PC parts / Power supplies
SeasonicPower supply
CORE GX-650 (2024)
Released December 2024.2Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 2026Seasonic's launch release, posted by Funky Kit on December 6, 2024. Estimated time to market was late December 2024 for the black version in Europe, January 2025 in the USA and Q4 2024 for the rest of the world. Noticias3D published its review on December 27, 2024. The 80 PLUS certificate is dated Sept 24, 2024. Last checked 15 October 2026.
- Power
- 650W
- Efficiency
- 80 PLUS Gold
- Modular cables
- Fully modular
- ATX version
- ATX 3.1
37 of 66 fields known.
General
- Model numbers
- SRP-CGX651-A5A32SF, SRP-CGX651-A5A32SF-W4Retailer pagedekada.com/en/seasonic-psu-atx-31-650w-gold-full-modular-pcie-51-core-gx650-v2-srpcgx651a5a32sf-p-6265.htmlRead 14 October 2026Part number SRP-CGX651-A5A32SF, listed as CORE GX-650 V2, black.5Retailer pageldlc.com/en/product/PB00677582.htmlRead 14 October 2026Model SRP-CGX651-A5A32SF-W for the white CORE GX ATX 3 (2024) 650 W.
- Announced
- 6 December 20242Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 2026Press release dated December 6, 2024.
- Predecessor
- Not available
- Successor
- Not available
- Launch price (US)
- From $89.992Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 20264Retailer pagedekada.com/en/seasonic-psu-atx-31-650w-gold-full-modular-pcie-51-core-gx650-v2-srpcgx651a5a32sf-p-6265.htmlRead 14 October 20265Retailer pageldlc.com/en/product/PB00677582.htmlRead 14 October 2026
- Launch price (EU)
- From €105.92Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 20264Retailer pagedekada.com/en/seasonic-psu-atx-31-650w-gold-full-modular-pcie-51-core-gx650-v2-srpcgx651a5a32sf-p-6265.htmlRead 14 October 20265Retailer pageldlc.com/en/product/PB00677582.htmlRead 14 October 2026
- ATX version
- ATX 3.12Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 2026The units comply with the latest ATX 3.1 and PCIe Gen 5.1 standards.7Certification listclearesult.com/80plus/sites/80plus/files/manufacturer-certificate/SEA%20SONIC%20ELECTRONICS%20CO.%20LTD._SRP-CGX651-A5A32SF_650W_SOCE%207566_Report_0.pdfRead 14 October 2026The certificate lists the type as ATX 3.1.
- PCIe CEM version
- PCIe 5.12Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 2026The units comply with PCIe Gen 5.1.
- Modular cables
- Fully modular2Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 202680 Plus Gold certified units with a fully modular design and color-matching cables with a braided pattern.
- Built by (OEM)
- Not available
Power
- Rated continuous power
- 650W3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: total continuous power 650 W.
- +12V max power
- 648W3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: +12V 648 W.6Retailer pageparadigit.ie/seasonic-core-gx-atx3-1-650-w/21660874/productRead 14 October 2026Combined power +12V 648 W, max output current +12V 54 A.
- +3.3V and +5V combined power
- 100W3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: 100 W shared by the +3.3V and +5V rails.
- +5V standby current
- 3A3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: +5VSB 3A, 15 W.
- AC input voltage
- Lowest100Highest240V3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: AC input 100 V - 240 V, 50-60 Hz, full range.
- Alternative low power mode (ALPM)
- Not available
Certifications
- 80 PLUS rating
- 80 PLUS Gold2Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 202680 Plus Gold certified, as printed in the release. The 80 PLUS list agrees.7Certification listclearesult.com/80plus/sites/80plus/files/manufacturer-certificate/SEA%20SONIC%20ELECTRONICS%20CO.%20LTD._SRP-CGX651-A5A32SF_650W_SOCE%207566_Report_0.pdfRead 14 October 202680 PLUS list entry ID 7566, model SRP-CGX651-A5A32SF, 650W, 80 PLUS Gold, tested 9/24/24 at 115V nominal and 60 Hz (typical efficiency at 50% load 91.33%).
