Intel Core i7-14650HX

IntelLaptop CPU

Core i7-14650HX

Released January 2024.5Press releaseintel.com/content/www/us/en/newsroom/news/ces-2024-client-processor-news.htmlRead 15 October 2026ARK Launch Date Q1'24 and the 8 January 2024 announcement. Intel says more than 60 HX partner systems come to market in 2024. The first retail month of a laptop with this exact chip was not found. Last checked 15 October 2026.

Cores
16
Max boost clock
5.2GHz
L3 cache
30MB
Socket or package
BGA1964

43 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Core 14th Gen HX5Press releaseintel.com/content/www/us/en/newsroom/news/ces-2024-client-processor-news.htmlRead 15 October 2026Intel's brief calls the line Intel Core Processors HX-Series (14th gen). Stored as Core 14th Gen HX, the form used for the other Intel laptop chips.
Model numbers
CM80715051589232Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/ordering.htmlRead 15 October 2026Ordering code CM8071505158923, spec code SRMXH, stepping B0, package FC-BGA16F, shipping media TRAY. Intel sells this chip as a tray part only.
GTIN / EAN
Not available
Announced
8 January 20245Press releaseintel.com/content/www/us/en/newsroom/news/ces-2024-client-processor-news.htmlRead 15 October 2026Intel's CES 2024 release introduces the 14th Gen Intel Core HX-series mobile processors on 8 January 2024. The release names the i9-14900HX and i7-14700HX. Intel's HX product brief of the same launch lists the i7-14650HX.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Marketing Status: Launched. Launch Date: Q1'24. Vertical Segment: Mobile. Product Collection: Intel Core i7 processors (14th gen). The ordering tab shows no discontinuance notice. Laptops with the chip are sold in 2026.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Instruction Set: 64-bit. Intel's 64-bit processors are x86-64.
Codename
Raptor Lake1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Code Name row reads Products formerly Raptor Lake. Intel's 14th Gen HX parts are called Raptor Lake Refresh in the press, and ARK uses Raptor Lake.
CPU process (as published)
Intel 71Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Lithography row: Intel 7.
CPU process node
10nm1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Intel 7 is stored as 10 nm, the nm class of Intel 7. Intel prints no nm figure.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Instruction Set Extensions lists Intel SSE4.1, SSE4.2 and AVX2 only.

Cores and clocks

Core configuration
Core typeCountCoreBase clock (GHz)Max clock (GHz)
Performance8Raptor Cove2.25.2
Efficiency8Gracemont1.63.7
Source1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Total Cores 16. # of Performance-cores 8 with Performance-core Max Turbo Frequency 5.2 GHz and Performance-core Base Frequency 2.2 GHz. # of Efficient-cores 8 with Efficient-core Max Turbo Frequency 3.7 GHz and Efficient-core Base Frequency 1.6 GHz. ARK names no core architecture, so core_name comes from the Tom's Hardware source.6Press articletomshardware.com/pc-components/cpus/intel-unleashes-14th-gen-raptor-lake-refresh-hx-series-laptops-cpus-refreshed-chips-with-up-to-24-cores-58-ghz-boost-clock-and-192gb-ddr5-supportRead 15 October 2026Tom's Hardware, 8 January 2024: Raptor Lake Refresh uses performant Raptor Cove P-cores and Gracemont E-cores. Its table lists the Core i7-14650HX with 16 cores (8+8), 24 threads, 30 MB cache, up to 5.2 GHz P-core and 3.7 GHz E-core turbo, up to 2.2 GHz and 1.6 GHz base. This matches ARK.
Cores
16
Cores labelled performance
8
Cores labelled efficiency
8
Threads
241Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Total Threads 24. The 8 P-cores have Hyper-Threading and the 8 E-cores do not.
Max boost clock
5.2GHz1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Max Turbo Frequency 5.2 GHz, the same as the Thermal Velocity Boost Frequency and the Performance-core Max Turbo Frequency. The Turbo Boost Max Technology 3.0 Frequency row reads 5.1 GHz.
Unlocked for overclocking
Yes3Maker spec sheet (PDF)download.intel.com/newsroom/2024/client-computing/Product-Brief-Intel-Core-Processors-HX-Series.pdfRead 15 October 2026Page 6, SKU Comparison: the i7-14650HX column has a check mark in the CPU Overclocking row, as do all five HX SKUs. Footnote 3 says unlocked features are present with select chipsets and processor combinations. Intel's brief also says the Extreme Tuning Utility is for users of unlocked processors.6Press articletomshardware.com/pc-components/cpus/intel-unleashes-14th-gen-raptor-lake-refresh-hx-series-laptops-cpus-refreshed-chips-with-up-to-24-cores-58-ghz-boost-clock-and-192gb-ddr5-supportRead 15 October 2026The article says Intel has revealed five HX-series overclockable SKUs, which are the five in its table including the i7-14650HX.

Cache

L2 cache
24MB7Spec databasecpubenchmark.net/cpu.phpRead 15 October 2026PassMark lists L2 Cache 8 x 2048 KB for the performance cores and 2 x 4096 KB for the efficiency cores. The sum is 16 MB plus 8 MB, which is 24 MB. Intel's datasheet section 2.4.2 gives 2 MB per P-core and 4 MB per group of 4 E-cores for the HX Refresh line. ARK has no Total L2 Cache row for this chip.
L3 cache
30MB1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Cache row: 30 MB Intel Smart Cache.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026AMD technology. ARK lists only the 30 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
55W1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Processor Base Power 55 W.
Max turbo power
157W1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Maximum Turbo Power 157 W.
Configurable power range
Minimum45W1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Minimum Assured Power 45 W. ARK has no Maximum Assured Power row, so only the minimum is stored. The datasheet frequency table also lists 55 W as the assured power at the base clocks.
Max operating temperature
100°C1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Max Operating Temperature 100 C. TJUNCTION is also 100 C.

