Computers / Routers
ASUSHome router
ZenWiFi BT10
Released July 2024.6Reviewdongknows.com/asus-zenwifi-bt10-reviewRead 15 October 2026The table gives the US release as Q3 2024, so July 2024 is stored. The text says the launch was in early June and that a preview was first posted on 2024-08-03. A one month error is acceptable. Last checked 15 October 2026.
- Form factor
- Mesh system
- Wi-Fi
- Wi-Fi 7
- Speed class
- BE18000
- WAN port
- 10Gbps
58 of 90 fields known.
At a glance
Wi-Fi link rate
17,981Mbps
Higher than 84% of other routers.
Coverage per unit
Higher than 75% of other routers.
Ports
- 3 RJ45
- USB-A USB 3.2 Gen 1
General
- Model numbers
- BT10, BT10(W-1-PK), BT10(W-2-PK), BT10(W-3-PK)2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Model Name row: BT10(W-3-PK), BT10(W-2-PK) and BT10(W-1-PK). The quick start guide says Model: BT10.
- GTIN / EAN
- 197105429833, 1971054299569Retailer pageglobal.channelonline.com/andrew/enduser/Products/overview/M025578487Read 15 October 2026Part BT10(W-1-PK), UPC 0197105429833. Stored without the leading zero.10Retailer pageglobal.channelonline.com/acme/classic/Products/overview/M025578488Read 15 October 2026Part BT10(W-2-PK), UPC 0197105429956. A second listing of a 2PK part shows 0197105429895, which is left out because its part number differs.
- Announced
- Not available
- Status
- Available1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026The US page and the ASUS eShop sell the 1, 2 and 3 packs.4Retailer pageeshop.asus.com/us/90ig08y0-ma1c6v-asus-zenwifi-bt10.htmlRead 15 October 2026ASUS eShop USA lists BT10(W-1-PK), part number 90IG08Y0-MA1C6V, at 359.99 dollars. Part numbers 90IG08Y0-MA1C4V and 90IG08Y0-MA1C2V are the 2 and 3 packs.
- Predecessor
- Not available
- Successor
- Not available
- Launch price (US)
- Not available
- Launch price (EU)
- Not available
- Markets
- Not available
Wi-Fi
- Wi-Fi speed class
- BE180002Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Product Segment row: BE18000, 688+5764+11529 Mbps.
- Wi-Fi radios
Band Wi-Fi Streams Max channel width (MHz) Max link rate (Mbps) Dedicated backhaul 2.4 GHz Wi-Fi 7 2 40 688 No 5 GHz Wi-Fi 7 4 160 5,764 No 6 GHz Wi-Fi 7 4 320 11,529 No Source1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026Smart AiMesh backhaul uses Multi-Link Operation, aggregating or switching across multiple bands, so no radio is only a backhaul. TechRadar says the 6 GHz channel can optionally be reserved for backhaul, with Auto giving better results, so dedicated_backhaul is stored as false.2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026WiFi Data Rate: 6 GHz up to 11529 Mbps, 5 GHz up to 5764 Mbps and 2.4 GHz up to 688 Mbps, all WiFi 7. Transmit / Receive: 6 GHz 4x4, 5 GHz 4x4 and 2.4 GHz 2x2. Boosts Speed lists 20/40/80/160/320 MHz in total. Widths per band are 40 MHz at 2.4 GHz, 160 MHz at 5 GHz and 320 MHz at 6 GHz. Dong Knows Tech prints the same widths per band (see its entry), and they give the printed rates with those streams.6Reviewdongknows.com/asus-zenwifi-bt10-reviewRead 15 October 2026Hardware table: 2.4 GHz 2x2 up to 688 Mbps (20/40 MHz), 5 GHz 4x4 up to 5762 Mbps (20/40/80/160 MHz) and 6 GHz 4x4 up to 11,525 Mbps (20/40/80/160/320 MHz). ASUS prints 5764 and 11529, which are stored. These are the widths per band.- Radio bands
- 3
- 6 GHz band
- Yes
- Combined Wi-Fi link rate
- 17,981Mbps
- Wi-Fi streams
- 10
- Max Wi-Fi channel width
- 320MHz
- Wi-Fi features
- Multi-Link Operation (MLO), 4K-QAM, OFDMA, MU-MIMO, Band steering1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026Comprehensive MLO Support: Multi-Link Operation combines and switches between the 2.4, 5 and 6 GHz bands. The page also names 4K-QAM and 320 MHz channels. Band steering comes from Tom's Hardware, see that source.2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Boosts Speed: OFDMA, 4096-QAM and 20/40/80/160/320 MHz bandwidth. Wireless row: MU-MIMO. Multi-RU, preamble puncturing, TWT and AFC are not listed. Dong Knows Tech shows AFC as TBD.7Reviewtomshardware.com/networking/routers/asus-zenwifi-bt10-wi-fi-7-mesh-router-reviewRead 15 October 2026The review unit came preconfigured with the 2.4, 5 and 6 GHz bands under a single SSID (Smart Connect). Stored as band_steering. Tom's Hardware measured 2,667 Mbps on 6 GHz and 1,293 Mbps on 5 GHz at six feet with iPerf3, which is a different method and is not stored.
