PC parts / CPUs

AMD Ryzen 9 9955HX3D

AMDLaptop CPU

Ryzen 9 9955HX3D

Released March 2025.3Press articlethefpsreview.com/2025/03/27/early-amd-ryzen-9-9955hx3d-benchmarks-show-the-fire-range-laptop-16-core-32-thread-cpu-besting-desktop-and-mobile-processorsRead 15 October 2026The FPS Review, 27 March 2025: multiple laptop makers are beginning to launch models with the chip globally, and HotHardware posted the first review benchmarks on an MSI Raider A18 HX, with gaming results held back by embargo. Dream Machines, the first seller to list the chip, expected to ship by the end of March or early April 2025 (Club386, 4 February 2025). The Asus ROG Strix G16 reviews followed in June and July 2025. The exact first retail date was not found, so the month is approximate. Last checked 15 October 2026.

Cores
16
Max boost clock
5.4GHz
L3 cache
128MB
Socket or package
FL1

39 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Ryzen 9000 Series1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Series row: Ryzen 9000 Series.
Model numbers
100-0000010301Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Product ID Tray 100-000001030. AMD lists no boxed product.
GTIN / EAN
Not available
Announced
6 January 20252Press releaseamd.com/en/newsroom/press-releases/2025-1-6-amd-announces-new-graphics-and-gaming-products-for.htmlRead 15 October 2026AMD release of 6 January 2025 (CES, Las Vegas) introduces the Ryzen 9000HX Series and lists the Ryzen 9 9955HX3D with 16 cores, 32 threads, up to 5.4 GHz boost, 2.5 GHz base, 144 MB total cache, Radeon 610M and 55-75W cTDP. It says systems are expected on shelf in the first half of 2025. It gives no price.
Status
Available1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Product is listed and current on AMD's page. The page has no Launch Date row.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Form Factor lists Laptops and Desktops. AMD laptop chips that also list Desktops stay laptop.
Instruction set
x86-641Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Instruction Set row reads x86-64.
Codename
Fire Range1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Former Codename row reads Fire Range.
CPU process (as published)
TSMC 4nm FinFET1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Processor Technology for CPU Cores: TSMC 4nm FinFET. The I/O die is TSMC 6nm FinFET. Package Die Count is 3.
CPU process node
4nm1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026
AVX-512
Yes1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Supported Extensions list includes AVX512.

Cores and clocks

Core configuration
CountCoreBase clock (GHz)Max clock (GHz)
16Zen 52.55.4
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026AMD names no core roles. Processor Architecture is Zen 5 and # of CPU Cores is 16. Base Clock 2.5 GHz is AMD's average effective base frequency of all cores. Max. Boost Clock is Up to 5.4 GHz, the highest single-core clock.
Cores
16
Cores labelled performance
Not available
Cores labelled efficiency
Not available
Threads
321Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Multithreading (SMT) Yes. # of Threads 32.
Max boost clock
5.4GHz1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Max. Boost Clock: Up to 5.4 GHz.
Unlocked for overclocking
Yes1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Unlocked for Overclocking: Yes. AMD's warranty does not cover damage from overclocking.

Cache

L2 cache
16MB1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026L2 Cache 16 MB. L1 is 1280 KB.
L3 cache
128MB1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026L3 Cache 128 MB, including the stacked 3D V-Cache. The 144 MB in AMD's launch table and in laptop spec sheets is L2 plus L3.
AMD 3D V-Cache
Yes1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026The page describes 2nd Gen AMD 3D V-Cache technology and lists 128 MB L3. AMD's CES 2025 release says the stacked memory sits below the processor.

Power and thermals

Base power (TDP)
55W1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Default TDP 55W. Tom's Hardware's CES 2025 table lists 54W, written before AMD's page gave 55W. AMD's page is used.
Max turbo power
Not available
Configurable power range
Minimum55Maximum75W1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026AMD Configurable TDP (cTDP) 55-75W. AMD's CES 2025 release table also lists 55-75W.
Max operating temperature
100°C1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Max. Operating Temperature (Tjmax) 100 C.

Memory

Memory support
Memory typeModule typeModulesMax speed (MT/s)
DDR5SO-DIMM2x1R5,600
DDR5SO-DIMM2x2R5,600
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026System Memory Type DDR5, subtype SO-DIMM. Max Memory Speed rows: 2x1R DDR5-5600 and 2x2R DDR5-5600.
Max memory speed (official)
5,600MT/s
Memory channels
21Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Memory Channels 2.
Memory bandwidth (claimed)
Not available
Max memory
96GB1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Max. Memory 96 GB.
ECC memory support
Not available

Platform

Socket or package
FL11Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026CPU Socket row reads FL1.
Compatible chipsets
Not available
CPU PCIe lanes
PCIe generationLanes
528
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026PCI Express Version PCIe 5.0. Native PCIe Lanes (Total/Usable) reads 28 and 28. The page lists no chipset link, so all 28 are stored.
CPU PCIe lanes in total
28
Highest PCIe generation
5
Native USB ports
StandardCount
USB 3.2 Gen 2 (10 Gbps)4
USB 2.01
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Native USB 3.2 Gen 2 (10Gbps) 4 and Native USB 2.0 (480Mbps) 1.
Native USB4 or Thunderbolt
No

Integrated graphics

Integrated graphics
Yes1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026
Integrated GPU
AMD Radeon 610M1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Graphics Model: AMD Radeon 610M.
GPU cores
21Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Graphics Core Count 2.
Max GPU clock
2,200MHz1Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Graphics Frequency 2200 MHz.
Max displays
41Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026Max Displays 4.
DisplayPort version
2.01Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026DisplayPort Version 2.0. AMD names no UHBR rate.
HDMI version
2.11Maker product pageamd.com/en/products/processors/laptop/ryzen/9000-series/amd-ryzen-9-9955hx3d.htmlRead 15 October 2026HDMI Version 2.1.
Hardware video encode
Not available
Hardware video decode
Not available

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Sources

We read 3 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 15 October 2026Backs 33 fields
  2. Read 15 October 2026Backs 1 field
  3. Read 15 October 2026Backs 1 field
