PC parts / CPUs
IntelLaptop CPU
Core Ultra X9 388H
- Cores
- 16
- Max boost clock
- 5.1GHz
- L3 cache
- 18MB
- Socket or package
- BGA2540
47 of 74 fields known.
At a glance
Max memory speed (official, any module type)
9,600MT/s
Higher than 96% of other CPUs.
Base power (TDP)
Lower than 87% of other CPUs. Lower is better.
Max turbo power
80W1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026Maximum Turbo Power 80 W with no footnote on ARK. Intel's launch SKU slide and the Quick Reference Guide print two values for this chip, 65 W and 80 W, which means the limit depends on the laptop maker's configuration. The ARK value is stored.3Maker spec sheet (PDF)cdrdv2-public.intel.com/871380/Intel%20Core%20Ultra%20Series%203%20Processors%20-%20Quick%20Reference%20Guide%20v1.pdfRead 15 October 2026Page 3 lists Maximum Turbo Power 65, 80 W with the Processor Base Power 25 W. The footnote says systems with a base power of 25 W and a turbo power of 64 W are supported, and systems with a base power of 45 W and a turbo power of 80 W. The ARK value of 80 W is stored.
Lower than 87% of other CPUs. Lower is better.
General
- Model numbers
- QQ807293B9B40E3, QQ807293B9B45852Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/ordering.htmlRead 15 October 2026Ordering codes QQ807293B9B40E3 (spec code Q9EK) and QQ807293B9B4585 (spec code SA4QW), both Tray, stepping B0, package FCBGA20X. ARK lists no boxed product.
- GTIN / EAN
- Not available
- Predecessor
- Not available
- Successor
- Not available
- Launch price (US)
- Not available
- Launch price (EU)
- Not available
- Markets
- Not available
- Colours
- Not available
Cores and clocks
- Core configuration
Core type Count Core Base clock (GHz) Max clock (GHz) Performance 4 Cougar Cove 2.1 5.1 Efficiency 8 Darkmont 1.6 3.8 Low-power efficiency 4 Darkmont 1.6 3.7 Source1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026# of Performance-cores 4 with base 2.1 GHz and Max Turbo 5.1 GHz. # of Efficient-cores 8 with base 1.6 GHz and Max Turbo 3.8 GHz. # of Low Power Efficient-cores 4 with base 1.6 GHz and Max Turbo 3.7 GHz. Total cores 16. ARK does not name the core architectures. Cougar Cove and Darkmont come from the Chips and Cheese and Igor's Lab Panther Lake architecture articles.5Press articleold.chipsandcheese.com/2025/10/14/panther-lakes-reveal-at-itt-2025Read 15 October 2026Chips and Cheese, 14 October 2025: the P-cores are codenamed Cougar Cove and the E-cores Darkmont. The largest Panther Lake configuration has 4 P-cores, 8 E-cores and 4 LP E-cores, with the 18 MB L3 shared by the P-cores and E-cores and the 12 Xe3 core GPU tile.6Press articleigorslab.de/en/evolution-or-revolution-intel-panther-lake-including-architecture-efficiency-and-software-integrationRead 15 October 2026Igor's Lab names the compute tile cores as four Cougar Cove-P, eight Darkmont-E and four Darkmont-LP-E cores. The LP E-core row stores Darkmont from this source.- Cores
- 16
- Cores labelled performance
- 4
- Cores labelled efficiency
- 12
- Unlocked for overclocking
- Not available
Cache
- L2 cache
- Not available
Power and thermals
- Max turbo power
- 80W1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026Maximum Turbo Power 80 W with no footnote on ARK. Intel's launch SKU slide and the Quick Reference Guide print two values for this chip, 65 W and 80 W, which means the limit depends on the laptop maker's configuration. The ARK value is stored.3Maker spec sheet (PDF)cdrdv2-public.intel.com/871380/Intel%20Core%20Ultra%20Series%203%20Processors%20-%20Quick%20Reference%20Guide%20v1.pdfRead 15 October 2026Page 3 lists Maximum Turbo Power 65, 80 W with the Processor Base Power 25 W. The footnote says systems with a base power of 25 W and a turbo power of 64 W are supported, and systems with a base power of 45 W and a turbo power of 80 W. The ARK value of 80 W is stored.
