Graphics cards / Compare

ASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition vs Gainward GeForce RTX 5090 Phantom

A

Product A: ASUS

ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition

81 of 100 known

Change ASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition

Compare the Gainward GeForce RTX 5090 Phantom with

Search graphics cards

B

Product B: Gainward

GeForce RTX 5090 Phantom

70 of 100 known

Change Gainward GeForce RTX 5090 Phantom

Compare the ASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition with

Search graphics cards

All 100 fields

Every value links to where we found it.

Only differences

AASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition

BGainward GeForce RTX 5090 Phantom

General

3 of 10 differ

Series

ROG Astral1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026The page is the ROG Astral line page for this card.

Phantom1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Breadcrumb and Gainward Series menu: PHANTOM.

Model numbersiMaker identifiers for this exact model and its listed variants. Excludes sibling models and other generations.

ROG-ASTRAL-RTX5090-O32G-GAMING, 90YV0LW0-MVAA00, 90YV0LW0-M0NA002Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Model ROG-ASTRAL-RTX5090-O32G-GAMING, named ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition.3Maker product pageeshop.asus.com/us/90yv0lw0-mvaa00-rog-astral-rtx5090-o32g-gaming.htmlRead 16 October 2026ASUS eShop USA: part number 90YV0LW0-MVAA00.7Retailer pageeu.computerorbit.com/products/asus-geforce-rtx-5090-rog-astral-oc-32gb-graphics-card.jsonRead 16 October 2026SKU 90YV0LW0-M0NA00 in the shop's product feed.8Spec databasegeizhals.de/asus-rog-astral-geforce-rtx-5090-oc-a3382344.htmlRead 16 October 2026Article number 90YV0LW0-M0NA00 for ROG-ASTRAL-RTX5090-O32G-GAMING.

NE75090019R5-GB2020P1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026P/N NE75090019R5-GB2020P. The Phantom GS has its own code, NE75090S19R5-GB2020P, and a higher boost clock, so it is another card. Palit's NE75090019R5-GB2020G is a Palit card.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Header: GEFORCE RTX 5090 PHANTOM, P/N NE75090019R5-GB2020P.

GTIN / EAN

47113878902887Retailer pageeu.computerorbit.com/products/asus-geforce-rtx-5090-rog-astral-oc-32gb-graphics-card.jsonRead 16 October 2026The shop's public product feed gives SKU 90YV0LW0-M0NA00 and barcode 4711387890288 (EAN-13). Several other shops list the same EAN for that SKU.

47105622448781Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Barcode 4710562244878. The datasheet prints the same number as BAR CODE 471056224-4878.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Header: BAR CODE 471056224-4878.

AnnouncediThe maker's first announcement of this model. This is separate from first retail availability.

7 January 20256Press releaserog.asus.com/me-en/articles/gaming-graphics-cards/introducing-the-rog-astral-geforce-rtx-5090-and-5080-a-new-frontier-of-gaming-graphicsRead 16 October 2026ASUS article dated 2025-01-07 introducing the ROG Astral GeForce RTX 5090 and 5080.

Not available

Status

Available8Spec databasegeizhals.de/asus-rog-astral-geforce-rtx-5090-oc-a3382344.htmlRead 16 October 2026Geizhals lists 5 offers for this model on 2026-10-16, from 6790 to 10167 EUR.

Available10Retailer pageldlc.com/en/product/PB00662760.htmlRead 15 October 2026LDLC listing of the Gainward GeForce RTX 5090 Phantom: in stock on 2026-10-15.11Retailer pagealternate.de/html/search.htmlRead 15 October 2026ALTERNATE search for NE75090019R5-GB2020P on 2026-10-15: the Gainward GeForce RTX 5090 Phantom is listed as Sofort verfuegbar, with 13 ratings. The product page itself showed a bot check and was not opened.12Spec databasegeizhals.de/gainward-geforce-rtx-5090-phantom-4878-ne75090019r5-gb2020p-a3382613.htmlRead 15 October 2026Geizhals Germany lists the card with 2 offers from 8622 EUR on 2026-10-15.

PredecessoriThe model this one directly replaced, in the same line, tier and size, as the maker or a trusted review names it.

Not available

Not available

SuccessoriThe model that directly replaced this one, in the same line, tier and size. A revision such as a Slim or OLED model does not count when a next generation exists.

Not available

Not available

Launch price (US)iThe maker's US launch MSRP for the stated configuration, excluding tax. Current store prices and later discounts do not qualify.

Not available

Not available

Launch price (EU)iThe maker's euro launch price for the stated configuration, including VAT as published. Current store prices and later discounts do not qualify.

Not available

Not available

MarketsiISO country or region codes where this exact model or variant is sold. A source page's language does not establish availability.

Not available

Not available

ColoursiThe maker's own colour names

Not available

Black1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026The overview text says the Phantom Series has an all-black design.

GPUiThe graphics chip as the chip maker names it, without the card maker's name or the memory size, e.g. "NVIDIA GeForce RTX 5070 Ti", "AMD Radeon RX 9070 XT", "Intel Arc B580". The memory size is in VRAM.

NVIDIA GeForce RTX 50901Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 20262Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 202612Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

NVIDIA GeForce RTX 50901Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026

GPU brandiThe chip maker, not the card maker.

NVIDIA12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

NVIDIA4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026The GeForce RTX 5090 is an NVIDIA GPU. Gainward is the card maker.

Reference launch price (US)iThe chip maker's launch price for this GPU in USD, excluding tax. It repeats in every card with this GPU and is not the card's own price. A price the card maker states goes in the launch price field.

