Lenovo Legion 5 (15", Gen 10) 15AHP10

LenovoGaming laptop

Legion 5 (15", Gen 10) 15AHP10

Released June 2025.4Spec databasetechspecsplus.com/laptops-notebooks-chromebooks-2-in-1/2025/lenovo/legion-5-15ahp10-amd-type-83m0-1236221Read 20 October 2026Released: 2025 (May), machine type 83M0, which lists 83M00002US among the US models. This matches the PSREF announce date of 20 May 2025. The first retail month is not confirmed, so June 2025 is the best estimate like the Legion 5i Gen 10 siblings. Last checked 20 October 2026.

Screen size
15.1in
Processor
AMD Ryzen 7 260
GPU
NVIDIA GeForce RTX 5060 Laptop GPU
Weight (published)
1.9kg

99 of 179 fields known.

Compare with another laptopDownload JSONDownload CSVGet it from the API

At a glance

Ports

  • Ethernet (RJ45)
  • USB-C USB 3.2 Gen 2
  • USB-C USB4
  • 3 USB-A USB 3.2 Gen 1
  • 3.5 mm audio
  • HDMI 2.1
  • DC in

All specs

SourceCalculated

General

Series
Legion 51Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Marketing name Lenovo Legion 5 (15 inch, 10), product family Legion 5.
Model numbers
83M00002US1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026PSREF page for model 83M00002US, machine type 83M0, region NA, country USA. Its data comes from the page's own public data service, because the page itself is script-rendered.
GTIN / EAN
1981564015331Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026EAN / UPC / JAN: 198156401533.
Announced
20 May 20251Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Announce Date: 2025-05-20. End of Support 2031-06-16 is a Lenovo support date, not an operating system update promise, so it is not stored.
Status
Available5Reviewframelimit.com/review-lenovo-legion-5-gen10-amdRead 20 October 2026Page updated 14 September 2026 covers the Ryzen 7 260, RTX 5060, 16GB DDR5 and 1TB SSD offer with the 15.1 inch 2560x1600 OLED, 80Wh and 1.9 kg, which matches 83M00002US. PSREF shows the model as not withdrawn.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
US1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Colours
Eclipse Black1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Case Color: Eclipse Black (with 24-Zone RGB Backlit Keyboard).
Segment
Gaming1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Form factor
Clamshell2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AHP10/Legion_5_15AHP10_Spec.PDFRead 20 October 2026Non-touch display, no pen support and no detachable screen in the spec sheet.

Chassis

Front and side, drawn to scale.

Dimensions
Width344.9Depth255.35Thickness (min)19.95Thickness (max)21.54mm(13.6 × 10.1 × 0.8 in)1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026344.9 x 255.35 x 19.95-21.54 mm. The spec sheet lists these dimensions for OLED models.
Weight (published)
1.9kg(4.2 lb)1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Starting at 1.9 kg (4.19 lbs). Lenovo says the weight is approximate and varies by configuration.
Lid material
Aluminium1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Case Material: Aluminium (Top), PC-ABS + 15% Talc (Bottom).
Bottom material
Plastic1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026PC-ABS + 15% Talc is a plastic.
Max hinge angle
Not available
MIL-STD-810 testing (claimed)
Not available

Display

Screen size
15.1in(38.4 cm)1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Display: 15.1 inch WQXGA (2560x1600) OLED, 165Hz. The spec sheet lists the IPS option as 15.3 inch, which is not this model.
Native resolution
2560 × 1600px1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Pixel density
199.9ppi
Panel type
OLED1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Backlight
None (self-emissive)1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Dimming zones
Not available
Panel part number
Not available
Screen surface
Glossy1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Display: glossy.
Touchscreen
No1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Stylus
None1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Pen Not Supported.
Refresh rate modes
Width (px)Height (px)Maximum operating refresh (Hz)
25601600165
Source1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026165Hz. The OLED row names no variable refresh technology, so it is not stored.
Max refresh rate
165Hz
Adaptive sync
Not available
Gray-to-gray response time (claimed)
Not available
Native panel colour depth
Not available
Brightness (SDR, claimed)
500nits1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026500nits (typical). The spec sheet marks the OLED as 500nits (SDR typical).
Peak brightness (SDR outdoors, claimed)
Not available
Sustained brightness (HDR, claimed)
Not available
Peak brightness (HDR, claimed)
1,000nits1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 20261000nits (peak) for HDR. The window size is not stated.
sRGB coverage (claimed)
Not available
DCI-P3 coverage (claimed)
100%1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026100% DCI-P3. Coverage or volume is not stated.
Adobe RGB coverage (claimed)
Not available
HDR certification
DisplayHDR True Black 6001Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026DisplayHDR True Black 600.
Factory calibrated
Yes1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Color Calibration: Factory Color Calibration. The spec sheet names X-Rite factory color calibration.
Second display
Not available

