BRAVIA 9

Released May 2024.6 Last checked 23 October 2026.

80 of 159 fields known.

At a glance

SourceCalculatedHide missing

Maximum accepted refresh rate per resolution and input: Maximum accepted refresh rate per resolution and input. The top rate is in bold.
Resolution HDMI 2.1
3840 × 2160Native 120Hz4:4:4
Source4
Show as source table
Width (px) Height (px) Input Input version Maximum accepted rate (Hz) Chroma
3840 2160 HDMI 2.1 120 4:4:4
Maximum accepted refresh rate: 120Hz
Maximum accepted refresh rate at 4K: 120Hz
Adaptive sync: HDMI VRR, G-SYNC Compatible4
VRR range per input: Not available
Low framerate compensation: Yes4
Dolby Vision gaming: Yes5
Auto game mode (ALLM): Yes1
Game menu features: Not available
Input lag (claimed): Not available

Maximum accepted refresh rate per resolution and input. The top rate is in bold.
Resolution	HDMI 2.1
3840 × 2160Native	120Hz4:4:4

Width (px)	Height (px)	Input	Input version	Maximum accepted rate (Hz)	Chroma
3840	2160	HDMI	2.1	120	4:4:4

Input lag (measured): Not available
Input lag at 4K 60 Hz (measured): Not available
Input lag at 4K 120 Hz (measured): Not available
Input lag at 4K 144 Hz (measured): Not available
SDR brightness in a real scene (measured): Not available
HDR brightness in a real scene (measured): Not available
HDR brightness per window (measured): Window Brightness (nits)
10% 1,871
100% 495
Source5
HDR peak brightness (measured): 1,871nits
Full-screen HDR brightness (measured): 495nits
Contrast ratio (measured): Not available
Contrast with local dimming (measured): Not available
Infinite contrast (measured): Not available
DCI-P3 coverage (measured): Not available
Rec. 2020 coverage (measured): Not available
Colour volume at 1,000 nits (measured): Not available
Colour volume at 10,000 nits (measured): Not available
Colour accuracy (measured Delta E): Not available
Gray uniformity deviation (measured): Not available
Colour shift angle (measured): Not available
Reflections (measured): Not available
Total pixel response time (measured): Not available
PWM flicker frequency (measured): Not available
VRR range (measured): Not available
4:4:4 chroma (measured): Not available
Power use SDR (measured): Not available

Window	Brightness (nits)
10%	1,871
100%	495

Type	Count
Terrestrial and cable	1

Physical speaker channels: 2.2.25 8
Physical speaker drivers: 81
Total built-in speaker power: 70W1
Built-in subwoofer: Yes1
Up-firing speakers: Yes8
Audio formats: Dolby Atmos, DTS, DTS Express, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS:X, Dolby Audio (formats not named)1
eARC passthrough: Not available
Audio features: Acoustic Multi-Audio+, Acoustic Center Sync, Voice Zoom 3, 3D Surround Upscaling1
Bluetooth headphones: Not available

Video inputs: Type Port Version Count Max refresh rate at 4K (Hz) eARC HDCP
HDMI HDMI 3 2.1 1 120 Yes 2.3
HDMI HDMI 4 2.1 1 120 Not available 2.3
HDMI HDMI 1, 2 Not available 2 Not available Not available 2.3
Source1 2 4
HDMI ports: 4
HDMI ports with 4K 120 Hz: Not available
Highest HDMI version: 2.1
Maximum HDMI link bandwidth: Not available
HDMI features: ALLM, VRR, eARC, CEC1
USB peripheral ports: Connector USB version Count
USB-A 2.0 1
USB-A 3.2 Gen 1 1
Source2 5
Ethernet speed: 100Mbps2
Wi-Fi: Wi-Fi 6E1
Wi-Fi bands: 2.4 GHz, 5 GHz, 6 GHz1
Bluetooth: 5.31
Optical out: Yes2
Headphone out: Not available
Included connection box: Not available

Type	Port	Version	Count	Max refresh rate at 4K (Hz)	eARC	HDCP
HDMI	HDMI 3	2.1	1	120	Yes	2.3
HDMI	HDMI 4	2.1	1	120	Not available	2.3
HDMI	HDMI 1, 2	Not available	2	Not available	Not available	2.3

Connector	USB version	Count
USB-A	2.0	1
USB-A	3.2 Gen 1	1

We could not find any of these 3 fields. Show them

Front and side, drawn to scale.

Dimensions with stand: Width1,443Height846Depth349mm(56.8 × 33.3 × 13.7 in)1 3
Dimensions without stand: Width1,443Height835Depth48mm(56.8 × 32.9 × 1.9 in)1 3
Thinnest depth: Not available
Weight with stand: 34.8kg(76.7 lb)1 3
Weight without stand: 32.4kg(71.4 lb)1 3