- Internal antennas
- 81Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026Eight internal antennas and ten high-power front-end modules.2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Internal antennas x 8.
- Detachable antennas
- No2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026The antennas are internal.
- Coverage of one unit (claimed)
- 279m²1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026A 1pk coverage up to 3,000 sq. ft. and a 2pk coverage up to 6,000 sq. ft. 3,000 sq. ft. converted exactly is 278.7 and stored as 279. The page gives no 3pk figure.
- Connected devices per unit (claimed)
- Not available
Ports and modem
- Ports
Port Count Role Max speed (Gbps) Version RJ45 1 WAN or LAN 1 Not available RJ45 1 WAN or LAN 10 Not available RJ45 1 LAN 10 Not available USB-A 1 Not available 5 USB 3.2 Gen 1 Source2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026I/O Ports: 10G WAN/LAN x 1, 10G LAN x 1, 1G WAN/LAN x 1 and USB 3.0 x 1. The manual labels them WAN/LAN1, 10G WAN/LAN2 and 10G LAN3 and calls the USB port USB 3.2 Gen 1x1. Stored as USB 3.2 Gen 1 at 5 Gbps.3Owner's manualdlcdnets.asus.com/pub/ASUS/wireless/BT10/E27195_ZenWiFi_BT10_UM_V2_EAA_WEB.pdfRead 15 October 2026Section 1.3: USB 3.2 Gen 1x1 port, WAN/LAN1 port, 10G WAN/LAN2 port and 10G LAN3 port.- Ethernet ports
- 3
- Multi-gig ports
- 2
- Fastest WAN port
- 10Gbps
- Fastest LAN port
- 10Gbps
- USB ports
- 1
- SFP+ port
- No
- Built-in modem
- Not available
- Modem standards
- Not available
Mesh
- Mesh technologies
- AiMesh1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026Smart AiMesh. The primary AiMesh router works with compatible ASUS routers as nodes.2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026AiMesh: primary AiMesh router and AiMesh node.
- Units per pack
- 1, 2, 31Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026ASUS sells 1, 2 and 3 packs.
- Coverage of the pack (claimed)
- Not available
- Satellite model
- Not available
- Satellite ports
- Not available
- Ethernet backhaul
- Yes1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026Dual 10G ports extend a 10G wired mesh backhaul between nodes. The page also names a flexible WAN or wired backhaul configuration with auto detection.7Reviewtomshardware.com/networking/routers/asus-zenwifi-bt10-wi-fi-7-mesh-router-reviewRead 15 October 2026The 10G LAN port can be used for a wired backhaul between the router and the satellite.
Software
- Management
- Mobile app, Web interface2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Router APP: ASUS Router APP. The web interface comes from the manual.3Owner's manualdlcdnets.asus.com/pub/ASUS/wireless/BT10/E27195_ZenWiFi_BT10_UM_V2_EAA_WEB.pdfRead 15 October 2026Setup runs through the ASUS Router app or the web GUI (ASUSWRT) at asusrouter.com.
- Operating modes
- Router, Access point, Mesh node2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Operating Mode: Access Point Mode, AiMesh Node Mode and Wireless Router Mode.
- Network features
- Guest network, IoT network, IPTV, Dual WAN, LAN aggregation, QoS, Parental controls, Dynamic DNS1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026Smart Home Master gives up to three SSIDs: IoT Network, Kid's Network and VPN Network. Parental controls are said to come without subscriptions.2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Listed: Guest Network, Parental Control, Dual WAN, DDNS, IPTV, LAN Link Aggregation, Adaptive QoS and Traditional QoS. IoT Network comes from the product page. WAN aggregation and VLAN are not listed.
- VPN server
- WireGuard, OpenVPN, IPsec, PPTP2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026VPN row: VPN Server IPSec, OpenVPN, PPTP and WireGuard.
- VPN client
- WireGuard, OpenVPN, L2TP, PPTP2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026VPN row: VPN Client L2TP, OpenVPN, PPTP and WireGuard. VPN Fusion and Instant Guard are also listed.
- USB applications
- File server, Media server, Time Machine, Printer server, Cellular modem2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026USB application row: 4G / 5G Auto Mobile Tethering, AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server and FTP Server. The WAN row lists 3G / 4G LTE Dongle. Printer server comes from Tom's Hardware.7Reviewtomshardware.com/networking/routers/asus-zenwifi-bt10-wi-fi-7-mesh-router-reviewRead 15 October 2026USB application section: Time Machine backup, a network printer server, and a smartphone cellular connection for internet access.
Security
- Wi-Fi security
- WPA2-Personal, WPA3-Personal, WPA2-Enterprise2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Security row: WPA/WPA2/WPA3-Personal and WPA/WPA2-Enterprise. A footnote says WPA/WPA2 Enterprise is only available on a single router and not under AiMesh mode.
