Gaming / Keyboards

Keychron Q5 HE 8K

KeychronGaming keyboard

Q5 HE 8K

Released March 2026.5Press articlepcvenus.com/keychron-q5-he-8k-gaming-keyboard-8000hzRead 14 October 2026Article dated 6 March 2026 says it is available in black and white through the Keychron store. The store product page was published on 5 March 2026 in its product data. Last checked 15 October 2026.

Form factor
96 % (1800)
Switch sensing technology
TMR
Connections
USB (wired)
Max polling rate
8,000Hz

87 of 164 fields known.

Compare with another keyboardDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Q HE 8K1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Product page and cart list it in the Q HE 8K series.
Model numbers
Q5HW-M1, Q5HW-P12Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboard.jsonRead 14 October 2026Store product data lists two SKUs: Q5HW-M1 (Black) and Q5HW-P1 (White).
GTIN / EAN
4894979052575, 48949790525822Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboard.jsonRead 14 October 2026Barcodes of the same two SKUs from the store product data.
Announced
March 20265Press articlepcvenus.com/keychron-q5-he-8k-gaming-keyboard-8000hzRead 14 October 2026Article dated 6 March 2026 reports the launch.
Status
Available6Press articlemechkeys.com/blogs/news/keychron-announces-q5-he-8k-magnetic-switch-keyboard-with-8k-polling-rateRead 14 October 2026Article dated 6 March 2026: the keyboard is now available through Keychron. The store page shows the Black SKU as backordered on the access date.
Predecessor
Not available
Successor
Not available
Launch price (US)
$239.991Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026US store regular price $239.99 for the Fully Assembled Knob Black and White. The press launch reports of 6 March 2026 give the same price.5Press articlepcvenus.com/keychron-q5-he-8k-gaming-keyboard-8000hzRead 14 October 2026Article: $239.99.6Press articlemechkeys.com/blogs/news/keychron-announces-q5-he-8k-magnetic-switch-keyboard-with-8k-polling-rateRead 14 October 2026Article: priced at $239.99, available through Keychron.
Launch price (EU)
Not available
Markets
US1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026US store page with USD prices.
Colours
Black, White2Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboard.jsonRead 14 October 2026Color options Black and White.
Segment
Gaming1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker text: a wired magnetic switch custom gaming keyboard.
Sold as
Complete1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Reference is the Fully Assembled Knob type. No barebone option is on the page.

Layout

Form factor
96 % (1800)1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Specs: layout 96 percent. Stored as the 1800 layout, which the schema defines as the 96 percent layout.
Layout standard
ANSI4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Overview diagram shows a horizontal Enter key. The maker plate file is for the US layout. The ISO collection tag on the site is a different SKU and is not covered.
Regional layouts
US ANSI4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026US layout, ANSI.
Keys in regional layout
1014Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Counted on the Windows layer diagram: 17 + 19 + 19 + 17 + 17 + 12 = 101, not counting the knob. The top row has Esc, F1 to F12, Del and three shape keys.
Key legends for
Windows, macOS1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Keycaps include Mac and Windows keycaps.
Numpad
Yes4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026
Function row
Yes4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026
Dedicated arrow keys
Yes4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026
Navigation keys
Compact4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Dedicated Del, Page Up, Page Down and Home. There is no End key.
Key stagger
Row-staggered4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Standard row-staggered layout in the diagrams.
Bottom row
Not available
Low profile
No1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Standard height. The maker describes the OSA profile as similar in height to OEM.

