Intel Core Ultra 9 285H

IntelLaptop CPU

Core Ultra 9 285H

Released February 2025.3Press releaseintel.com/content/www/us/en/newsroom/news/2025-ces-client-computing-news.htmlRead 15 October 2026The same release says Intel Core Ultra 200H and U series-powered systems follow with availability starting in February 2025. ARK lists Launch Date Q1'25. Laptop shipping dates for systems with this chip were not checked. Last checked 15 October 2026.

Cores
16
Max boost clock
5.4GHz
L3 cache
24MB
Socket or package
BGA2049

45 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

At a glance

All specs

SourceCalculated

General

Series
Core Ultra 200H3Press releaseintel.com/content/www/us/en/newsroom/news/2025-ces-client-computing-news.htmlRead 15 October 2026Intel calls the family the Intel Core Ultra 200H series.
Model numbers
QQ80768063BE, QQ80768063F12Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/ordering.htmlRead 15 October 2026Ordering codes QQ80768063BE (spec code Q5YP) and QQ80768063F1 (spec code SRQAL), both Tray, stepping A1, package FCBGA18X. ARK lists no boxed product.
GTIN / EAN
Not available
Announced
6 January 20253Press releaseintel.com/content/www/us/en/newsroom/news/2025-ces-client-computing-news.htmlRead 15 October 2026Intel newsroom release dated 6 January 2025 (CES, Las Vegas) introduces the Core Ultra 200HX and H series mobile processors. It names the Core Ultra 9 285H in a performance comparison with the 185H.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Marketing Status: Launched. Launch Date: Q1'25. Product Collection: Intel Core Ultra Processors (Series 2). Vertical Segment: Mobile.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Vertical Segment row reads Mobile.
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Instruction Set: 64-bit, with Intel 64 listed as Yes. Intel's 64-bit processors are x86-64.
Codename
Arrow Lake1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Code Name row reads Products formerly Arrow Lake.
CPU process (as published)
TSMC N3B1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026CPU Lithography row: TSMC N3B.
CPU process node
3nm1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026TSMC N3B is stored as 3 nm, as on the other Arrow Lake products. Intel prints no nm figure.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Instruction Set Extensions lists Intel SSE4.1, SSE4.2 and AVX2 only.

Cores and clocks

Core configuration
Core typeCountCoreBase clock (GHz)Max clock (GHz)
Performance6Lion Cove2.95.4
Efficiency8Skymont2.74.5
Low-power efficiency2Not available12.5
Source1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026# of Performance-cores 6 with base 2.9 GHz and Max Turbo 5.4 GHz. # of Efficient-cores 8 with base 2.7 GHz and Max Turbo 4.5 GHz. # of Low Power Efficient-cores 2 with base 1 GHz and Max Turbo 2.5 GHz. Total cores 16. Core names are not on ARK. Lion Cove and Skymont come from the Tom's Hardware launch article. Intel does not state the architecture of the low-power cores, so that row has no core_name.4Press articletomshardware.com/pc-components/cpus/intel-launches-arrow-lake-mobile-family-with-core-ultra-200hx-and-200h-processorsRead 15 October 2026Tom's Hardware, 6 January 2025: the 200H processors feature the Lion Cove P-core microarchitecture and employ Skymont for the E-cores. Its table lists the flagship 45 W model as 16 cores (6+8+2), 16 threads, 5.4 GHz P-core turbo and 24 MB cache, which matches ARK. The table labels that chip Core Ultra 9 258H, which looks like a typo for 285H.
Cores
16
Cores labelled performance
6
Cores labelled efficiency
10
Threads
161Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Total Threads 16. Intel Hyper-Threading Technology is No.
Max boost clock
5.4GHz1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Max Turbo Frequency 5.4 GHz, the same as the Performance-core Max Turbo Frequency.
Unlocked for overclocking
Not available

Cache

L2 cache
Not available
L3 cache
24MB1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 202624 MB Intel Smart Cache. The Total L2 Cache row is not on ARK.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026AMD technology. ARK lists only the 24 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
45W1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Processor Base Power 45 W.
Max turbo power
115W1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Maximum Turbo Power 115 W.
Configurable power range
Minimum35W1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Minimum Assured Power 35 W. ARK has no Maximum Assured Power row, so max_w is left out.
Max operating temperature
110°C1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Max Operating Temperature 110 C.