$1,99915Press releasenvidianews.nvidia.com/news/nvidia-blackwell-geforce-rtx-50-series-opens-new-world-of-ai-computer-graphicsRead 16 October 2026GeForce RTX 5090 at $1,999, available on 2025-01-30, dated 2025-01-06. NVIDIA's own price for the GPU, not ASUS's price for this card.

$1,9997Press releasenvidianews.nvidia.com/news/nvidia-blackwell-geforce-rtx-50-series-opens-new-world-of-ai-computer-graphicsRead 15 October 2026Dated 2025-01-06: the GeForce RTX 5090 is available on Jan. 30 at $1,999. No tax is included in the figure.

GPU

0 of 14 differ

GPU architectureiAs the chip maker names it, e.g. "Blackwell", "RDNA 4", "Xe2".

Blackwell12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 202613Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026

Blackwell4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026NVIDIA Architecture: Blackwell.

GPU dieiThe die name, e.g. "GB203", "Navi 48", "BMG-G21". Cards with the same GPU name can use different dies.

GB20213Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Appendix A, Table 3: Blackwell GB202 GPU, used for the RTX 5090.

GB2025Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Appendix A, Table 3: the RTX 5090 uses the GB202 GPU.

ProcessiFoundry process name as the chip maker writes it, e.g. "TSMC 4N". When the chip maker names none, a spec table in a trusted review counts, and the source note says so. Node names are marketing names, not a physical size. Write the foundry and its node name with no unit, such as "Samsung 8N", not "Samsung 8 nm".

TSMC 4N13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: manufacturing process TSMC 4nm 4N, NVIDIA custom process.

TSMC 4N5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: TSMC 4nm 4N, NVIDIA Custom Process.

TransistorsiTransistors on the whole die, in billions. A cut-down GPU keeps the full count of its die.

92.2billion13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: 92.2 billion.

92.2billion5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 92.2 billion, the full GB202 die.

Die sizeiArea of the whole die.

750mm²13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: 750 mm2.

750mm²5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 750 mm2.

Compute unitsiNVIDIA streaming multiprocessors (SM), AMD compute units (CU) or Intel Xe-cores, enabled on this GPU. The blocks differ between makers, so compare within one maker.

17013Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: 170 SMs.

1705Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 170 SMs on the RTX 5090. The full GB202 has 192.

Shader coresiNVIDIA CUDA cores or AMD stream processors, as published. For Intel only a shader count a trusted source states, not a count of Xe Vector Engines. Makers count differently, so compare within one maker.

21,7602Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 202612Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 202613Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026

21,7602Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026CUDA Cores 21760.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026NVIDIA CUDA Cores 21760.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 21760 CUDA cores.

Ray tracing coresiNVIDIA RT cores, AMD Ray Accelerators or Intel Ray Tracing Units, enabled on this GPU.

17013Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: 170 RT cores.

1705Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 170 RT Cores (4th Gen).

AI coresiNVIDIA Tensor cores, AMD AI Accelerators or Intel XMX engines, enabled on this GPU.

68013Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: 680 Tensor cores.

6805Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 680 Tensor Cores (5th Gen).

ROPsiRender output units enabled on this GPU.

17613Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: 176 ROPs.

1765Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 176 ROPs.

L2 cacheiL2 cache enabled on this GPU.

96MB13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: L2 cache 98304 KB, which is 96 MB.

96MB5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 98304 KB, which is 96 MB.

Infinity Cache (L3)iAMD Infinity Cache, a last-level cache behind L2. Left out for a GPU whose maker states no such cache.

Not available

Not available

FP32 compute (claimed)iPeak single-precision shader throughput the chip maker publishes. Makers count operations differently. AMD includes dual-issue rates. Not a game performance figure.

104.8TFLOPS13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: peak FP32 104.8 TFLOPS at the reference boost clock.

104.8TFLOPS5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: peak FP32 104.8 TFLOPS, based on the 2407 MHz GPU Boost Clock.

AI performance (claimed)iPeak AI throughput the maker publishes, one row per precision and sparsity. A figure without a stated precision stays out. Compare rows with the same precision and sparsity only. NVIDIA: store the headline rows (FP8 and FP16 with FP16 accumulate, FP4 as listed) and name the accumulate precision in the source note. When a maker does not say whether a figure uses sparsity, leave the sparse key out of that row. The chip maker's figures are stored, the same in every card with that GPU. A card maker's higher figure for its own clocks, such as an OC mode, goes in the source note.

AASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition

Precision	With sparsity	Throughput (TOPS)
FP4	No	1,676
FP4	Yes	3,352
FP8	No	838
FP8	Yes	1,676
FP16	No	419
FP16	Yes	838
INT8	No	838
INT8	Yes	1,676

Source13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3, effective rates without and with sparsity. FP4 uses FP32 accumulate. FP8 and FP16 rows use FP16 accumulate. INT8 as listed. ASUS's 3352 TOPs is the FP4 sparse figure.

BGainward GeForce RTX 5090 Phantom

Precision	With sparsity	Throughput (TOPS)
FP4	No	1,676
FP4	Yes	3,352
FP8	No	838
FP8	Yes	1,676
FP16	No	419
FP16	Yes	838
INT8	No	838
INT8	Yes	1,676

Source5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3, dense and with sparsity. FP4 uses FP32 accumulate (1676 and 3352 AI TOPS). FP8 and FP16 use FP16 accumulate (838 and 1676, 419 and 838). FP8 and FP16 with FP32 accumulate are half as high. INT8 is 838 and 1676.