Memory

Memory support
Memory typeModule typeMax speed (MT/s)
DDR5SO-DIMM5,600
DDR4SO-DIMM3,200
Source1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Memory Types: up to DDR5 5600 MT/s and up to DDR4 3200 MT/s. ARK names no module type, rank or configuration, so config is left out. The module type sodimm comes from the datasheet and Tom's Hardware, see those sources.4Maker spec sheet (PDF)cdrdv2-public.intel.com/743844/743844-015.pdfRead 15 October 2026Table 25, DDR support matrix, 14th Generation Intel Core: the HX Refresh line is listed with SoDIMM for DDR4 (up to 3200 MT/s) and DDR5 (1DPC up to 5600 MT/s). The datasheet footnote says speeds refer to the top SKU of a line, so the ARK speeds are used.6Press articletomshardware.com/pc-components/cpus/intel-unleashes-14th-gen-raptor-lake-refresh-hx-series-laptops-cpus-refreshed-chips-with-up-to-24-cores-58-ghz-boost-clock-and-192gb-ddr5-supportRead 15 October 2026The article says the HX line supports XMP SO-DIMMs, with DDR5-5600 and DDR4-3200 and up to 192 GB of DDR5.
Max memory speed (official)
5,600MT/s
Memory channels
21Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Max # of Memory Channels: 2.
Memory bandwidth (claimed)
89.6GB/s1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Max Memory Bandwidth 89.6 GB/s.
Max memory
192GB1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Max Memory Size (dependent on memory type): 192 GB.
ECC memory support
Not available

Platform

Socket or package
BGA19641Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Sockets Supported: FCBGA1964. Stored without the FC prefix. Package Size 45.0 mm x 37.5 mm.
Compatible chipsets
Not available
CPU PCIe lanes
PCIe generationLanes
516
44
Source1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026PCI Express Revision 5.0 and 4.0, Max # of PCI Express Lanes 20, PCI Express Configurations Up to 1x16+4, 2x8+4. ARK gives no per-generation split, so the 16 Gen 5 lanes and 4 Gen 4 lanes come from Intel's HX product brief. The 8 DMI 4.0 lanes to the chipset are not counted.3Maker spec sheet (PDF)download.intel.com/newsroom/2024/client-computing/Product-Brief-Intel-Core-Processors-HX-Series.pdfRead 15 October 2026Page 6, Total PCIe Lanes row for all HX SKUs: 1x16 Gen5 + 1x4 Gen4 (CPU) and 1x16 Gen4 + 1x12 Gen3 (PCH). Only the CPU's own lanes are stored. Page 4 also lists 16 CPU PCIe 5.0 lanes and up to 8 DMI 4.0 lanes.
CPU PCIe lanes in total
20
Highest PCIe generation
5
Native USB ports
Not available
Native USB4 or Thunderbolt
Not available

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026
Integrated GPU
Intel UHD Graphics for 14th Gen Intel Processors1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026GPU Name row reads Intel UHD Graphics for 14th Gen Intel Processors. ARK lists 16 Execution Units and no Xe-core count, so the GPU core count is left out.
GPU cores
Not available
Max GPU clock
1,600MHz1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Graphics Max Dynamic Frequency 1.6 GHz. Intel's HX product brief also lists up to 1.6 GHz for this chip.
Max displays
41Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026# of Displays Supported: 4.
DisplayPort version
1.4a1Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1. Intel's datasheet platform diagram for the HX line shows DP 1.4 and HDMI 2.0b. ARK is used.
HDMI version
2.11Maker product pageintel.com/content/www/us/en/products/sku/235996/intel-core-i7-processor-14650hx-30m-cache-up-to-5-20-ghz/specifications.htmlRead 15 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1. Max Resolution (HDMI) reads 4096 x 2160 at 60 Hz.
Hardware video encode
H.264, H.265 (HEVC), VP94Maker spec sheet (PDF)cdrdv2-public.intel.com/743844/743844-015.pdfRead 15 October 2026Section 9.1.1.2: Xe supports full hardware accelerated video encoding for AVC, HEVC, VP9 and JPEG, and Table 57 lists AVC/H264, HEVC/H265 and VP9. AV1 encode is not listed. The datasheet covers the Xe graphics of the whole 13th and 14th Gen line and does not name the i7-14650HX.
Hardware video decode
H.264, H.265 (HEVC), VP9, AV14Maker spec sheet (PDF)cdrdv2-public.intel.com/743844/743844-015.pdfRead 15 October 2026Section 9.1.1.1: Xe supports full hardware accelerated video decoding for AVC, HEVC, VP9, JPEG and AV1, and Table 56 lists AVC/H264, HEVC/H265, VP9 and AV1. The datasheet covers the Xe graphics of the whole line and does not name the i7-14650HX.

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Sources

We read 7 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 15 October 2026Backs 29 fields
  2. Read 15 October 2026Backs 1 field
  3. Read 15 October 2026Backs 2 fields
  4. Read 15 October 2026Backs 4 fields
  5. Read 15 October 2026Backs 3 fields
  6. Read 15 October 2026Backs 3 fields
  7. Read 15 October 2026Backs 1 field

See a wrong value? Tell us and name the field.
