PC parts / CPUs

Intel Processor N100

IntelLaptop CPU

Processor N100

Released January 2023.1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Launch Date Q1'23. Marketing Status: Launched. CNX Software reports the announcement at CES on 3 January 2023. Last checked 16 October 2026.

Cores
4
Max boost clock
3.4GHz
L3 cache
6MB
Socket or package
BGA1264

40 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

At a glance

All specs

SourceCalculated

General

Series
Intel Processor N-series1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Product Collection row reads Intel Processor N-series.
Model numbers
FJ80715047418232Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/ordering.htmlRead 16 October 2026Ordering code FJ8071504741823, shipping media Tray, stepping N0, spec code SRMDM. ARK lists no boxed product, so the chip is sold in tray form only.
GTIN / EAN
Not available
Announced
January 202310Press articlecnx-software.com/2023/01/03/meet-intel-processor-and-core-i3-n-series-alder-lake-n-series-processorsRead 16 October 2026CNX Software, 3 January 2023 (updated 4 January): Intel introduced the Alder Lake-N family with the Intel Processor and Core i3 N-series. The N100 is listed with 4 cores, up to 3.4 GHz turbo, 24 EUs and 6 W.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Marketing Status: Launched. Mini PCs with the N100 were still on sale in 2025 (see the CNX Software Yxk S15 Ultra article).11Press articlecnx-software.com/2025/06/27/yxk-s15-uitra-a-thin-fanless-mini-pc-with-intel-n100-16gb-ram-512gb-ssd-selling-for-119-99Read 16 October 2026CNX Software, 27 June 2025: a fanless mini PC with the N100 sold on Amazon for $119.99. Its spec list repeats 4 cores up to 3.4 GHz, 6 MB cache, 24 EU graphics at 750 MHz and 6 W.
Predecessor
Not available
Successor
Intel Processor N1503Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/introductionRead 16 October 2026The same table puts the N150 (4 E-cores, 24 EUs, 3.6 GHz burst, graphics burst 1 GHz) next to the N100 (4 E-cores, 24 EUs, 3.4 GHz burst, graphics burst 0.75 GHz). The N150 is the Twin Lake refresh of the N100.
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Vertical Segment row reads Mobile. Intel's N-series is also used in mini PCs, but ARK files it as Mobile.
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Instruction Set: 64-bit. Intel's 64-bit processors are x86-64.
Codename
Alder Lake-N1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Code Name row reads Products formerly Alder Lake-N.
CPU process (as published)
Intel 71Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Lithography row: Intel 7.
CPU process node
10nm1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Intel 7 is stored as 10 nm, the nm class of Intel 7. Intel prints no nm figure.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Instruction Set Extensions lists Intel SSE4.1, SSE4.2 and AVX2 only.

Cores and clocks

Core configuration
Core typeCountCoreBase clock (GHz)Max clock (GHz)
Efficiency4Gracemont0.83.4
Source3Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/introductionRead 16 October 2026SKUs Supported table, column N100: E-Cores 4, CPU HFM 0.8 GHz and CPU Max Burst Frequency 3.4 GHz. HFM is the high frequency mode, Intel's guaranteed base clock. The N100 has only efficient cores. ARK states no core-type rows and no base clock. Intel's N-series overview names the Gracemont microarchitecture.4Maker product pageintel.com/content/www/us/en/support/articles/000093479/processors.htmlRead 16 October 2026Intel's N-series overview describes the Gracemont microarchitecture on the Intel 7 process with up to eight efficient cores. It names no SKU, so the N100's own core count and clocks come from the ARK page and the datasheet.10Press articlecnx-software.com/2023/01/03/meet-intel-processor-and-core-i3-n-series-alder-lake-n-series-processorsRead 16 October 2026The article says the chips use the Gracemont efficiency cores from Alder Lake and no performance cores.
Cores
4
Cores labelled performance
0
Cores labelled efficiency
4
Threads
41Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Total Threads 4. Intel Hyper-Threading Technology: No.
Max boost clock
3.4GHz1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Max Turbo Frequency 3.40 GHz.
Unlocked for overclocking
No9Maker product pageintel.com/content/www/us/en/support/articles/000038213/processors/intel-core-processors.htmlRead 16 October 2026Intel: overclocking is supported only for unlocked Intel Core processors, identified by a K or X in the processor number. The N100 is an Intel Processor, not a Core processor, and ARK lists no overclocking feature. Stored as locked.