Memory
- Memory support
Memory type Max speed (MT/s) LPDDR5X 9,600 - Max memory speed (official)
- 9,600MT/s
- Memory bandwidth (claimed)
- Not available
- ECC memory support
- Not available
Platform
- Compatible chipsets
- Not available
- CPU PCIe lanes
PCIe generation Lanes 5 4 4 8 Source1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026PCI Express Revision 5.0 and 4.0. Max # of PCI Express Lanes 12. PCI Express Configurations: x4 PCIe5 (1x4, 2x2) and two rows of x4 PCIe4 (1x4, 2x2, 4x1). That gives 4 lanes at Gen 5 and 8 lanes at Gen 4, which adds up to the stated 12. The Quick Reference Guide gives the same split, 12 (8 G4, 4 G5). The Core Ultra 9 386H has 20 lanes with an extra 8 Gen 5 lanes.3Maker spec sheet (PDF)cdrdv2-public.intel.com/871380/Intel%20Core%20Ultra%20Series%203%20Processors%20-%20Quick%20Reference%20Guide%20v1.pdfRead 15 October 2026Page 3: Total Platform PCIe Lanes, CPU PCIe Config for the 388H reads 12 (8 G4, 4 G5).5Press articleold.chipsandcheese.com/2025/10/14/panther-lakes-reveal-at-itt-2025Read 15 October 2026The article says the largest configuration keeps the I/O configuration of the smallest one, which is 4 Gen 5 and 8 Gen 4 lanes for 12 lanes. The middle configuration, as in the Core Ultra 9 386H, adds 8 Gen 5 lanes.- CPU PCIe lanes in total
- 12
- Highest PCIe generation
- 5
- Native USB ports
Standard Count Thunderbolt 4 4 Source1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026Intel Thunderbolt 4: Yes. ARK gives no port count. The count of 4 comes from the Quick Reference Guide.3Maker spec sheet (PDF)cdrdv2-public.intel.com/871380/Intel%20Core%20Ultra%20Series%203%20Processors%20-%20Quick%20Reference%20Guide%20v1.pdfRead 15 October 2026Page 3: a merged cell for the 388H, 386H, 368H and 366H rows reads 4 Integrated Thunderbolt 4 Ports, Discrete Thunderbolt 5 Technology Support. Only the 4 integrated Thunderbolt 4 ports are stored. Thunderbolt 5 needs a separate controller on the laptop board.- Native USB4 or Thunderbolt
- Yes
Integrated graphics
- Integrated graphics
- Yes1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026
- Integrated GPU
- Intel Arc B3901Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026GPU Name: Intel Arc B390 GPU. Intel also sells an Arc Pro B390 name for vPro systems.
- DisplayPort version
- 2.1 UHBR201Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026Graphics Output: eDP 1.5, DP 2.1 UHBR20, HDMI 2.1 FRL.
- Hardware video encode
- H.264, H.265 (HEVC), AV11Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026H.264 and H.265 (HEVC) hardware encode and decode and AV1 encode and decode are listed. H.266 is decode only.
- Hardware video decode
- H.264, H.265 (HEVC), AV1, H.266 (VVC)1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026H.264, H.265 (HEVC), AV1 and H.266 (decode only) are listed for hardware decode. ARK has no VP9 row, so VP9 is left out.
NPU
- Total AI performance
- Not available
Measured performance
- Cinebench 2024 single-core
- Not available
- Cinebench 2024 multi-core
- Not available
- Cinebench 2026 single-thread
- Not available
- Cinebench 2026 multi-core
- Not available
- Game frame rates
- Not available
Measured power and temperature
- CPU power in multi-thread load (measured)
- Not available
- CPU power while gaming (measured)
- Not available
- CPU power at idle (measured)
- Not available
- CPU temperature in stress test
- Not available
In the box
We could not find any of these 2 fields. Show them
- Cooler in the box
- Not available
- Included cooler
- Not available
Links
- Product page
- www.intel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.html1Maker product pageintel.com/content/www/us/en/products/sku/245526/intel-core-ultra-x9-processor-388h-18m-cache-up-to-5-10-ghz/specifications.htmlRead 15 October 2026
- Spec sheet
- cdrdv2-public.intel.com/871380/Intel%20Core%20Ultra%20Series%203%20Processors%20-%20Quick%20Reference%20Guide%20v1.pdf3Maker spec sheet (PDF)cdrdv2-public.intel.com/871380/Intel%20Core%20Ultra%20Series%203%20Processors%20-%20Quick%20Reference%20Guide%20v1.pdfRead 15 October 2026Intel Core Ultra Series 3 Processors Quick Reference Guide v1, SKU table on page 3 with a row for the Core Ultra X9 388H.
- Manual
- Not available
- EPREL registration number
- Not available
Warranty
We could not find any of these 1 fields. Show them
- Manufacturer warranty (source market)
- Not available
Compare with
Pick a CPU to see both side by side. Differences are marked yellow.
Variants
Each variant lists only what differs from the specs above.
| Model number |
|---|
| QQ807293B9B40E3 |
| QQ807293B9B4585 |
Sources
We read 8 sources for this CPU. The numbers match the markers in the sheet.
See a wrong value? Tell us and name the field.