Clocks

3 of 5 differ

Base clockiLowest rated clock under load that the card maker states for this card in MHz. NVIDIA's base clock in GHz is a chip value, and a figure such as 2.33 GHz gives no exact MHz value, so it is not converted. A row labelled only "Clock Speed" next to a boost clock row, as on PNY, is the base clock. On an NVIDIA card, a row labelled Graphics Clock next to a Boost Clock row, as on Palit, is the base clock too. A retail or distributor feed that repeats NVIDIA's reference base clock does not count. A card maker's own page that states the reference base clock for a card at reference clocks counts.

Not available

2,017MHz2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Base Clock 2017 MHz, listed next to Boost Clock 2407 MHz on the Gainward sheet for this card. It is the reference base clock of the card at reference clocks. NVIDIA writes 2.01 GHz.

Game clockiAMD Game Clock or Intel Graphics Clock of this card. Both are a typical clock in games, below the peak boost. On an Intel card, a card maker figure labelled Graphics Clock or Engine Clock is this clock, also with "up to". A figure the card maker labels Boost Clock stays a boost clock.

Not available

Not available

Boost clockiRated boost clock of this card out of the box, e.g. ASUS "Default mode" or MSI "Boost". Not a measured clock, the OC mode clock or another card's rating. AMD's boost clock is a maximum burst clock. NVIDIA's is its rated boost clock. Compare within one chip maker only. When the card ships in its OC BIOS position, as the PowerColor Hellhound does, that BIOS clock is stored here and the OC mode field stays empty. The other BIOS clock goes in the source note.

2,580MHz2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Engine Clock: Default mode 2580 MHz (Boost clock). ComputerBase also lists 2580 MHz for the Performance BIOS.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026Spec table: GPU average 2580 MHz in the Performance BIOS, 173 MHz above the Founders Edition.

2,407MHz1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026GPU Clockspeed 2407 MHz (Boost). This is also NVIDIA's reference boost clock, so the card runs at reference clocks.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Boost Clock 2407 MHz.

Boost clock in OC modeiBoost clock the card maker states for its OC mode, set in its software or with a BIOS switch, e.g. ASUS "OC mode" or MSI "Extreme Performance".

2,610MHz2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Engine Clock: OC mode 2610 MHz.

Not available

Reference boost clockiThe chip maker's boost clock for this GPU. It shows how far the card is factory overclocked.

2,407MHz13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: GPU boost clock 2407 MHz.

2,407MHz5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: GPU Boost Clock 2407 MHz.

Memory

0 of 5 differ

VRAMiGraphics memory on the card. A card with another memory size is another product.

32GB2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 202612Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

32GB1Maker product pagegainward.com/main/vgapro.phpRead 15 October 20262Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026DRAM Amount 32 GB.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Standard Memory Config 32 GB GDDR7.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 32 GB GDDR7.

VRAM type

GDDR72Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 202612Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

GDDR71Maker product pagegainward.com/main/vgapro.phpRead 15 October 20262Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026DRAM Type 512 bits GDDR7.

Memory bus width

512bits2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 202612Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

512bits1Maker product pagegainward.com/main/vgapro.phpRead 15 October 20262Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026DRAM Type row: 512 bits.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Memory Interface Width 512-bit.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 512-bit.

Memory speediEffective data rate per pin, e.g. 28 for GDDR7 at 28 Gbps. A memory clock published as 28000 MHz effective is 28 Gbps.

28Gbps2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Memory Speed 28 Gbps.13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026

28Gbps1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Memory Clockspeed 14000Mhz (28Gbps).5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: memory clock (data rate) 28 Gbps.

Memory bandwidthiPeak bandwidth between the GPU and its VRAM, as published. Effective bandwidth figures that include the cache do not count.

1,792GB/s13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: 1792 GB/s at 28 Gbps on a 512-bit interface.

1,792GB/s1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Bandwidth 1792 GB/s.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026DRAM Bandwidth 1792 GB/s.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 1792 GB/sec.

Connectivity

3 of 12 differ

PCIe generationiHighest PCIe generation the card supports. In an older slot it runs at that slot's generation.

52Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Bus Standard PCI Express 5.0.12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

51Maker product pagegainward.com/main/vgapro.phpRead 15 October 20262Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Key features: PCI Express Gen 5.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026PCI Express Gen 5: Yes.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: PCI Express Interface Gen 5.

PCIe lanesiElectrical lanes the card uses. Many 8-lane cards have a full-length x16 connector. In a PCIe 4.0 slot an 8-lane card has half the link bandwidth of a 16-lane card.

1614Owner's manualnvidia.com/content/geforce-gtx/geforce-rtx-5090-user-guide-r2.pdfRead 16 October 2026Quick start guide of the RTX 5090 Founders Edition: install the card in a PCI Express x16 slot. This is the GB202 link. ASUS lists PCI Express 5.0 only and gives no lane count for its card.

162Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Minimum system requirements: one tri-width x16 graphics slot.

Display outputsiPhysical video connectors on the card, one row per type and version. USB-C is a USB Type-C port that carries video.

AASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition

Type	Version	Count	Max bandwidth (Gbps)
HDMI	2.1b	2	Not available
DisplayPort	2.1b UHBR20	3	80

Source2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Native HDMI 2.1b x2 and native DisplayPort 2.1b x3. The UHBR20 class and the 80 Gbps link rate come from the NVIDIA RTX 5090 page footnote 2 and ComputerBase.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026Spec table: 3 x DisplayPort 2.1 UHBR20 and 2 x HDMI 2.1.12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026Standard connectors 3x DisplayPort and 1x HDMI on the Founders Edition. Footnote 2: DisplayPort 2.1b with UHBR20. Footnote 3: HDMI 2.1b. The second HDMI port is ASUS's.

