC, HDMI ARC and optical: up to 96 kHz. Multichannel PCM over eARC also tops out at 96 kHz.

Max music file sample rateiHighest explicitly published supported local or network music-file sample rate. Name the playback route and file format in source notes. This is the published route and format limit, not proof of a device-wide maximum across all music formats. Wired HDMI or optical input and Bluetooth are separate.

48kHz5Maker product pagesupport.sonos.com/en-us/article/supported-audio-formats-for-sonos-music-libraryRead 8 October 2026Published local music-library maximum. Not a claim that HDMI/optical input rates match this route.

Not available

Max wired audio bit depthiHighest explicitly published supported bit depth for decoded wired audio input. Name the exact HDMI, ARC, eARC or optical connection and codec in source notes. This is the published route limit, not proof of a device-wide maximum across all inputs. Local or network music-file limits and Bluetooth do not qualify.

Not available

24bits3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Same tables: PCM at 16, 20 and 24-bit on eARC, ARC and optical.

Max music file bit depthiHighest explicitly published supported local or network music-file bit depth. Name the playback route and file format in source notes. This is the published route and format limit, not proof of a device-wide maximum across all music formats. Wired HDMI or optical input and Bluetooth are separate.

24bits5Maker product pagesupport.sonos.com/en-us/article/supported-audio-formats-for-sonos-music-libraryRead 8 October 2026FLAC and ALAC local network music-library playback on the current app. AIFF and WAV are limited to 16 bits.

Not available

Connectivity

11 of 17 differ

Ports on the bariPhysical connectors on the soundbar alone. Record input, output, ARC or eARC, service, subwoofer and power roles explicitly. Count identical connectors per row. Component connectors are described in source notes.

ASonos Ray

Connector	Count	Version	Role
Optical	1	Not available	Digital optical audio input
Ethernet	1	10/100 Mbps	Network input
AC power	1	Not available	Mains power input

Source2Owner's manualsonos.com/en-us/guides/rayRead 8 October 2026User guide Connector panel. One optical audio input, one Ethernet port and one AC power input.

BYamaha SR-B30A

Connector	Count	Role
HDMI	1	TV connection with eARC or ARC (HDMI OUT)
Optical	1	Digital audio input
Subwoofer	1	Mono RCA output for an optional external subwoofer
USB-A	1	Firmware update only
AC power	1	Soundbar power input

Source3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Specifications: one OPTICAL input, one HDMI OUT/TV (eARC/ARC), one SUBWOOFER OUT (RCA mono) and one USB marked UPDATE ONLY.

HDMI ARC

No13Reviewwhathifi.com/reviews/sonos-rayRead 8 October 2026

Yes3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

HDMI eARC

No13Reviewwhathifi.com/reviews/sonos-rayRead 8 October 2026

Yes3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

HDMI-CEC

Not available

Yes2Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/specs.htmlRead 13 October 2026

HDMI video passthroughiCan pass video from a dedicated HDMI source input to a television output. ARC or eARC alone does not qualify.

No14Reviewtechradar.com/reviews/sonos-rayRead 8 October 2026Connectivity section says no HDMI connection, only optical TV audio.

No3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026The only HDMI connector is the TV output.

Video passthrough modesiPublished supported passthrough combinations, not inferred maxima at untested resolutions. State chroma, bit depth, HDR and firmware restrictions in source notes.

Not available

Not available

HDR passthrough formats

Not available

Not available

VRR passthrough

Not available

Not available

ALLM passthrough

Not available

Not available

HDCP versioniHighest HDCP version the maker states for an HDMI port of the soundbar, such as 2.3. When the source inputs and the TV output differ, the source input version is stored. A bar with no HDMI input stores the version of its TV output, also when that output carries video from a built-in streaming player.

Not available

Not available

Bluetooth audio inputiCan receive audio from a Bluetooth source. A Bluetooth remote alone does not qualify.

No13Reviewwhathifi.com/reviews/sonos-rayRead 8 October 2026

Yes3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Bluetooth versioniPublished version of the soundbar audio connection. An optional remote or detachable rear can use a different version.

Not available

5.13Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Bluetooth Ver 5.1, Class 1, A2DP, sink function only.

Bluetooth audio codecsiExplicitly supported codecs for received Bluetooth audio. A Bluetooth version alone does not establish a codec.

Not available

SBC, AAC3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Sink function: SBC and MPEG4-AAC.

Wi-Fi

Yes1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

No2Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/specs.htmlRead 13 October 2026Specs page lists Wi-Fi No, AirPlay No and MusicCast Surround No for the SR-B30A.