Processor

Processor
AMD Ryzen 7 2601Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Processor: AMD Ryzen 7 260 (8C / 16T, 3.8 / 5.1GHz, 8MB L2 / 16MB L3).
Processor brand
AMD1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Core configuration
Core typeCountCoreBase clock (GHz)Max clock (GHz)
Zen 48Zen 43.85.1
Source3Maker product pageamd.com/en/products/processors/laptop/ryzen/200-series/amd-ryzen-7-260.htmlRead 20 October 2026Processor Architecture Zen 4, 8 cores, 16 threads, base clock 3.8 GHz, max boost up to 5.1 GHz. AMD's Radeon 780M graphics and former codename Hawk Point.
CPU cores
8
Cores labelled performance
0
Cores labelled efficiency
0
Threads
161Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Max boost clock
5.1GHz
L3 cache
16MB1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Process
4nm3Maker product pageamd.com/en/products/processors/laptop/ryzen/200-series/amd-ryzen-7-260.htmlRead 20 October 2026Processor Technology for CPU Cores: TSMC 4nm FinFET.
Sustained CPU power (configured)
Not available
Peak CPU power (configured)
Not available
Combined CPU and GPU power
Not available
NPU performance
16TOPS1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026NPU: integrated AMD Ryzen AI, up to 16 TOPS. The overall 38 TOPS of the spec sheet also counts the CPU and GPU and is not stored.

Graphics

Discrete GPU
Yes1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
GPU
NVIDIA GeForce RTX 5060 Laptop GPU1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Graphics: NVIDIA GeForce RTX 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPS.
GPU brand
NVIDIA1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
VRAM
8GB1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Max GPU power (TGP)
115W1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026TGP 115W. Whether this includes Dynamic Boost is not stated.
Dynamic Boost
Not available
GPU boost clock
2,497MHz1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
GPU switching
Not available
Integrated GPU
AMD Radeon 780M2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AHP10/Legion_5_15AHP10_Spec.PDFRead 20 October 2026Processor table, Ryzen 7 260 row: processor graphics AMD Radeon 780M.

Memory

Installed RAM
16GB1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Memory: 1x 16GB SODIMM DDR5-5600. Two DDR5 SODIMM slots, dual-channel capable.
RAM type
DDR51Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
RAM speed
5,600MT/s1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Memory channels
11Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026One 16 GB module is installed in two slots, so memory runs as one channel until a second module is added.
RAM upgrade
Slots1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Two DDR5 SODIMM slots, one occupied.
Memory slots
SlotCountOccupiedModule size (GB)
SO-DIMM1Yes16
SO-DIMM1NoNot available
Source1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026One slot holds the 16 GB module. The second slot is free. The module size of a free slot is not stated.
RAM slots
2
Free RAM slots
1
Maximum supported RAM
32GB1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Up to 32GB DDR5-5600 offering, based on current Lenovo memory offerings.