BGainward GeForce RTX 5090 Phantom

Type	Version	Count	Max bandwidth (Gbps)
HDMI	2.1b	1	Not available
DisplayPort	2.1b UHBR20	3	80

Source1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Connectivity: DP 2.1b x 3 / HDMI 2.1b x 1. The UHBR20 class and the 80 Gbps link rate are on the Gainward datasheet.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026OUTPUT: HDMI 2.1b x 1 and DP 2.1b x 3. Key features: DisplayPort 2.1b with UHBR20 (80 Gbps).4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Footnote 2: DisplayPort 2.1b with UHBR20. Footnote 3: HDMI 2.1b.

Display outputs in totaliPhysical video connectors on the card.

5=CalculatedFrom Display outputs

4=CalculatedFrom Display outputs

HDMI ports

2=CalculatedFrom Display outputs

1=CalculatedFrom Display outputs

DisplayPort ports

3=CalculatedFrom Display outputs

3=CalculatedFrom Display outputs

Highest HDMI version

2.1b=CalculatedFrom Display outputs

2.1b=CalculatedFrom Display outputs

Highest DisplayPort version

2.1b UHBR20=CalculatedFrom Display outputs

2.1b UHBR20=CalculatedFrom Display outputs

Fastest DisplayPort linkiHighest stated DisplayPort link rate on the card.

80Gbps=CalculatedFrom Display outputs

80Gbps=CalculatedFrom Display outputs

Max displaysiDisplays the card drives at the same time.

42Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Maximum Display Support 4, for simultaneous displays.12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026Multi monitor: up to 4 displays.

44Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Multi Monitor: up to 4. This is a chip figure and the Gainward pages do not state one.

Max output resolutioniHighest stated output resolution and its refresh rate at that resolution. Do not combine a resolution and a refresh rate from different modes. DSC and port conditions belong in the source note. When the card maker states only the resolution, take the refresh rate at that resolution from the chip maker. When two ports differ, store the highest mode and name the port in the source note.

Resolution7680 × 4320 pxRefresh rate165 Hz2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Digital Max Resolution 7680 x 4320. ASUS states no refresh rate. The 165 Hz is NVIDIA's figure for 8K over DisplayPort 2.1b with DSC.12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026Maximum digital resolution: 4K at 480 Hz or 8K at 165 Hz with DSC.

Resolution7680 × 4320 pxRefresh rate165 Hz2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026DP 2.1b x 3: 7680 x 4320 at 165 Hz. HDMI 2.1b x 1: 7680 x 4320 at 120 Hz. Key features: DisplayPort 2.1b with UHBR20 gives up to 4K 480 Hz or 8K 165 Hz with DSC. The DisplayPort mode is the highest and is stored.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Footnotes: DisplayPort 2.1b with UHBR20 gives up to 8K at 165 Hz with DSC.

HDCP version

2.32Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026HDCP Support Yes (2.3).12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

2.32Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Key features: HDCP 2.3.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026HDCP 2.3.

Video engine

0 of 4 differ

Video encodersiHardware encode engines, e.g. 3 for "3x NVENC". Intel multi-format codec engines both encode and decode and count here and in video decoders. AMD publishes no engine counts. Leave it empty until an AMD document gives them.

312Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 20263x ninth-generation NVENC.

34Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026NVIDIA Encoder (NVENC): 3x Ninth Generation.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 3 x NVENC (9th Gen).

Video decodersiHardware decode engines, e.g. 2 for "2x NVDEC". AMD publishes no engine counts. Leave it empty until an AMD document gives them.

212Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 20262x sixth-generation NVDEC.

24Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026NVIDIA Decoder (NVDEC): 2x Sixth Generation.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: 2 x NVDEC (6th Gen).

Hardware video encodeiCodecs the maker states the GPU encodes in hardware.

H.264, H.265 (HEVC), AV116Maker product pagedeveloper.nvidia.com/video-encode-decode-support-matrixRead 16 October 2026GeForce RTX 5090, ninth-generation NVENC: H.264, H.265 and AV1 encode.

H.264, H.265 (HEVC), AV16Maker product pagedeveloper.nvidia.com/video-encode-decode-support-matrixRead 15 October 2026GeForce RTX 5090 row: H.264, H.265 (HEVC) and AV1 encode are marked YES.

Hardware video decodeiCodecs the maker states the GPU decodes in hardware.

H.264, H.265 (HEVC), VP9, AV116Maker product pagedeveloper.nvidia.com/video-encode-decode-support-matrixRead 16 October 2026GeForce RTX 5090, sixth-generation NVDEC: H.264, H.265, VP9 and AV1 decode. The table also lists older codecs.

H.264, H.265 (HEVC), VP9, AV16Maker product pagedeveloper.nvidia.com/video-encode-decode-support-matrixRead 15 October 2026GeForce RTX 5090 row: H.264, H.265, VP9 and AV1 decode are marked YES. The table has no VVC column.

Graphics features

0 of 5 differ

DirectXiAs published, e.g. "12 Ultimate".

12 Ultimate12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

12 Ultimate2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Key features: Microsoft DirectX 12 Ultimate.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Microsoft DirectX 12 Ultimate: Yes.

VulkaniAs published. It can rise with drivers.

1.412Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026Vulkan 1.4 and OpenGL 4.6 supported.

1.42Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Key features: Vulkan 1.4, OpenGL 4.6.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Vulkan 1.4, OpenGL 4.6: Yes.

OpenGLiAs published.

4.62Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026OpenGL 4.6.12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026Vulkan 1.4 and OpenGL 4.6 supported.

4.62Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Key features: Vulkan 1.4, OpenGL 4.6.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Vulkan 1.4, OpenGL 4.6: Yes.