- Security service
- AiProtection Pro1Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026Commercial-grade AiProtection Pro powered by Trend Micro.2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026AiProtection row: AiProtection Pro with Router Security Assessment, Malicious Site Blocking, Two-Way IPS and Infected Device Prevention and Blocking.
- Automatic firmware updates
- Yes2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Administration row: Auto Firmware Update.
- Security updates until
- 31 December 20285Maker product pageasus.com/support/faq/1051929Read 15 October 2026The UK FAQ on security update support (PSTI), updated 2026-08-19, lists ZenWiFi BT10 with a product security update period of 4 years, until 31 December 2028, and says extended support may be provided after that date. The date is a minimum and applies to the UK.
Smart home
- Thread border router
- Not available
- Matter controller
- Not available
- Zigbee hub
- Not available
- Bluetooth
- Not available
Hardware
- System on chip
- Not available
- Cooling fan
- Not available
Power
- Power supply
- External DC adapter2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026AC Input 110V~240V (50~60Hz), DC Output 12V with max. 3A current.
- Rated power input
- 12 V, 3 A2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026DC Output 12V with max. 3A current. The manual lists the same rating.3Owner's manualdlcdnets.asus.com/pub/ASUS/wireless/BT10/E27195_ZenWiFi_BT10_UM_V2_EAA_WEB.pdfRead 15 October 2026Section 1.3 notes: DC power adapter output +12V with 3A current.
- Included adapter output
- 36W2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 202612 V at a maximum of 3 A is 36 W.
- Power use (typical, claimed)
- Not available
- Power use (max, claimed)
- Not available
Measured
- Wi-Fi throughput (measured)
- Not available
- Fastest Wi-Fi throughput (measured)
- Not available
- Wi-Fi throughput through a wall (measured)
- Not available
- Range (measured)
- Not available
- Power use under load (measured)
- Not available
- Energy use per day (measured)
- 360Wh6Reviewdongknows.com/asus-zenwifi-bt10-reviewRead 15 October 2026Energy use per 24 hours reads about 360 for the router unit and about 250 for the satellite unit. The BT10 cells print no unit, while the BQ16 Pro cell on the same row reads Wh. Firmware 3.0.0.6.102_36758.
Dimensions and weight
Front and side, drawn to scale.
- Dimensions
- Width159Height186Depth72mm(6.3 × 7.3 × 2.8 in)2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026Product Dimensions 159 x 72 x 186 mm, printed without labels. The unit stands upright, so 186 mm is the height. A retailer listing gives width 6.3 in, depth 2.8 in and height 7.3 in, which fits 159 wide, 72 deep and 186 high. Tom's Hardware prints 7.48 x 6.14 x 2.91 in, which is not stored.8Reviewtechradar.com/computing/servers-network-devices/asus-zenwifi-bt10-reviewRead 15 October 2026Specification table lists 159 x 186 x 72 mm with a (HxWxD) label. The values match the ASUS 159 x 72 x 186 mm and a 186 mm tall unit. TechRadar measured 1,661 Mbps close range, 614 Mbps two rooms away and 370 Mbps at 15 m with downloads from a Synology NAS to an HP OmniBook Ultra Flip 14. That is not Tom's Guide IxChariot, so it is not stored.
- Dimensions with antennas
- Not available
- Wall mountable
- Not available
Certifications
We could not find any of these 3 fields. Show them
- Wi-Fi Alliance certification ID
- Not available
- FCC ID
- Not available
- Other certifications
- Not available
In the box
We could not find any of these 1 fields. Show them
- In the box
- Not available
Links
- Product page
- www.asus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt101Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10Read 15 October 2026
- Spec sheet
- www.asus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspec2Maker product pageasus.com/us/networking-iot-servers/whole-home-mesh-systems/asus-zenwifi/asus-zenwifi-bt10/techspecRead 15 October 2026
- Manual
- dlcdnets.asus.com/pub/ASUS/wireless/BT10/E27195_ZenWiFi_BT10_UM_V2_EAA_WEB.pdf3Owner's manualdlcdnets.asus.com/pub/ASUS/wireless/BT10/E27195_ZenWiFi_BT10_UM_V2_EAA_WEB.pdfRead 15 October 2026English user manual, published 2025-10-15 on the ASUS support page.
- EPREL registration number
- Not available
Warranty
Compare with
Pick a router to see both side by side. Differences are marked yellow.
Variants
Each variant lists only what differs from the specs above.
| Model number | GTIN | Units per pack | Coverage of the pack (claimed) | In the box |
|---|---|---|---|---|
| BT10(W-1-PK) | 197105429833 | 1 | 279 m² | ZenWiFi BT10, RJ45 cable, Power adapter, Warranty card, Quick start guide |
| BT10(W-2-PK) | 197105429956 | 2 | 557 m² | Not available |
| BT10(W-3-PK) | Not available | 3 | Not available | Not available |
Sources
We read 11 sources for this router. The numbers match the markers in the sheet.