Wi-Fi standardiPublished Wi-Fi standards for the soundbar, written as 802.11 names without IEEE, such as "802.11a/b/g/n/ac/ax". A Wi-Fi generation is written as its standard, so Wi-Fi 5 is "802.11ac" and Wi-Fi 6 is "802.11ax". Do not infer the standard from frequency bands.

802.11b/g/n3Maker product pagesupport.sonos.com/en-us/article/supported-wifi-modes-and-security-standards-for-sonos-productsRead 8 October 2026Dedicated device-mode support list. General user-guide router compatibility text is not device-protocol evidence.

Not available

Wi-Fi bandsiPublished radio bands, such as 2.4 GHz and 5 GHz.

2.4 GHz3Maker product pagesupport.sonos.com/en-us/article/supported-wifi-modes-and-security-standards-for-sonos-productsRead 8 October 2026Router uplink bands from the dedicated support list. Surround speaker radio links are separate.

Not available

Built-in Ethernet speediRated speed of the built-in port. An optional adapter does not count.

100Mbps1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Not available

Streaming and control

6 of 8 differ

Streaming protocolsiNamed network playback protocols, such as AirPlay 2, Google Cast, Spotify Connect and Tidal Connect. Bluetooth is separate.

AirPlay 2, Spotify Connect, Tidal Connect1Maker product pagesonos.com/en-us/shop/rayRead 8 October 202613Reviewwhathifi.com/reviews/sonos-rayRead 8 October 2026

Not available

Voice assistantsiNamed assistants supported by the soundbar. Built-in and external-device routes and market restrictions belong in source notes.

Not available

Not available

Built-in microphoneiPhysical microphone in the bar for voice or calibration. An external setup phone or remote microphone does not count.

No13Reviewwhathifi.com/reviews/sonos-rayRead 8 October 2026Features section explicitly says in-built microphones are absent.

Not available

Microphone mute controliA physical control on the soundbar explicitly disables its built-in voice microphone. State whether this is an electrical switch or software-controlled button when known.

Not available

Not available

Companion apps

Sonos1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Sound Bar Remote3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Free Sound Bar Remote app. Tone control works only in the app.

Companion app platforms

iOS, iPadOS, Android, Fire OS, macOS, Windows, Web6Maker product pagesupport.sonos.com/en-us/article/sonos-app-requirementsRead 8 October 2026Current app: iOS/iPadOS 18+, Android 10+, Fire OS 7+. Desktop macOS 10.12+/Windows 8+. Desktop and web have limited system setup features. Mobile iOS or Android required for initial setup.

iOS, Android3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Multiroom audioiCan play synchronised audio with other rooms through a supported network platform. Optional surround expansion alone does not qualify.

Yes12Maker product pagesonos.com/en-us/blog/guide-to-rayRead 8 October 2026

Not available

Remote includediA separate remote control supplied with the reference package. Phone apps and TV remotes do not count.

No1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Complete box contents contain no separate remote. Control uses a TV remote, touch controls or the app.

Yes3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Sound processing

5 of 7 differ

Sound modes

Speech Enhancement, Night Sound1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Stereo, Standard, Movie, Game3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026One stereo mode and three surround modes: Standard, Movie and Game.

Automatic room calibrationiExplicit acoustic measurement or analysis used to adapt playback to the room. Manual EQ alone does not qualify. Setup phone requirements belong in source notes.

Yes1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Trueplay measures room acoustics. Requires a supported iOS device.

Not available

Room calibration system

Trueplay1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Not available

Dialogue enhancementiA dialogue or voice mode counts, also when the maker lists it as an EQ preset.

Yes1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Yes3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Night mode

Yes1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Not available

Equalizer controlsiPublished user-adjustable EQ controls. Bass and treble controls are distinct from multi-band EQ.

Bass, Treble, Loudness1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Treble, Bass, Bass Extension3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Tone control in the app adjusts treble and bass. Bass Extension is an on or off function. The press release for both models also lists an independent subwoofer volume control, which the B30A guide does not describe.

TV speaker integrationiNamed features allowing compatible television speakers to play with the bar. TV models and connection requirements belong in source notes.

Not available

Not available

Power

4 of 6 differ

Published operating poweriMaker-published operating electrical consumption of the soundbar alone. Included subwoofer and rear-speaker consumption do not count. Keep workload and method in source notes. Audio amplifier output is separate.

Not available

23W3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Power consumption 23 W for the whole bar with built-in subwoofers.

Published standby poweriMaker-published non-networked standby consumption of the bar alone. Networked standby and other components are separate.