Upscaling technologiesiThe maker's upscaling names with version, e.g. "DLSS 4", "FSR 4", "XeSS 2". Game support varies. A bundle name such as FSR Redstone is not an upscaler name, so its upscaler is written with its version, such as FSR 4. When the card maker and the chip maker write different versions, the chip maker's spec table wins. When the chip maker names no version, as NVIDIA writes DLSS for RTX 30 cards, the name is stored without one.

DLSS 41Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026NVIDIA DLSS 4 with Multi Frame Generation.12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026

DLSS 41Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026NVIDIA DLSS 4 with Multi Frame Generation.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026NVIDIA DLSS row: DLSS 4, Super Resolution, DLAA, Ray Reconstruction, Frame Generation and Multi Frame Generation.

Frame generationiThe maker's frame generation names, e.g. "DLSS Multi Frame Generation", "FSR Frame Generation", "AMD Fluid Motion Frames 2". Driver-level features count. Game support varies. Chip-level lists are copied the same way into every card with that GPU. Versions are written with the major number only, so AMD Fluid Motion Frames 2.1 is AMD Fluid Motion Frames 2.

DLSS Frame Generation, DLSS Multi Frame Generation1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026NVIDIA DLSS 4 with Multi Frame Generation.12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026DLSS 4 lists Frame Generation and Multi Frame Generation.

DLSS Frame Generation, DLSS Multi Frame Generation1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026NVIDIA DLSS 4 with Multi Frame Generation.4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026The same DLSS row lists Frame Generation and Multi Frame Generation.

Power

1 of 4 differ

Board poweriDefault board power or power limit of this card. Use the card maker's figure first: NVIDIA Total Graphics Power, AMD Total or Typical Board Power, Intel TBP. A row on the card maker's own page counts under any label, such as Power Consumption or TDP. When the card maker states none, a reviewer's reading of the default power limit counts, and the source note names the reader and the tool. Retail feed fields such as "Power consumption (typical)" do not count. AMD's Typical Board Power and the power limit can differ. When both are known, store the default-mode power limit. The reference figure is not proof of a partner card's power. Other BIOS modes go in the source note. A reviewer who only relays a maker figure has not read the power limit.

600W9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026Spec table: standard TDP 600 W. The text says 600 W is the factory limit and the maximum, and it can be lowered by 33 percent to 400 W. ASUS states no board power, so this is the reviewer's reading. The reviewer names no tool.

575W2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026TGP 575 W on the card's own datasheet.

Reference board poweriThe chip maker's board power for this GPU. It is a chip spec and repeats in every card with this GPU.

575W12Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 16 October 2026Total Graphics Power 575 W for the RTX 5090.13Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 16 October 2026Table 3: TGP 575 W.

575W4Maker product pagenvidia.com/en-us/geforce/graphics-cards/50-series/rtx-5090Read 15 October 2026Total Graphics Power 575 W.5Maker spec sheet (PDF)images.nvidia.com/aem-dam/Solutions/geforce/blackwell/nvidia-rtx-blackwell-gpu-architecture.pdfRead 15 October 2026Table 3: TGP 575 W.

PSU wattage (card maker)iThe PSU wattage the card maker lists for a full system with this card, whether it calls it Recommended, Minimum or Required. NVIDIA calls it Required System Power, AMD Minimum PSU Recommendation. When a maker lists both a recommendation and a lower minimum, store the recommendation and note the minimum. Makers differ for the same GPU, so compare cards of one maker only.

1,000W2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Recommended PSU 1000 W. ASUS says the figure assumes a fully overclocked GPU and CPU.

1,000W2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Minimum system requirements: recommend 1000 W or greater system power supply in ATX 3.X specification.

Power connectoriSupplementary power inputs on the card. 16-pin with no revision means the maker does not say 12V-2x6 or 12VHPWR. Use 12V-2x6 or 12VHPWR only when the card maker's page or manual names it. Do not infer it from the GPU generation or from a reviewer's or retailer's wording.

16-pin (revision not stated)2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Power Connectors: 1 x 16-pin. ASUS names no 12V-2x6 revision on the spec page, so the 16-pin option is used. The feature text calls the cable 12VHPWR, while ComputerBase writes 12V-2x6.

16-pin (revision not stated)1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Power Connector: 16-pin x1. The page does not name 12V-2x6 or 12VHPWR. The datasheet's system requirements line says '16-pin PCIe 12VHPWR or four 8-pin', which is a power supply requirement and not a name for the card input, so the plain 16-pin option is stored.

Cooling

1 of 5 differ

Cooler typeiOpen air covers axial fans that blow onto the heatsink, including flow-through designs. All-in-one liquid is a card with an attached radiator. A water block needs a custom loop. Passive means no fan, and the fan count is 0.

Open air1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026Quad-fan design with four axial tech fans, a patented vapor chamber, more fin density and a phase-change GPU thermal pad. ComputerBase says the fourth fan sits in the backplate and pulls air through the heatsink.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026The rear fan pulls air through the heatsink, a flow-through design with fans blowing onto the heatsink.

Open air1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Features: Cyclone Fan blades, vapor chamber, composite heat pipes and diffuser fins on a 3.5 slot fan cooler. The fans blow onto the heatsink.

FansiFans mounted on the card. Radiator fans of an all-in-one cooler are not counted.

41Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026Quad-Fan Force: a four-fan design. Four axial tech fans.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026Spec table: 4 x 105 mm axial fans, three on the GPU side and one rear fan that pulls air through the heatsink.

312Spec databasegeizhals.de/gainward-geforce-rtx-5090-phantom-4878-ne75090019r5-gb2020p-a3382613.htmlRead 15 October 2026Cooling: 3x axial fans (100 mm) with a 0 dB zero fan mode.13Retailer pagearvutitark.ee/en/pc-components/graphics-cards-vga/vga-gainward-rtx5090-32gb-phantom-1440574Read 15 October 2026Description: a triple fan design with vapor chamber technology and a Zero RPM fan. The shop was out of stock on 2026-10-15.