Switches

Switch sensing technology
TMR1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker: powered by TMR technology with contactless sensing. The switch family is called magnetic.
Switch feel
Linear3Maker product pagekeychron.com/cdn/shop/files/Q-HE-8K-Keychron-Ultra-Fast-Lime-Magnetic-Switch.pngRead 14 October 2026Switch card on the product page: switch type linear.
Switch maker
Keychron1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Switch models
Keychron Ultra-fast Lime Magnetic Switch1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Switch stem
Not available
Actuation force
Not available
Bottom-out force
55gf3Maker product pagekeychron.com/cdn/shop/files/Q-HE-8K-Keychron-Ultra-Fast-Lime-Magnetic-Switch.pngRead 14 October 2026Switch card: 55 g end force. The card also lists a 30 g start force, which is not an actuation force and is not stored.
Tactile bump force
Not available
Actuation point
Not available
Total travel
Not available
Rated keystrokes
100million3Maker product pagekeychron.com/cdn/shop/files/Q-HE-8K-Keychron-Ultra-Fast-Lime-Magnetic-Switch.pngRead 14 October 2026Switch card: 100 million clicks lifespan. The Lime switch page also says up to 100 million clicks.
Factory-lubed switches
Yes3Maker product pagekeychron.com/cdn/shop/files/Q-HE-8K-Keychron-Ultra-Fast-Lime-Magnetic-Switch.pngRead 14 October 2026Switch card: pre-lubed from factory.
Adjustable actuation
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Actuation range
Min0.1Max3.35mm1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Adjustable actuation points 0.1 to 3.35 mm.
Actuation step
0.01mm1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker: 0.01 mm sensitivity. Stored as the finest selectable step.
Per-key actuation
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker: customize each key with adjusting actuation points.
Rapid trigger
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Minimum rapid trigger movement
0.01mm1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Specs: sensitivity 0.01 mm. Stored as the finest selectable movement. Press and reset distances are set in Keychron Launcher.
Multi-action keys
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Dynamic Keystrokes: up to 4 actions per key by press depth.
SOCD handling
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Last Key Priority (LKP) and Snap Click. Both are off by default.
Analog input
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Analog Mode gives variable inputs like a game controller. Series table lists Gamepad Analog.
Hot-swap sockets
Magnetic1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Magnetic sockets. The page says it supports hot-swapping with Keychron Lime and Gateron Jade magnetic switches.
Compatible switches
Keychron Lime and Gateron Jade magnetic switches1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Footnote on the page: supports hot-swapping with Keychron Lime and Gateron Jade magnetic switches.
Stabilizers
PCB screw-in1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Specs: screw-in PCB stabilizer.
Factory-lubed stabilizers
Not available

Keycaps

Keycap material
PBT1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Legend method
Doubleshot1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Keycap profile
OSA1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker names the profile OSA, similar in height to OEM with an SA-like shape.
Keycap thickness
Not available
Shine-through legends
No1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker: south-facing RGB works with premium non-shine-through PBT keycaps.

Performance

Polling rate per connection
ConnectionPolling rate (Hz)
USB (wired)125
USB (wired)250
USB (wired)500
USB (wired)1,000
USB (wired)2,000
USB (wired)4,000
USB (wired)8,000
Source1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Specs: 8000 Hz, 4000 Hz and 1000 Hz. The 8K rate is wired only. The lower rates are from the user manual.4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Toggle switch can be set to 1K, 2K or 8K. Launcher supports 0.125K, 0.25K, 0.5K, 1K, 2K, 2K and 8K. The second 2K is read as the 4K rate listed on the product page. Default is 1K.
Max polling rate
8,000Hz
Polling rate (wired)
8,000Hz
Polling rate (2.4 GHz)
Not available
Polling rate (Bluetooth)
Not available
Scan rate
256kHz1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker: up to a 256 kHz single-key scanning rate.
Input latency (claimed)
Not available
Key rollover per connection
ConnectionRollover
USB (wired)NKRO
Source1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Specs: N-Key Rollover yes. The keyboard is wired only.
Anti-ghosting
Not available
Adjustable debounce
Not available
Minimum debounce
Not available