Storage

Installed storage
1TB1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Storage: 1TB SSD M.2 2242 PCIe 4.0x4 NVMe.
Storage type
NVMe SSD1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Installed drive PCIe generation
41Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Storage slots
Form factorInterfacePCIe generationPCIe lanesCountOccupied
M.2 2280PCIe NVMe441Yes
M.2 2280PCIe NVMe421No
Source1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Two M.2 2280 PCIe 4.0 slots. The 1st slot supports x4 lanes and the 2nd slot x2 lanes. The spec sheet says Lenovo offers one SSD with a second slot for self-expansion. The installed drive is PCIe 4.0 x4, so it sits in the first slot.
M.2 slots
2
Free storage slots
1
Maximum slot PCIe generation
4

Ports

Ports
TypeVersionCountSideMaximum data rate (Gbps)Thunderbolt or USB4DP Alt ModeMaximum charging input (W)
Ethernet (RJ45)Not available1Left1Not availableNot availableNot available
USB-CUSB 3.2 Gen 21Left10Not availableYes100
USB-CUSB41Left40USB4YesNot available
USB-AUSB 3.2 Gen 11Left5Not availableNot availableNot available
3.5 mm audioNot available1RightNot availableNot availableNot availableNot available
USB-AUSB 3.2 Gen 12Right5Not availableNot availableNot available
HDMIHDMI 2.11RearNot availableNot availableNot availableNot available
DC inNot available1RearNot availableNot availableNot availableNot available
Source1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Standard Ports: 2x USB-A 5Gbps, 1x USB-A 5Gbps Always On, 1x USB-C 10Gbps with USB PD 95-100W and DisplayPort 2.1, 1x USB-C USB4 40Gbps with DP 1.4, 1x HDMI 2.1 up to 8K/60Hz, 1x combo jack, 1x RJ-45, 1x slim tip power connector. Footnote: the 10Gbps USB-C port supports the Lenovo protocol for 140W charging but needs a unique Lenovo adapter, so 100 W is stored. The overview diagram shows two side views and a rear view. The left and right views are matched to the sides described in the T3 review of the Legion 5 Gen 10 chassis. Rear: HDMI and the power connector.6Reviewt3.com/tech/laptops/lenovo-legion-5-review-gen-10Read 20 October 2026The review of the Intel Legion 5 Gen 10 unit says the left side has a USB-A port, two USB-C ports and Ethernet. The right side has two USB-A ports and the 3.5 mm jack. The back has HDMI and the power socket. The Lenovo overview diagram of the AMD model shows the same groups. Only the side labels come from this review.
USB-C ports
2
Thunderbolt
No
Highest HDMI version
HDMI 2.1
Card reader
No
Ethernet speed
1Gbps
Maximum USB-C charging input
100W

Wireless

Wi-Fi
Wi-Fi 71Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026WLAN + Bluetooth: Wi-Fi 7, 802.11be 2x2 + BT5.4.
Wi-Fi bands
Not available
Wi-Fi module
Not available
Bluetooth
5.41Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Cellular
No1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026WWAN Not Supported.

Keyboard and touchpad

Keyboard layouts
English1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Keyboard: 24-Zone RGB Backlit, English.
Key switches
Not available
Keyboard backlight
RGB zones1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 202624-Zone RGB Backlit.
Numpad
Yes2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AHP10/Legion_5_15AHP10_Spec.PDFRead 20 October 2026Keyboard: 6-row, multimedia Fn keys, numeric keypad, key travel 1.6mm, cap recess 0.3mm, Copilot key.
Key travel
1.6mm2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AHP10/Legion_5_15AHP10_Spec.PDFRead 20 October 2026Key travel 1.6mm.
Pointing stick
Not available
Touchpad size
Width120Height75mm(4.7 × 3 in)1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Buttonless Mylar surface multi-touch touchpad, 75 x 120 mm.2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AHP10/Legion_5_15AHP10_Spec.PDFRead 20 October 202675 x 120 mm (2.95 x 4.72 inches).
Touchpad mechanism
Not available

Camera and audio

Webcam
5.0MP1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Camera: 5.0MP with E-shutter.
IR face login
Not available
Webcam privacy
Electronic kill switch1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026E-shutter is listed under Other Security.
Built-in speaker drivers
21Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio.
Total speaker power
4W1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Audio features
Audio by HARMAN, Nahimic Audio1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Microphones
21Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Microphone: 2x, array.