Radiator sizeiLiquid-cooled cards only. The nominal size class from the fan positions, e.g. 240 or 360.

Not available

Not available

Fan stop at low loadiThe fans stop below a temperature or load threshold, e.g. ASUS 0dB or MSI Zero Frozr. A maker's semi-passive or 0dB text counts. A threshold goes in the source note.

Yes8Spec databasegeizhals.de/asus-rog-astral-geforce-rtx-5090-oc-a3382344.htmlRead 16 October 2026Fans: 4x axial fans with a 0dB zero-fan mode.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026Page 2, Zuverlaessiger Fan Stop: the fan stop works reliably in the test system, because of the large cooler.10Measurementcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096/seite-2Read 16 October 2026The fan stop paragraph says the fans stay off at idle in the GPU test system.11Reviewguru3d.com/review/review-asus-rog-geforce-rtx-5090-astral-oc-gaming/page-8Read 16 October 2026Page 8: the card turns down the fans in passive mode at desktop idle and makes no noise.

Yes1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026ZERO RPM FAN: the fans stay idle during light tasks and run only when necessary. No temperature threshold is stated.12Spec databasegeizhals.de/gainward-geforce-rtx-5090-phantom-4878-ne75090019r5-gb2020p-a3382613.htmlRead 15 October 2026Cooling: 0 dB zero fan mode.

Dual BIOSiA switch on the card selects between two factory firmware profiles, e.g. Performance and Quiet.

Yes1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026Dual BIOS: Performance mode and Quiet mode with the same power target.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026A BIOS dip switch selects Performance, the factory default, or Quiet. The modes differ in the GPU temperature target and so in fan control.

Yes1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Dual BIOS: P-Performance Mode and S-Silent Mode, selected with a switch on the back side of the card.12Spec databasegeizhals.de/gainward-geforce-rtx-5090-phantom-4878-ne75090019r5-gb2020p-a3382613.htmlRead 15 October 2026Features: dual BIOS switch.

Dimensions and weight

5 of 8 differ

LengthiCard length along the PCIe connector, from the bracket to the far end. Makers write it as L. Makers write L x W x H. W is the card height and H is the thickness. NVIDIA calls the height Width. Retail feeds relabel the sides as Height, Width or Depth, so decide by size: length is the longest side and thickness the shortest. When the maker lists sizes with and without the bracket, store the size with the bracket.

357.6mm2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Dimensions 357.6 x 149.3 x 76 mm. ASUS lists length, height and thickness in this order and does not say whether the bracket is included.

331.9mm1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Product Size 331.9 x 145.6 x 69.9 mm. The page does not say whether the bracket or the power plug is included.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026DIMENSIONS Board: 331.9 x 145.6 x 69.9 mm. The sheet does not say whether the bracket or the power plug is included.

HeightiFrom the PCIe connector edge to the top of the card. The source note says when the bracket or the power plug is included. Makers write L x W x H. W is the card height and H is the thickness. NVIDIA calls the height Width. Retail feeds relabel the sides as Height, Width or Depth, so decide by size: length is the longest side and thickness the shortest. When the maker lists sizes with and without the bracket, store the size with the bracket.

149.3mm2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Second value of 357.6 x 149.3 x 76 mm.

145.6mm1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Second value of 331.9 x 145.6 x 69.9 mm.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Board: second value, 145.6 mm.

ThicknessiFrom the bracket face to the back of the cooler. Makers often write it as H. Makers write L x W x H. W is the card height and H is the thickness. NVIDIA calls the height Width. Retail feeds relabel the sides as Height, Width or Depth, so decide by size: length is the longest side and thickness the shortest. When the maker lists sizes with and without the bracket, store the size with the bracket.

76mm2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Third value of 357.6 x 149.3 x 76 mm.

69.9mm1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Third value of 331.9 x 145.6 x 69.9 mm.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026Board: third value, 69.9 mm.

Slot widthiThickness in expansion-slot units as the card maker states it, e.g. 2.5 or 3.125. Not the number of slots the card covers in a case. Only a slot figure the card maker states. Do not compute it from the thickness. Retail feeds give different values for the same card. A slot figure in a row labelled Height, as on Palit, counts.

3.8slots2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Slot: 3.8 Slot.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026Spec table: ROG Astral, 3.8 slot.

3.5slots1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026Cooling: 3.5 Slot Fan Cooler.2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026DIMENSIONS: Cooler 3.5 slots, Bracket 3 slots. The cooler figure is stored.

Low profileiThe maker states the card fits low-profile slots, usually with a half-height bracket in the box. False when a data sheet says full-height bracket (FH/FL or FH/HL). Left out otherwise.

No8Spec databasegeizhals.de/asus-rog-astral-geforce-rtx-5090-oc-a3382344.htmlRead 16 October 2026Slot bracket: full height.

Not available

NVIDIA SFF-ReadyiThe card is on NVIDIA's SFF-Ready Enthusiast GeForce list. Only GeForce cards can qualify. For a GPU class the list covers, the list decides, and a card missing from it is false. Below the 70 class, which the list does not cover, the card maker's own SFF-Ready claim counts. A retail title does not.

No17Certification listnvidia.com/en-us/geforce/news/small-form-factor-sff-readyRead 16 October 2026The list names two ASUS ProArt RTX 5090 cards and the Founders Edition for the RTX 5090. No ROG Astral card is on it, so false.