Measured

We could not find any of these 7 fields. Show them
Latency per connection (measured)
Not available
Actuation point (measured)
Not available
Total travel (measured)
Not available
Operating force (measured)
Not available
Typing noise (measured)
Not available
Battery life (measured)
Not available
Weight (measured)
Not available

Connectivity

Connections
USB (wired)1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Wireless technology
Not available
Bluetooth
Not available
Bluetooth device slots
Not available
Devices it can switch between
Not available
Device switching
Not available
Receiver connector
Not available
Receiver storage in keyboard
Not available
Receiver shared with other devices
Not available
Wireless range
Not available
Detachable cable
Yes4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Type-C cable and a Type-A to Type-C adapter are listed as separate items. The overview shows a Type-C port.
Port on keyboard
USB-C4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Overview: Type-C port on the side.
Cable plug
USB-C4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026In the box: Type-C cable and a Type-A to Type-C adapter. The cable itself ends in Type-C at the host.
Cable
Not available
Cable length
Not available
USB passthrough
Not available
Works with
Windows, macOS, Linux1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Specs: macOS, Windows and Linux.
Consoles
Not available

Battery

We could not find any of these 16 fields. Show them
Battery type
Not available
Number of batteries
Not available
Battery capacity
Not available
User-replaceable battery
Not available
Battery life per mode (claimed)
Not available
Longest battery life (claimed)
Not available
Battery life, lighting off
Not available
Battery life, lighting on
Not available
Battery life, backlight on (claimed)
Not available
Battery life, backlight off (claimed)
Not available
Charging port
Not available
Full charge time
Not available
Quick charge
Not available
Use while charging
Not available
Solar charging
Not available
Battery indicator
Not available

Build

Case material
6063 aluminum1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker: the entire metal body is crafted from 6063 aluminum.
Plate material
Aluminium1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Mount style
Gasket1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker: double-gasket design. Gaskets on the plate plus silicone pads between the top and bottom cases.
Flex cuts in PCB
Not available
Sound dampening
Case foam, Foam, position not stated, Other1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Maker lists a sound absorbing foam, latex bottom foams and a bottom case acoustic foam. The series table lists EVA foam, EPDM film, bottom case PET film and a silicone bottom pad for the 8K edition. The two lists differ. Stored as case foam, foam for the sound absorbing foam of unstated position and other.
Typing angles
5.3°1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Specs: angle 5.3 degrees. The same table gives a feet height of 1.24 mm while the manual says 2.4 mm. The angle is the same in both.
Spill resistant
Not available
IP rating
Not available

Lighting

Backlight
RGB per key1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026South-facing RGB LED with per-key RGB.
LED position
South-facing1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Lighting zones
Not available
Brightness levels
Not available
Side or underglow lighting
Not available
Lighting sensors
Not available
Lighting sync
Not available

Controls

Media keys
Fn layer4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Mute, volume, previous, play and next are on the F row with Fn. Shared keys, not separate buttons.
Separate media buttons
04Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026No separate media buttons in the diagrams. The knob press is excluded.
Volume control
Knob4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Overview shows a knob in the top right. On the Windows layer diagram the knob press is labelled Mute. The key description table lists Vol+ and Vol-. The default rotation function is not spelled out. Fn plus knob rotation changes the backlight brightness.
Knobs
14Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Overview: knob, number 1.
Programmable knob
Yes5Press articlepcvenus.com/keychron-q5-he-8k-gaming-keyboard-8000hzRead 14 October 2026Article: a programmable rotary knob.
Knob press
Yes4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Backlight setting: Fn + knob (press) turns the backlight on or off.
Separate macro keys
35Press articlepcvenus.com/keychron-q5-he-8k-gaming-keyboard-8000hzRead 14 October 2026Article: dedicated macro keys above the numpad. The three shape keys (circle, triangle, square) sit above the numpad. The Windows layer diagram labels them F13, F14 and F15. The maker pages do not call them macro keys.
Built-in screen
None4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026The overview shows no screen.
Touchpad
Not available
Fingerprint reader
Not available
OS mode switch
Switch4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Win Mac (OS toggle) on the side. Mac/iOS and Windows/Android positions.
Windows key lock
Not available