Cache

L2 cache
2MB5Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/ia-core-level-1-and-level-2-cachesRead 16 October 2026Datasheet cache hierarchy note: MLC (L2) 2 MB per 4 cores and LLC 6 MB. The N100 has one module of 4 cores, so its L2 is 2 MB.
L3 cache
6MB1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 20266 MB Intel Smart Cache. ARK has no Total L2 Cache row.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026AMD technology. ARK lists only the 6 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
6W1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026The row is labelled TDP and reads 6 W. ARK has no Maximum Turbo Power or configurable TDP row.
Max turbo power
25W3Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/introductionRead 16 October 2026SKUs Supported table, column N100: TDP (PL1)/PL2 6W/25W. The 25 W is the PL2 package power limit. ARK leaves it out.
Configurable power range
Not available
Max operating temperature
105°C1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026TJUNCTION and Max Operating Temperature both read 105 C.

Memory

Memory support
Memory typeModule typeMax speed (MT/s)
DDR4Not available3,200
DDR5Not available4,800
LPDDR5Soldered4,800
Source1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Memory Types: DDR4 3200 MT/s, DDR5 4800 MT/s and LPDDR5 4800 MT/s. ARK names no module type or configuration. The datasheet shows DDR4 and DDR5 for both SODIMM and memory-down use, so those two rows have no module type. LPDDR5 is memory-down only in the datasheet, so that row is soldered.8Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/ddr-support-matrixRead 16 October 2026DDR Support Matrix: DDR4 3200 MT/s, DDR5 4800 MT/s and LPDDR5 4800 MT/s. The module list shows SODIMM and memory-down for DDR4 and DDR5 and memory-down only for LPDDR5.
Max memory speed (official)
4,800MT/s
Memory channels
11Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Max # of Memory Channels: 1. The datasheet counts one DDR4 channel, two DDR5 channels or four LPDDR5 channels, which are all 64 bits in total.8Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/ddr-support-matrixRead 16 October 2026The memory controller supports up to four channels of LPDDR5, two channels of DDR5 or one channel of DDR4, which is one 64-bit channel in total.
Memory bandwidth (claimed)
Not available
Max memory
16GB1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Max Memory Size (dependent on memory type): 16 GB.
ECC memory support
No1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026ECC Memory Supported: No.

Platform

Socket or package
BGA12641Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Sockets Supported: FCBGA1264. Stored without the FC prefix. The datasheet names the package BGA1264, 24 x 35 mm.
Compatible chipsets
Not available
CPU PCIe lanes
Not available
CPU PCIe lanes in total
Not available
Highest PCIe generation
Not available
Native USB ports
Not available
Native USB4 or Thunderbolt
Not available

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026GPU Name: Intel UHD Graphics.
Integrated GPU
Intel UHD Graphics1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026GPU Name: Intel UHD Graphics. Execution Units 24. ARK states no Xe-core count, so the GPU core count is left out. A Beelink EQ12 review says HWiNFO shows 32 EUs, but Intel states 24.
GPU cores
Not available
Max GPU clock
750MHz1Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Graphics Max Dynamic Frequency 750 MHz.
Max displays
31Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026# of Displays Supported: 3.
DisplayPort version
1.41Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Graphics Output: eDP 1.4b, DP 1.4, HDMI 2.1, MIPI-DSI 1.3.
HDMI version
2.11Maker product pageintel.com/content/www/us/en/products/sku/231803/intel-processor-n100-6m-cache-up-to-3-40-ghz/specifications.htmlRead 16 October 2026Graphics Output: eDP 1.4b, DP 1.4, HDMI 2.1, MIPI-DSI 1.3.
Hardware video encode
H.264, H.265 (HEVC), VP96Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/hardware-accelerated-video-encodeRead 16 October 2026Xe supports full hardware video encoding for AVC, HEVC, VP9 and JPEG. There is no AV1 encode. The datasheet covers the whole N-series line. Its processor graphics device ID table lists the N100 with 24 EUs.
Hardware video decode
H.264, H.265 (HEVC), VP9, AV17Maker product pageedc.intel.com/content/www/us/en/design/products/platforms/processor-and-core-i3-n-series-datasheet-volume-1-of-2/hardware-accelerated-video-decodeRead 16 October 2026Xe supports full hardware video decoding for AVC, HEVC, VP9, JPEG and AV1. The datasheet covers the whole N-series line. ServeTheHome also notes the new AV1 decode engine in Alder Lake-N.

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Sources

We read 11 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 16 October 2026Backs 27 fields
  2. Read 16 October 2026Backs 1 field
  3. Read 16 October 2026Backs 4 fields
  4. Read 16 October 2026Backs 1 field
  5. Read 16 October 2026Backs 1 field
  6. Read 16 October 2026Backs 1 field
  7. Read 16 October 2026Backs 1 field
  8. Read 16 October 2026Backs 2 fields
  9. Read 16 October 2026Backs 1 field
  10. Read 16 October 2026Backs 3 fields
  11. Read 16 October 2026Backs 1 field

See a wrong value? Tell us and name the field.