No8Certification listnvidia.com/en-us/geforce/news/small-form-factor-sff-readyRead 15 October 2026The Enthusiast GeForce list covers the RTX 5090 class. It names the Founders Edition and two ASUS ProArt RTX 5090 cards and lists Gainward only for RTX 50 and 40 Python III cards below the 90 class. No Gainward RTX 5090 is on it, so false is stored. The card is 331.9 mm long and 3.5 slots, above the list limits.

WeightiThe card alone, without support bracket, adapter or packaging. A liquid-cooled card includes its attached radiator and tubes. A weight rounded to whole kilograms, as some retail and distributor feeds print it, is not stored. A colour edition can state its own weight, so it is per variant. A feed weight that does not say whether it is the card or the package is not stored.

Not available

Not available

Package weightiOne retail box with its contents. A weight rounded to whole kilograms in a retail or distributor feed is not stored. A feed weight that does not say whether it is the card or the package is not stored. A feed's gross weight is the package weight, and the same rounding rule applies.

Not available

Not available

Lighting and software

2 of 3 differ

RGB lightingiDecorative lighting with selectable colours. A white logo or a single fixed colour does not count.

Yes1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026Indirect Aura lighting: ARGB lighting allows for personalized setting.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026An RGB trim strip on the side.

Yes1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026ARGB Lighting: addressable RGB lets gamers customise each LED color. Auto Sync 2.0 uses a universal 5V ARGB connector to sync with the board's lighting.12Spec databasegeizhals.de/gainward-geforce-rtx-5090-phantom-4878-ne75090019r5-gb2020p-a3382613.htmlRead 15 October 2026Features: lighting (RGB).

Lighting synciSync standards the maker names, as a short name without a version, e.g. "ASUS Aura Sync", "MSI Mystic Light", "Gigabyte RGB Fusion". Leave it empty when the maker names only its own app. That goes in Software.

ASUS Aura Sync1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026Aura Sync with indirect ARGB lighting. The spec page row reads AURA SYNC ARGB.2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026AURA SYNC: ARGB.

Not available

SoftwareiThe card maker's tuning software, not the chip maker's driver.

ASUS GPU Tweak III1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026GPU Tweak III, the tuning utility, with OC mode and Silent mode toggles.2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Software: ASUS GPU Tweak III and MuseTree.

Gainward EXPERTool1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026The ARGB text says lighting effects are set with the GAINWARD Expertool Utility. The download tab lists ExperTool.3Owner's manualgainward.com/support/4/91_M_GW22D.pdfRead 15 October 2026Software Installation step 2: install Gainward EXPERTool to adjust fan settings, lighting effects and performance tuning.

Measured performance

1 of 6 differ

GPU clock while gaming (measured)iAverage GPU clock a reviewer logged in a game at the card's default settings, after warm-up. Game, resolution and BIOS mode are in the source note.

Not available

Not available

3DMark Time Spy graphicsiGraphics score, not the overall score. Measured by a reviewer, not claimed by the maker. A score the review does not label as graphics is left out.

Not available

Not available

3DMark Steel NomadiMeasured by a reviewer, not claimed by the maker.

Not available

Not available

3DMark Port RoyaliMeasured by a reviewer, not claimed by the maker.

Not available

Not available

3DMark Speed WayiMeasured by a reviewer, not claimed by the maker.

Not available

Not available

Game frame ratesiReviewer frame rates for this card. The test CPU, memory and driver, frame generation, and whether the card ran at factory or reference clocks are in the source note.

AASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition

Game	Width (px)	Height (px)	Upscaling	Ray tracing	Average FPS	1 % low FPS
Horizon Forbidden West	3840	2160	Off	Not available	113.4	90.2
Star Wars Outlaws	3840	2160	DLSS Quality	Yes	70.9	53.9

Source10Measurementcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096/seite-2Read 16 October 2026Both rows are the Quiet BIOS at 3840 x 2160 in a Fractal Design Torrent case on a Ryzen 7 9800X3D. Horizon Forbidden West with DLSS/FSR off: 113.4 average and 90.2 1 percent low. Star Wars Outlaws with DLSS/FSR Quality and ray tracing: 70.9 average and 53.9 1 percent low. The Performance BIOS is not reported. No driver version is stated.

BGainward GeForce RTX 5090 Phantom

Not available

Measured noise and temperature

4 of 5 differ

Fan noise per loadiSound pressure a reviewer measured from the card. Profile is the BIOS mode or fan profile as the reviewer names it. Fixed fan-speed tests are not a load. Compare only at the same distance. A row needs a distance. Take it from the review or from the site's test-method page. Leave the row out when neither states it. A synthetic or render load, such as a 3DMark loop or FurMark, is max load. Sone values are not converted. When a review gives two distances for one test, the row is left out.

AASUS ROG Astral GeForce RTX 5090 32GB GDDR7 OC Edition

Profile	Load	Distance (cm)	Noise (dB(A))
Performance	Gaming	30	50
Quiet	Gaming	30	46

Source10Measurementcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096/seite-2Read 16 October 2026Metro Exodus at 3840 x 2160. 50.0 dB(A) in the Performance BIOS, the factory default, and 46.0 dB(A) in the Quiet BIOS. Measured 30 cm from the side of the card. The footnote on page 1 says values are taken after 30 minutes of 4K load at the full power target. Fans about 1895 rpm and 1695 rpm. The 28.0 dB(A) desktop figure is not stored.

BGainward GeForce RTX 5090 Phantom

Not available

Fan noise while gamingiLoudest gaming row, so the loudest BIOS mode tested. Compare only at the same distance.