- Cybenetics efficiency at 115V
- Not available
- Cybenetics efficiency at 230V
- Not available
- Cybenetics noise at 115V
- Not available
- Cybenetics noise at 230V
- Not available
Measured
We could not find any of these 10 fields. Show them
- Average efficiency at 115V (measured)
- Not available
- Average efficiency at 230V (measured)
- Not available
- Light-load efficiency at 115V (measured)
- Not available
- Average power factor at 115V (measured)
- Not available
- Average noise at 115V (measured)
- Not available
- Noise at full load at 115V (measured)
- Not available
- Standby power with no load at 115V (measured)
- Not available
- Hold-up time (measured)
- Not available
- 12V ripple at full load (measured)
- Not available
- 12V load regulation (measured)
- Not available
Cables and connectors
- Cables
Connector Connectors Cables Length to first plug (mm) Wire gauge ATX 24-pin (20+4) 1 1 610 Not available CPU 8-pin (EPS, 4+4) 2 2 750 16AWG PCIe 8-pin (6+2) 2 1 700 16AWG 12V-2x6 1 1 700 16AWG SATA power 6 2 Not available Not available 4-pin Molex 3 1 Not available Not available Source3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Page 1 cable list with counts and lengths: ATX 24-pin 1 x 610 mm, ATX12V/EPS 4+4-pin 2 x 750 mm, 12V-2x6 1 x 700 mm, 12V-2x6 to 2 PCIe 1 x 700 mm, Molex x3 1 cable 690 mm, SATA with 3 connectors 2 cables 750 mm. The review says there are no native PCIe 6+2 cables and that the two traditional PCIe cables come from the 12V-2x6 socket of the PSU, so the dual 8-pin cable shares that socket with the native 12V-2x6 cable. The review gives 16 AWG for the CPU and PCIe cables. Lengths come from this single review, since Seasonic's own cable table was not readable. The SATA 750 mm and Molex 690 mm figures match Seasonic's cable table for the CORE GX family, which gives the length to the last plug, so they are not stored.4Retailer pagedekada.com/en/seasonic-psu-atx-31-650w-gold-full-modular-pcie-51-core-gx650-v2-srpcgx651a5a32sf-p-6265.htmlRead 14 October 2026Connector counts: 12VHPWR 1, PCI-Express 6+2 pin 2, Molex 3, SATA 6, 4+4 pin ATX/EPS 2, 20+4 pin ATX 1. LDLC lists the same counts for the white unit.5Retailer pageldlc.com/en/product/PB00677582.htmlRead 14 October 2026Power connectors: 2 x +12V (P8, 2 x P4), 6 x Serial ATA, 1 x ATX 20+4 pin, 3 x Molex (4 pin), 2 x PCI Express 6+2 pin, 1 x PCI Express 16 pin (12V-2x6).6Retailer pageparadigit.ie/seasonic-core-gx-atx3-1-650-w/21660874/productRead 14 October 2026One Molex connector and two PATA connectors, 3 four-pin plugs in all, matching the Noticias3D cable list.- CPU (EPS) connectors
- 2
- PCIe 8-pin connectors
- 2
- 16-pin GPU connectors
- 1
- SATA power connectors
- 6
- 4-pin Molex connectors
- 3
Fan
- Fan size
- 120mm2Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 2026A 120 mm hydro dynamic bearing fan with Seasonic's Smart and Silent Fan Control.3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: fan size 120 mm. The review's sample had an Ong Hua 120 mm fan.
- Fan bearing
- Hydrodynamic (HDB)2Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 2026Hydro dynamic bearing fan, 120 mm.3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: hydro dynamic bearing (Rodamiento hidrodinamico), life 25,000 hours at 40 C, 15-65% RH.
- Fan mode
- Not available
- Fan mode switch
- Not available
Protection and parts
- Protections
- Over-current (OCP), Over-voltage (OVP), Under-voltage (UVP), Over-power (OPP), Over-temperature (OTP), Short-circuit (SCP)3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: OCP, OPP, OTP, OVP, SCP, UVP.4Retailer pagedekada.com/en/seasonic-psu-atx-31-650w-gold-full-modular-pcie-51-core-gx650-v2-srpcgx651a5a32sf-p-6265.htmlRead 14 October 2026OPP, OCP, OTP, OVP, SCP, UVP.
- All-Japanese capacitors
- Not available
- MTBF (claimed)
- 100,000h3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: MTBF 100,000 hours at 25 C, without the fan.6Retailer pageparadigit.ie/seasonic-core-gx-atx3-1-650-w/21660874/productRead 14 October 2026Mean time between failures 100000 h.
Monitoring and lighting
- Software monitoring
- Not available
- Software
- Not available
- Built-in power display
- Not available
Dimensions and weight
Front and side, drawn to scale.
- Dimensions
- Width150Height86Depth140mm(5.9 × 3.4 × 5.5 in)3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: 140 x 150 x 86 mm. A retailer writes it as 140 mm (L) x 150 mm (W) x 86 mm (H). Depth 140, width 150, height 86.
- Weight
- Not available
In the box
We could not find any of these 1 fields. Show them
- In the box
- Not available
Links
- Product page
- seasonic.com/core-gx-atx-3-20241Maker product pageseasonic.com/core-gx-atx-3-2024Read 14 October 2026Seasonic's site is blocked for agents, so the page text was not read. The link is the CORE GX ATX 3.1 family page that search results name for this unit. The specs come from Seasonic's launch release, the 80 PLUS list, a review that copies Seasonic's spec table and EU retailer listings.
- Spec sheet
- Not available
- Manual
- Not available
- EPREL registration number
- Not available
Warranty
- Manufacturer warranty (source market)
- 7years2Press releasefunkykit.com/news/seasonic-launches-updated-core-atx-3-psu-series-with-atx-3-1-and-pcie-gen-5-1Read 14 October 2026Sea Sonic's 7-year worldwide manufacturer's warranty.3Reviewnoticias3d.com/articulo/3844/seasonic-core-gx-atx-3-2024-650w-review-apuesta-economica-ultimos-estandares.htmlRead 14 October 2026Specifications page: 7 years.4Retailer pagedekada.com/en/seasonic-psu-atx-31-650w-gold-full-modular-pcie-51-core-gx650-v2-srpcgx651a5a32sf-p-6265.htmlRead 14 October 2026Warranty 84 months.
Compare with
Pick a power supply to see both side by side. Differences are marked yellow.
Variants
Each variant lists only what differs from the specs above.
| Model number | GTIN | Launch price (US) | Launch price (EU) | Markets | Colours |
|---|---|---|---|---|---|
| SRP-CGX651-A5A32SF | 4711173878452 | $89.99 | €105.9 | US, EU | Black |
| SRP-CGX651-A5A32SF-W | Not available | Not available | Not available | Not available | White |
Sources
We read 7 sources for this power supply. The numbers match the markers in the sheet.
- Maker product pageseasonic.com/core-gx-atx-3-2024
- Retailer pageldlc.com/en/product/PB00677582.html
See a wrong value? Tell us and name the field.
