Intel Celeron N4500

IntelLaptop CPU

Celeron N4500

Released January 2021.1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Launch Date Q1'21. Marketing Status: Launched. CNX Software dates the CES 2021 launch to 12 January 2021. Last checked 16 October 2026.

Cores
2
Max boost clock
2.8GHz
L3 cache
4MB
Socket or package
BGA1338

36 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

At a glance

All specs

SourceCalculated

General

Series
Celeron N Series1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Product Collection row reads Celeron N Series.
Model numbers
DC80697046099072Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/ordering.htmlRead 16 October 2026Ordering code DC8069704609907, shipping media Tray, stepping A1, spec code SRKH0. ARK lists no boxed product, so the chip is sold in tray form only.
GTIN / EAN
Not available
Announced
January 20215Press articlecnx-software.com/2021/01/12/intel-jasper-lake-n-series-launched-with-6w-celeron-and-10w-pentium-silver-processorsRead 16 October 2026CNX Software, 12 January 2021: Intel announced the Jasper Lake N-series at CES 2021 and the six parts appeared on ARK. The Celeron N4500 is listed with 2 cores, 1.1 GHz base, 2.8 GHz boost and 6 W.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Marketing Status: Launched. The ordering tab shows the tray code and spec code and no status label.6Press articledealnews.com/products/Acer/Acer-Chromebook-Celeron-N4500-15-6-Laptop/495604.htmlRead 16 October 2026Dealnews: Best Buy sold the Acer Chromebook 315 (CB315-4H-C0BR) with the Celeron N4500 for $129 until 20 March 2026. The deal has expired, so this shows the chip in new laptops in 2026 but not live stock today.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Vertical Segment row reads Mobile.
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Instruction Set: 64-bit. Intel's 64-bit processors are x86-64.
Codename
Jasper Lake1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Code Name row reads Jasper Lake.
CPU process (as published)
10 nm1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Lithography row: 10 nm. Intel's first 10 nm process, not the later one it renamed Intel 7.
CPU process node
10nm1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Lithography 10 nm.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Instruction Set Extensions lists Intel SSE4.2 only.

Cores and clocks

Core configuration
CountCoreBase clock (GHz)Max clock (GHz)
2Tremont1.12.8
Source1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Total Cores 2, Processor Base Frequency 1.10 GHz and Burst Frequency 2.80 GHz. ARK names no core roles and no core architecture. The datasheet names the cores.3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Section 1.3 Features Supported: up to four Tremont Atom Cores. The N4500 has two. Core names the architecture only. The SKU map lists the 1.1 GHz HFM and 2.8 GHz burst clocks.
Cores
2
Cores labelled performance
Not available
Cores labelled efficiency
Not available
Threads
21Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Total Threads 2. Intel Hyper-Threading Technology: No.
Max boost clock
2.8GHz1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Burst Frequency 2.80 GHz. ARK has no Max Turbo Frequency row. Burst is Intel's turbo clock on this chip. Intel Turbo Boost Technology is listed as not supported.
Unlocked for overclocking
No4Maker product pageintel.com/content/www/us/en/support/articles/000038213/processors/intel-core-processors.htmlRead 16 October 2026Intel: overclocking is supported only for unlocked Intel Core processors, identified by a K or X in the processor number. The N4500 is a Celeron and ARK lists no overclocking feature. Stored as locked.

Cache

L2 cache
1.5MB3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Section 2.2.2: the L2 cache is 1.5 MB, shared by the cores in the module. Section 1.3 lists L2 1.5 MB and L3 4 MB. The L2 does not shrink on the two-core part.7Spec databasetechnical.city/en/cpu/Celeron-N4500Read 16 October 2026Lists L2 1.5 MB shared and L3 4 MB shared, the same as the datasheet.
L3 cache
4MB1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 20264 MB Intel Smart Cache. The datasheet says the 4 MB is the last level cache, also called third level cache.3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Section 2.2.1: the size of the LLC is 4 MB. Section 1.3 lists L3 4 MB.7Spec databasetechnical.city/en/cpu/Celeron-N4500Read 16 October 2026Lists L3 4 MB shared.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026AMD technology. ARK lists only the 4 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
6W1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026TDP 6 W. Scenario Design Power (SDP) is 4.8 W and is not stored. ARK has no configurable TDP rows and no maximum turbo power row.
Max turbo power
Not available
Configurable power range
Not available
Max operating temperature
105°C1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026TJUNCTION 105 C.

Memory

Memory support
Memory typeModule typeMax speed (MT/s)
DDR4SO-DIMM2,933
LPDDR4XSoldered2,933
Source1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Memory Types: DDR4 and LPDDR4x. Maximum Memory Speed 2933 MHz, which is 2933 MT/s in the datasheet. ARK names no module type or configuration.3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Table 24 pairs DDR4 with SoDIMM and LPDDR4/4x with memory down. Table 22: maximum data rate 2933 MT/s for both. Memory-down is stored as soldered.
Max memory speed (official)
2,933MT/s
Memory channels
21Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Max # of Memory Channels: 2.3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Table 22: LPDDR4x as 2 x 32 or 4 x 32 bits and DDR4 as 1 x 64 or 2 x 64 bits. A full build has two 64-bit channels.
Memory bandwidth (claimed)
Not available
Max memory
16GB1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Max Memory Size (dependent on memory type): 16 GB.
ECC memory support
No1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026ECC Memory Supported: No.

Platform

Socket or package
BGA13381Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Sockets Supported: FCBGA1338. Stored without the FC prefix.
Compatible chipsets
Not available
CPU PCIe lanes
Not available
CPU PCIe lanes in total
Not available
Highest PCIe generation
Not available
Native USB ports
Not available
Native USB4 or Thunderbolt
Not available

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026GPU Name: Intel UHD Graphics.
Integrated GPU
Intel UHD Graphics1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026GPU Name: Intel UHD Graphics. Execution Units 16. ARK states no Xe-core count and this is Gen11 graphics, so the GPU core count is left out.
GPU cores
Not available
Max GPU clock
750MHz1Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026Graphics Burst Frequency 750 MHz. Graphics Base Frequency 350 MHz.
Max displays
31Maker product pageintel.com/content/www/us/en/products/sku/212326/intel-celeron-processor-n4500-4m-cache-up-to-2-80-ghz/specifications.htmlRead 16 October 2026# of Displays Supported: 3.3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026The display chapter lists three display interfaces, DDI 0, DDI 1 and DDI 2, which matches ARK.
DisplayPort version
1.4a3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Features Supported table: DP 1.4a at 8.1 Gbps. HBR3 needs DP alternate mode over Type-C or a retimer, and HBR2 is native on a DP connector. eDP is 1.4b.
HDMI version
2.0b3Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Features Supported table: HDMI 2.0b at 5.94 Gbps, with platform level shifters above HD resolution.
Hardware video encode
H.264, H.265 (HEVC), VP93Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Table 28, Hardware Accelerated Video Decode and Encode: H.265/HEVC, VP9 and H.264 all have an encode level. AV1 is not listed.
Hardware video decode
H.264, H.265 (HEVC), VP93Maker spec sheet (PDF)cdrdv2-public.intel.com/633935/633935-006.pdfRead 16 October 2026Table 28: H.265/HEVC, VP9 and H.264 decode up to 4Kp60. AV1 is not listed.

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available