50dB(A)=CalculatedFrom Fan noise per load

Not available

GPU temperature while gamingiGPU core sensor after warm-up in a game, at default fan settings. Not the hot spot. A synthetic stress test does not count. The average or plateau reading after the card has warmed up, never the peak. A run of a few minutes does not count. The run length goes in the source note.

67°C10Measurementcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096/seite-2Read 16 October 2026Temperature table Last (Metro Exodus, 3840 x 2160), GPU edge 67 C in the Performance BIOS (71 C in the Quiet BIOS). Fractal Design Torrent case, Ryzen 7 9800X3D. The table states no run length. The page 1 footnote gives 30 minutes of 4K load for the fan speed row. No ambient temperature is stated.

Not available

Hot spot temperature while gamingiHottest sensor on the GPU die under the same game load. The average or plateau reading after the card has warmed up, never the peak. A run of a few minutes does not count. The run length goes in the source note.

Not available

Not available

Memory temperature while gamingiVRAM sensor under the same game load. The average or plateau reading after the card has warmed up, never the peak. A run of a few minutes does not count. The run length goes in the source note.

80°C10Measurementcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096/seite-2Read 16 October 2026Same table: GDDR memory 80 C in the Performance BIOS (84 C in the Quiet BIOS). No hot spot value is given.

Not available

Measured power

2 of 2 differ

Card power at idle (measured)iPower of the card alone at the desktop with one display. A hardware capture of slot and cable power comes first, a software reading of total board power second. The method is in the source note. Wall power does not count.

31W10Measurementcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096/seite-2Read 16 October 2026Power table, Windows desktop at 3840 x 2160 and 60 Hz, complete idle: 31 W. Same external tool.

Not available

GPU power while gaming (measured)iAverage power of the card alone in a game at default settings. Same method rule as idle power. A mix of games, synthetic loads or stress tests does not count. Total board power, such as PCGH's Boardpower, not the GPU chip or Graphics Power reading alone.

632W10Measurementcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096/seite-2Read 16 October 2026Power table, gaming, Metro Exodus at 3840 x 2160: 632 W measured with ComputerBase's external tool, 600 W in the card's telemetry. The slot carries about 11 W and over 620 W flows through the 12V-2x6 plug, so it is a card-level capture. The page does not name the tool.

Not available

In the box

2 of 3 differ

In the box

1 x Speedsetup Manual, 1 x ROG Graphics Card Holder, 1 x ROG Velcro Hook & Loop, 1 x ROG Magnet, 1 x ROG Graphics Card Keycap, 1 x ROG PCB Ruler, 1 x Thank You Card, 1 x Adapter Cable (1 to 4)2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026Accessories list on the spec page, verbatim.

Power Cable, VGA Holder, Holder Extender2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026ACCESSORIES: Power Cable, VGA Holder, Holder Extender.

Power adapter cable includediAn adapter from PCIe 8-pin cables to the card's 16-pin input is in the box.

Yes2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 20261 x Adapter Cable (1 to 4). ComputerBase says the box holds a 4x8-pin to 12V-2x6 adapter.9Reviewcomputerbase.de/artikel/grafikkarten/asus-rog-geforce-rtx-5090-astral-test.91096Read 16 October 2026The box holds a 4x8-pin to 12V-2x6 adapter with shorter cables than the Founders Edition adapter.

Not available

Support bracket includediAn anti-sag holder or support bracket is in the box.

Yes2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 20261 x ROG Graphics Card Holder.

Yes2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026ACCESSORIES: VGA Holder and Holder Extender. Gainward's VGA Holder Installation Guide covers the holder.

Links

Not compared

Product page

rog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming1Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gamingRead 16 October 2026

www.gainward.com/main/vgapro.php1Maker product pagegainward.com/main/vgapro.phpRead 15 October 2026

Spec sheet

rog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/spec2Maker product pagerog.asus.com/graphics-cards/graphics-cards/rog-astral/rog-astral-rtx5090-o32g-gaming/specRead 16 October 2026

www.gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdf2Maker spec sheet (PDF)gainward.com/main/product/vga/pro/p01225/p01225_datasheet_129567a1dad803604.pdfRead 15 October 2026

Manual

www.asus.com/us/supportonly/rog-astral-rtx5090-o32g-gaming/helpdesk_manual4Owner's manualasus.com/us/supportonly/rog-astral-rtx5090-o32g-gaming/helpdesk_manualRead 16 October 2026ASUS support page for ROG-ASTRAL-RTX5090-O32G-GAMING with the quick start guide, the warranty card, the 16-pin plug guide and the GPU Tweak manual.

www.gainward.com/support/4/91_M_GW22D.pdf3Owner's manualgainward.com/support/4/91_M_GW22D.pdfRead 15 October 2026Graphics Card Installation Guide, version M-GW22D, 2025-10-03, from the Download tab of this card.

EPREL registration numberiId in the EU energy label database. Each size or model of a series has its own id, so it is per variant.

Not available

Not available

Warranty

1 of 1 differ

Manufacturer warranty (source market)iThe maker's warranty period for the exact SKU or configuration and market named in the source note. It applies only to that stated market, not every regional variant. Statutory consumer rights are excluded. The base term is stored. An extension that needs registration goes in the source note.

3years3Maker product pageeshop.asus.com/us/90yv0lw0-mvaa00-rog-astral-rtx5090-o32g-gaming.htmlRead 16 October 2026ASUS eShop USA: 3 year manufacturer warranty. The market is the United States.5Maker spec sheet (PDF)asus.com/support/images/upload/warranty/us_Graphic%20Card.pdfRead 16 October 2026ASUS graphics card warranty card: the warranty applies for 36 months from the date of purchase. It is a generic card for ASUS graphics cards.

Not available

Both are also in the API. Back to all graphics cards.
