LemokeyGaming keyboard

P1 HE

Released January 2025.7 Last checked 11 October 2026.

Form factor: 75 %
Switch sensing technology: Magnetic (Hall effect)
Connections: USB (wired), 2.4 GHz, Bluetooth
Max polling rate: 1,000Hz

103 of 164 fields known.

Compare with another keyboard Download JSON Download CSV Get it from the API

All specs

SourceCalculatedHide missing

General

Series: P HE1
Model numbers: P1H-M1, P1H-P12
GTIN / EAN: 4894979011329, 48949790113432
Announced: January 20257
Status: Available1
Predecessor: Not available
Successor: Not available
Launch price (US): $1697
Launch price (EU): Not available
Markets: US1
Colours: Black, White1
Segment: Gaming1
Sold as: Complete1

Layout

Form factor: 75 %1
Layout standard: ANSI1
Regional layouts: ANSI (US)1
Keys in regional layout: 813
Key legends for: Windows1
Numpad: No3
Function row: Yes3
Dedicated arrow keys: Yes3
Navigation keys: Compact3
Key stagger: Row-staggered3
Bottom row: Not available
Low profile: No1

Switches

Switch sensing technology: Magnetic (Hall effect)1
Switch feel: Linear4
Switch maker: Gateron1
Switch models: Gateron Double-Rail Magnetic Nebula Switch1
Switch stem: Not available
Actuation force: Not available
Bottom-out force: 60gf4
Tactile bump force: Not available
Actuation point: Not available
Total travel: Not available
Rated keystrokes: 150million4
Factory-lubed switches: Yes4
Adjustable actuation: Yes1
Actuation range: Min0.2Max3.8mm1
Actuation step: 0.1mm1
Per-key actuation: Yes1
Rapid trigger: Yes1
Minimum rapid trigger movement: 0.1mm1
Multi-action keys: Yes1
SOCD handling: Yes1
Analog input: Yes1
Hot-swap sockets: Magnetic1
Compatible switches: Gateron Double-Rail Magnetic Switches only1
Stabilizers: PCB screw-in1
Factory-lubed stabilizers: Not available

Keycaps

Keycap material: PBT1
Legend method: Doubleshot1
Keycap profile: Cherry1
Keycap thickness: Not available
Shine-through legends: Yes1

Performance

Polling rate per connection: Connection Polling rate (Hz) Receiver or adapter
USB (wired) 1,000 Not available
2.4 GHz 1,000 Included Type-A 2.4 GHz receiver
Bluetooth 125 Not available
Source1
Max polling rate: 1,000Hz
Polling rate (wired): 1,000Hz
Polling rate (2.4 GHz): 1,000Hz
Polling rate (Bluetooth): 125Hz
Scan rate: Not available
Input latency (claimed): Not available
Key rollover per connection: Connection Rollover
USB (wired) NKRO
2.4 GHz NKRO
Bluetooth NKRO
Source1
Anti-ghosting: Not available
Adjustable debounce: Not available
Minimum debounce: Not available

Measured

We could not find any of these 7 fields. Show them

Latency per connection (measured): Not available
Actuation point (measured): Not available
Total travel (measured): Not available
Operating force (measured): Not available
Typing noise (measured): Not available
Battery life (measured): Not available
Weight (measured): Not available

Connectivity

Connections: USB (wired), 2.4 GHz, Bluetooth1
Wireless technology: Not available
Bluetooth: 5.21
Bluetooth device slots: 31
Devices it can switch between: Not available
Device switching: Keys3
Receiver connector: USB-A3
Receiver storage in keyboard: Not available
Receiver shared with other devices: Not available
Wireless range: 10m1
Detachable cable: Yes1
Port on keyboard: USB-C3
Cable plug: USB-A1
Cable: Not available
Cable length: Not available
USB passthrough: Not available
Works with: Windows, macOS, Linux1
Consoles: Not available

Battery

Battery type: Li-Po1
Number of batteries: Not available
Battery capacity: 4,000mAh1
User-replaceable battery: Not available
Battery life per mode (claimed): Lighting Hours (h)
Off 100
Source1
Longest battery life (claimed): 100h
Battery life, lighting off: 100h
Battery life, lighting on: Not available
Battery life, backlight on (claimed): Not available
Battery life, backlight off (claimed): Not available
Charging port: USB-C1
Full charge time: 300min1
Quick charge: Not available
Use while charging: Yes3
Solar charging: Not available
Battery indicator: LED3

Build

Case material: Full metal, CNC machined aluminum1
Plate material: Aluminium1
Mount style: Gasket1
Flex cuts in PCB: Not available
Sound dampening: Case foam, Other1
Typing angles: 5.5°1
Spill resistant: Not available
IP rating: Not available

Lighting

Backlight: RGB per key1
LED position: North-facing1
Lighting zones: Not available
Brightness levels: Not available
Side or underglow lighting: Not available
Lighting sensors: Not available
Lighting sync: Not available

Controls

Media keys: Fn layer3
Separate media buttons: 03
Volume control: Knob6
Knobs: 11
Programmable knob: Yes1
Knob press: Yes3
Separate macro keys: Not available
Built-in screen: None3
Touchpad: No3
Fingerprint reader: No3
OS mode switch: None3
Windows key lock: Not available

Software

Software: Lemokey Launcher1
Software runs on: Web1
Open firmware: QMK1
Onboard memory: Not available
Onboard profiles: 33
Macros: Yes1
Macros stored onboard: Not available
Key remapping: Yes1
Layers: 43
User firmware updates: Yes3

Ergonomics

Wrist rest: None1
Wrist rest material: Not available
Tenting: Not available
Tenting angles: Not available

Dimensions and weight

Dimensions: Width322Depth140mm(12.7 × 5.5 in)1
Dimensions with wrist rest: Not available
Keyboard weight: 1,630g(3.6 lb)1
Weight including wrist rest: Not available
Box dimensions: Not available
Box weight: Not available

Certifications

We could not find any of these 2 fields. Show them

Platform certifications: Not available
Other certifications: Not available

In the box

In the box: Fully assembled keyboard with case, PCB, aluminum plate, sound absorbing foam, EPDM foam and bottom case PET film, 12 gaskets (silicone beans, installed), 4 sets of stabilizers, PBT double-shot keycaps, Gateron double-rail magnetic switches, Type-A to Type-C cable, Type-A 2.4 GHz receiver, Extension adapter for receiver, Keycap and switch puller, Screwdriver, Hex key3
Cables included: Type Count
Type-A to Type-C cable 1
Source3
Spare switches: Not available

Links

Product page: www.keychron.com/products/lemokey-p1-he-wireless-magnetic-switch-custom-gaming-keyboard 1
Spec sheet: www.keychron.com/products/lemokey-p1-he-wireless-magnetic-switch-custom-gaming-keyboard 1
Manual: cdn.shopify.com/s/files/1/0059/0630/1017/files/Lemokey_P1_HE_User_Manual.pdf 3
EPREL registration number: Not available

Warranty

Manufacturer warranty (source market): 1year5

Compare with

Pick a keyboard to see both side by side. Differences are marked yellow.

More keyboard comparisons

Variants

Each variant lists only what differs from the specs above.

Model number	GTIN	Colours
P1H-M1	4894979011329	Black
P1H-P1	4894979011343	White