Battery and power

Battery energy
80Wh1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Battery: 80Wh.
Claimed battery life
Use caseHours (h)
MobileMark 305.6
Video playback9.6
Source2Maker spec sheet (PDF)psref.lenovo.com/syspool/Sys/PDF/Legion/Legion_5_15AHP10/Legion_5_15AHP10_Spec.PDFRead 20 October 2026Models with 80Wh battery: MobileMark 30 at 250nits 5.6 hr, local video (1080p) playback at 150nits 9.6 hr. Claims are approximate maximums.
Adapter rated output
245W1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Power Adapter: 245W Slim Tip (3-pin).
Laptop charging connector
Proprietary1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Slim tip (rectangle) power connector.
Charge 0 to 50 % (claimed)
Not available

Cooling

We could not find any of these 4 fields. Show them
Fans
Not available
Vapor chamber
Not available
Liquid metal
Not available
Power modes
Not available

Security

Fingerprint
None1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026No Fingerprint Reader.
TPM
2.01Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Firmware TPM 2.0 Enabled.
Remote management
Not available
Security lock slot
Not available

Software

Operating system
Windows 11 Home1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Operating System: Windows 11 Home, English.
OS family
Windows1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026
Security updates until
Not available

Measured display

We could not find any of these 12 fields. Show them
Brightness (measured, centre)
Not available
Brightness (measured, average)
Not available
Contrast ratio (measured)
Not available
HDR peak brightness (measured)
Not available
sRGB coverage (measured)
Not available
DCI-P3 coverage (measured)
Not available
Colour accuracy (measured Delta E)
Not available
PWM flicker found
Not available
PWM frequency (measured)
Not available
PWM at or below brightness
Not available
Response black to white (measured)
Not available
Response grey to grey (measured)
Not available

Measured performance

We could not find any of these 8 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
3DMark Time Spy graphics
Not available
3DMark Steel Nomad
Not available
SSD sequential read (measured)
Not available
Game frame rates
Not available

Measured noise and temperature

We could not find any of these 9 fields. Show them
Fan noise per mode
Not available
Max fan noise
Not available
Fan noise while gaming
Not available
Top surface under load
Not available
Bottom surface under load
Not available
Palm rest under load
Not available
CPU temperature in stress test
Not available
CPU clock in stress test
Not available
GPU temperature while gaming
Not available

Measured battery and power

We could not find any of these 10 fields. Show them
Battery runtime per test
Not available
Wi-Fi browsing runtime
Not available
Video runtime
Not available
Full charge time (measured)
Not available
Power draw idle
Not available
Power draw gaming
Not available
Power draw max
Not available
Sustained CPU power (measured)
Not available
GPU power while gaming (measured)
Not available
Weight (measured)
Not available

Certifications

Intel Evo
Not available
Copilot+ PC
Not available
Colour certifications
Not available
ENERGY STAR
Yes1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026ENERGY STAR 9.0. The spec sheet says this is only available on models with a preloaded OS.
EPEAT
Gold1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026EPEAT Gold Registered, only on models with a preloaded OS.
Other certifications
TÜV Rheinland Low Blue Light (Hardware Solution), ErP Lot 6/26, RoHS compliant1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Other Certifications: TÜV Rheinland Low Blue Light (Hardware Solution). The Flicker Free option is not listed for this model. Green Certifications add ErP Lot 6/26 and RoHS compliant.

In the box

In the box
Not available
Power adapter included
Yes1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Power Adapter: 245W Slim Tip is listed for this model and Bundled Accessories reads None. The spec sheet says adapter offers depend on the country.

Warranty

Manufacturer warranty (source market)
1year1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 2026Base Warranty: 1-year, Courier or Carry-in. The market is the US.
Warranty service
Collect and return, Carry-in1Maker product pagepsref.lenovo.com/Detail/Legion/Legion_5_15AHP10Read 20 October 20261-year courier or carry-in service.

Compare with

Pick a laptop to see both side by side. Differences are marked yellow.

More laptop comparisons

Sources

We read 6 sources for this laptop. The numbers match the markers in the sheet.

  1. Read 20 October 2026Backs 72 fields
  2. Read 20 October 2026Backs 8 fields
  3. Read 20 October 2026Backs 2 fields
  4. Read 20 October 2026Backs 1 field
  5. Read 20 October 2026Backs 1 field
  6. Read 20 October 2026Backs 2 fields

See a wrong value? Tell us and name the field.