Not available

0.3W3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Standby 0.3 W with HDMI Control and Bluetooth Standby off.

Published networked standby poweriMaker-published networked standby consumption of the bar alone. Enabled radio and network conditions belong in source notes.

Not available

0.6W3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Standby 0.6 W with HDMI Control and Bluetooth Standby on. The bar has no Wi-Fi.

Power supplyiPublished AC input range or external DC adapter arrangement. Electrical input ratings are not operating consumption.

100-240 V AC, 50/60 Hz, internal power supply1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

AC 100 to 120 V, 50/60 Hz (US, Canada, Taiwan and Mexico models).3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Detachable rear battery lifeiMaker-stated runtime of the supplied detachable rear speakers. Volume, mode and recharge conditions belong in source notes.

Not available

Not available

Detachable rear charge timeiMaker-stated full recharge time of supplied detachable rear speakers. Charging route belongs in source notes.

Not available

Not available

Measured

None of 8 known

Low-frequency extension (measured)iReviewer-measured lower extension for the exact tested package. Test threshold, mode, room correction and configuration belong in source notes.

Not available

Not available

High-frequency extension (measured)iReviewer-measured upper extension for the exact tested package. Test threshold and configuration belong in source notes.

Not available

Not available

Max sound pressure (measured)iReviewer-measured maximum sound pressure. Signal, distance, sound mode and supplied or optional speaker configuration belong in source notes.

Not available

Not available

Frequency response deviation (measured)iReviewer-measured standard error against the stated target. Target, averaging range, preset and test method belong in source notes.

Not available

Not available

Measured latencyiReviewer-measured audio latency. Keep source/TV, firmware, codec, synchronisation correction and exact tested speaker configuration in source notes. Negative offsets are valid when the method reports them.

Not available

Not available

Operating power (measured)iReviewer-measured operating consumption of the soundbar alone. Optional or supplied external speakers do not count. Workload and enabled radio conditions belong in source notes.

Not available

Not available

Standby power (measured)iReviewer-measured bar-only standby consumption. Network state and test conditions belong in source notes.

Not available

Not available

Soundbar weight (measured)iReviewer-measured bar-only weight. Excludes subwoofer, rears, mounting hardware and cables.

Not available

Not available

Dimensions and weight

2 of 6 differ

Soundbar dimensionsiBar alone in its normal tabletop orientation, without detachable rears, wall brackets or external cables. A source that includes detachable ends must use component_dimensions instead. A size labelled L x W x H, as on Amazon, is width x depth x height.

Width559Height71Depth95mm(22 × 2.8 × 3.7 in)2Owner's manualsonos.com/en-us/guides/rayRead 8 October 2026User guide Specifications and launch fact sheet give 559 x 71 x 95 mm. Current shop page instead gives 557 x 70 x 93 mm. Manual and datasheet take precedence.

Width910Height68Depth133mm(35.8 × 2.7 × 5.2 in)3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Sound bar installed in front of a TV: 910 x 68 x 133 mm. With wall spacers: 910 x 66 x 139 mm.

Soundbar weightiBar alone, without detachable rears, subwoofer, wall brackets or external cables. Source-published masses including detachable ends belong in component_dimensions.

1,950g(4.3 lb)2Owner's manualsonos.com/en-us/guides/rayRead 8 October 2026Manual and launch fact sheet give 1.95 kg. Current shop page gives 1.9 kg. Manual and datasheet take precedence.

3,900g(8.6 lb)3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Weight 3.9 kg (8.6 lb).

Component dimensions and weightiPublished dimensions and mass for named supplied components, including a bar with detachable rears attached when stated. Each row describes one enclosure, not the pair, unless the component label explicitly states a set. Width, height and depth use normal installed orientation.

Not available

Not available

Package dimensions

Not available

Not available

Package weightiShipping package including supplied components and packaging.

Not available

Not available

Wall mountable

Yes1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Yes1Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/index.htmlRead 13 October 2026Page feature list: wall-mountable with built-in keyholes. The guide lists a mounting template and spacers.

In the box

4 of 4 differ

In the box

Sonos Ray, Power cable, Optical audio cable, Setup guide, Legal and warranty information1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Product page Box Contents lists the standalone bar package.

Soundbar, Remote control, Remote battery (CR2025), Power cord, HDMI cable (1.5 m), Mounting template, Two spacers, Quick guide, Safety guide3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026Confirming the included items: sound bar, remote with CR2025 battery, power cord, 1.5 m HDMI cable, mounting template, two spacers, quick guide and safety guide.