Memory

Memory support
Memory typeMax speed (MT/s)
LPDDR58,400
LPDDR5X8,400
DDR56,400
Source1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Memory Types: Up to LPDDR5/X 8400 MT/s and up to DDR5 6400 MT/s. LPDDR5/X is stored as one lpddr5 row and one lpddr5x row at 8400. ARK names no module type, rank or configuration, so those keys are left out.
Max memory speed (official)
8,400MT/s
Memory channels
21Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Max # of Memory Channels: 2.
Memory bandwidth (claimed)
Not available
Max memory
128GB1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Max Memory Size (dependent on memory type): 128 GB. Tom's Hardware's launch table gives lower limits per memory type for the 200H family. The maker's page wins.
ECC memory support
No1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026ECC Memory Supported: No.

Platform

Socket or package
BGA20491Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Sockets Supported: FCBGA2049. Stored without the FC prefix.
Compatible chipsets
Not available
CPU PCIe lanes
PCIe generationLanes
58
420
Source1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026PCI Express Revision 5.0 and 4.0. PCI Express Configurations: 1x8 5.0 + 3x4 4.0 + 2x4 (x1,x2,x4) 4.0. Max # of PCI Express Lanes 28. The split is read from the configuration string: 8 lanes at Gen 5 and 12 plus 8 lanes at Gen 4, which gives 20 at Gen 4. ARK does not print the per-generation totals.
CPU PCIe lanes in total
28
Highest PCIe generation
5
Native USB ports
Standard
Thunderbolt 4
Source1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Intel Thunderbolt 4: Yes. Intel gives no port count, so the row has no count.
Native USB4 or Thunderbolt
Yes

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026
Integrated GPU
Intel Arc 140T1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026GPU Name: Intel Arc 140T GPU.
GPU cores
81Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Xe-cores: 8.
Max GPU clock
2,350MHz1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Graphics Max Dynamic Frequency 2.35 GHz.
Max displays
41Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026# of Displays Supported: 4.
DisplayPort version
2.1 UHBR201Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Graphics Output: eDP 1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL.
HDMI version
2.1 FRL1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Graphics Output: eDP 1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL.
Hardware video encode
H.264, H.265 (HEVC), AV11Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026H.264 Hardware Encode/Decode Yes, H.265 (HEVC) Hardware Encode/Decode Yes, AV1 Encode/Decode Yes.
Hardware video decode
H.264, H.265 (HEVC), AV11Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026H.264, H.265 (HEVC) and AV1 are listed as Yes. ARK has no VP9 row, so VP9 is left out.

NPU

NPU performance
13TOPS1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026NPU Peak TOPS (Int8): 13. NPU name Intel AI Boost.
Total AI performance
99TOPS1Maker product pageintel.com/content/www/us/en/products/sku/241747/intel-core-ultra-9-processor-285h-24m-cache-up-to-5-40-ghz/specifications.htmlRead 15 October 2026Overall Peak TOPS (Int8): 99. GPU Peak TOPS (Int8) is 77 and NPU Peak TOPS (Int8) is 13. Tom's Hardware's launch article quotes up to 99 platform TOPS and up to 11 NPU TOPS for the family. ARK's figures for this chip are stored.

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Variants

Each variant lists only what differs from the specs above.

Model number
QQ80768063BE
QQ80768063F1

Sources

We read 4 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 15 October 2026Backs 35 fields
  2. Read 15 October 2026Backs 2 fields
  3. Read 15 October 2026Backs 3 fields
  4. Read 15 October 2026Backs 1 field