Software

Software
Keychron Launcher1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026
Software runs on
Web1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Keychron Launcher web app in a current Chrome, Opera or Edge browser, with the keyboard connected by cable.
Open firmware
Not available
Onboard memory
Yes4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Custom configurations are retained after power-off. Profile switching works with the physical toggle without software.
Onboard profiles
34Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Three-position switch selects the profiles Default, Gaming and Gamepad.
Macros
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Launcher: customize any macro command, shortcut or key combination.
Macros stored onboard
Not available
Key remapping
Yes1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026Launcher: remap keys.
Layers
44Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Four layers: layer 0 and 1 for Mac, layer 2 and 3 for Windows.
User firmware updates
Yes4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Firmware update tab in Keychron Launcher with the keyboard plugged in.

Ergonomics

Wrist rest
None1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 2026The Fully Assembled box has no palm rest. A silicone palm rest is sold separately.
Wrist rest material
Not available
Tenting
Not available
Tenting angles
Not available

Dimensions and weight

Front and side, drawn to scale.

Dimensions
Width408.1Depth144.8Height46.8Front height30.6mm(16.1 × 5.7 × 1.8 × 1.2 in)4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Specifications page: width 144.8 mm, length 408.1 mm. Back height 46.8 mm and front height 30.6 mm with keycaps installed (31.8 mm and 20.7 mm without keycaps). Whether the feet are folded is not stated.
Dimensions with wrist rest
Not available
Keyboard weight
2,301g(5.1 lb)1Maker product pagekeychron.com/products/keychron-q5-he-8k-magnetic-switch-keyboardRead 14 October 20262301 g plus or minus 10 g.
Weight including wrist rest
Not available
Box dimensions
Not available
Box weight
Not available

Certifications

We could not find any of these 2 fields. Show them
Platform certifications
Not available
Other certifications
Not available

In the box

In the box
Fully assembled keyboard with aluminum case, PCB, aluminum plate, sound absorbing foam, latex bottom pad and bottom case acoustic foam, 16 gaskets (12 installed and 4 in the box), 7 sets of stabilizers, PBT double-shot keycaps (Mac and Windows), Magnetic switches, Type-C cable, Type-A to Type-C adapter, Keycap and switch puller, Screwdriver, Hex key4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Fully Assembled Version page.
Cables included
TypeCount
Type-C cable1
Source4Owner's manualcdn.shopify.com/s/files/1/0059/0630/1017/files/Keychron_Q5_HE_8K_User_Manul.pdfRead 14 October 2026Type-C cable. The Type-A to Type-C adapter is not a cable and is only in the box list.
Spare switches
Not available

Warranty

Manufacturer warranty (source market)
1year7Maker product pagekeychron.com/pages/warrantyRead 14 October 2026Unless stated otherwise the warranty period is twelve months. The page lists the Q HE series. The HE 8K edition is not named separately. Global page, the market is not named.

Compare with

Pick a keyboard to see both side by side. Differences are marked yellow.

More keyboard comparisons

Variants

Each variant lists only what differs from the specs above.

Model numberGTINColours
Q5HW-M14894979052575Black
Q5HW-P14894979052582White

Sources

We read 7 sources for this keyboard. The numbers match the markers in the sheet.

  1. Read 14 October 2026Backs 47 fields
  2. Read 14 October 2026Backs 4 fields
  3. Read 14 October 2026Backs 4 fields
  4. Read 14 October 2026Backs 27 fields
  5. Read 14 October 2026Backs 5 fields
  6. Read 14 October 2026Backs 3 fields
  7. Maker product pagekeychron.com/pages/warranty
    Read 14 October 2026Backs 1 field

See a wrong value? Tell us and name the field.