Wall mount hardware includediSupplied bar mounting brackets or mount. Screws alone do not establish that a complete mount is included.

No1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Sonos wall mount is sold separately.

Not available

HDMI cable included

No1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Yes3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

Optical cable included

Yes1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Optical audio cable supplied.

No3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026No optical cable is in the included items list.

General

5 of 7 differ

Series

Not available

Not available

Model numbersiMaker identifiers for this exact model and its listed variants. Excludes sibling models and other generations.

RAYG1US1BLK, RAYG1US11Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Maker ProductGroup JSON-LD lists the black and white US standalone soundbar SKUs.

SR-B30A1Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/index.htmlRead 13 October 2026Yamaha USA page for the SR-B30A all-in-one sound bar with built-in subwoofers.

GTIN / EAN

840136802846, 8401368028391Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026Maker JSON-LD names the property gtin13 but publishes these literal 12-digit US UPC values, matched to the black and white SKUs.

Not available

AnnouncediThe maker's first announcement of this model. This is separate from first retail availability.

11 May 20229Press releaseinvestors.sonos.com/news-and-events/investor-news/latest-news/2022/Upgrade-Your-Sound-With-Sonos-Ray-and-New-Colors-for-Sonos-Roam/default.aspxRead 8 October 2026

20 July 20234Press releaseusa.yamaha.com/news_events/2023/yamaha-expands-its-lineup-of-dolby-atmos-sound-bars.htmlRead 13 October 2026

Status

Available1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

Available1Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/index.htmlRead 13 October 2026The Yamaha USA product page, specs and downloads pages are live in 2026. The page offers no price.

PredecessoriThe model this one directly replaced, in the same line, tier and size, as the maker or a trusted review names it.

Not available

Not available

SuccessoriThe model that directly replaced this one, in the same line, tier and size. A revision such as a Slim or OLED model does not count when a next generation exists.

Not available

Not available

Launch price (US)iThe maker's US launch MSRP for the stated configuration, excluding tax. Current store prices and later discounts do not qualify.

$2798Maker spec sheet (PDF)assets.sonos.com/media-kits/hardware/ray/rayfactsheet.pdfRead 8 October 2026Official launch fact sheet USD price for the standalone bar, excluding US sales tax. Later shop prices are not launch prices.

$279.954Press releaseusa.yamaha.com/news_events/2023/yamaha-expands-its-lineup-of-dolby-atmos-sound-bars.htmlRead 13 October 2026US press release: SR-B30A $279.95 MSRP. Tax treatment is not stated.

Launch price (EU)iThe maker's euro launch price for the stated configuration, including VAT as published. Current store prices and later discounts do not qualify.

€2998Maker spec sheet (PDF)assets.sonos.com/media-kits/hardware/ray/rayfactsheet.pdfRead 8 October 2026Official launch fact sheet euro retail launch price as published for the standalone bar, including VAT.

Not available

MarketsiISO country or region codes where this exact model or variant is sold. A source page's language does not establish availability.

Not available

US1Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/index.htmlRead 13 October 2026

ColoursiThe maker's own colour names

Black, White1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026The black and white standalone bar have the same acoustic hardware.

Not available

Links

Not compared

Product page

www.sonos.com/en-us/shop/ray1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

usa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/index.html1Maker product pageusa.yamaha.com/products/audio_visual/sound_bar/sr-b30a/index.htmlRead 13 October 2026

Spec sheet

assets.sonos.com/media-kits/hardware/ray/rayfactsheet.pdf8Maker spec sheet (PDF)assets.sonos.com/media-kits/hardware/ray/rayfactsheet.pdfRead 8 October 2026

Not available

Manual

www.sonos.com/en-us/guides/ray1Maker product pagesonos.com/en-us/shop/rayRead 8 October 2026

usa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdf3Owner's manualusa.yamaha.com/files/download/other_assets/2/1624462/web_AV23-0023_SR-B30A_ug_UABGRIN_En_B0.pdfRead 13 October 2026

EPREL registration numberiId in the EU energy label database. Each size or model of a series has its own id, so it is per variant.

Not available

Not available

Warranty

1 of 1 differ

Manufacturer warranty (source market)iThe maker's warranty period for the exact SKU or configuration and market named in the source note. It applies only to that stated market, not every regional variant. Statutory consumer rights are excluded. The base term is stored. An extension that needs registration goes in the source note.

1year7Maker product pagesonos.com/en-us/legal/terms-of-useRead 8 October 2026US new product manufacturer warranty, section 10(a). One year from original purchase. Excludes statutory rights and extended protection.

Not available

Both are also in the API. Back to all soundbars.
