AMD Ryzen 7 5800XT

AMDDesktop CPU

Ryzen 7 5800XT

Released July 2024.1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Launch Date 07/31/2024 on the AMD page. Last checked 14 October 2026.

Cores
8
Max boost clock
4.8GHz
L3 cache
32MB
Socket or package
AM4

38 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Ryzen 5000 Series1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Series row: Ryzen 5000 Series.
Model numbers
100-100001582WOF, 100-100001582WOZ, 100-100001582BOX, 100-000001582, 100-100001582MPK, 100-100001582CPK1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Product ID Boxed 100-100001582WOF and 100-100001582WOZ, Product ID Tray 100-000001582, Product ID MPK 100-100001582MPK and 100-100001582CPK. The original boxed code 100-100001582BOX is no longer on the AMD page. It comes from Stock in the Channel and other retailers.
GTIN / EAN
7301433165765Retailer pageus.stockinthechannel.com/Product/AMD-Ryzen-7-5800XT-processor-3-8-GHz-36-MB-L2-L3-Box/52631324Read 14 October 2026Stock in the Channel lists EAN 0730143316576 for SKU 100-100001582BOX, which is UPC 730143316576 with a leading zero. No barcode was found for the WOF, WOZ or tray codes.
Announced
2 June 20242Press releaseamd.com/en/newsroom/press-releases/2024-6-2-amd-unveils-next-gen-zen-5-ryzen-processors-to-p.htmlRead 14 October 2026AMD press release dated 2 June 2024 (Computex, Taipei) announces the Ryzen 7 5800XT and Ryzen 9 5900XT as new Ryzen 5000 Series processors, expected from July 2024. It gives no price.
Status
Available1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Product is listed and current on AMD's page.
Predecessor
Not available
Successor
Not available
Launch price (US)
$2493Press articletomshardware.com/pc-components/cpus/amds-ryzen-9-5900xt-ryzen-7-5800xt-launch-today-for-dollar349-and-dollar249-respectively-existing-ryzen-5000-is-less-expensiveRead 14 October 2026Tom's Hardware, 31 July 2024: launch-day pricing for the Ryzen 7 5800XT is $249, listed at Newegg and Best Buy. Guru3D's launch article also gives $249 in North America. US prices are before sales tax. The article does not name the cooler. No euro launch price is stored, since Guru3D's roughly 265 euro is a retail figure and not an AMD list price.
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Desktop1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
Instruction set
x86-641Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
Codename
Vermeer1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Former Codename row reads Vermeer.
CPU process (as published)
TSMC 7nm FinFET1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Processor Technology for CPU Cores: TSMC 7nm FinFET. The I/O die is 12nm (Globalfoundries). Package Die Count is 2.
CPU process node
7nm1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
AVX-512
No1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026The Supported Extensions list names AVX and AVX2 and has no AVX512.

Cores and clocks

Core configuration
CountCoreBase clock (GHz)Max clock (GHz)
8Zen 33.84.8
Source1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026AMD names no core roles. Processor Architecture is Zen 3. Base Clock is AMD's average effective base frequency of all cores. Max. Boost Clock is the highest single-core clock, Up to 4.8 GHz.
Cores
8
Cores labelled performance
Not available
Cores labelled efficiency
Not available
Threads
161Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
Max boost clock
4.8GHz1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
Unlocked for overclocking
Yes1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026

Cache

L2 cache
4MB1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
L3 cache
32MB1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 202632 MB L3. L2 is 4 MB and L1 is 512 KB. AMD's launch table lists 36 MB, which is L2 plus L3 together.
AMD 3D V-Cache
No1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026AMD lists 32 MB L3 and no stacked cache or 3D V-Cache technology.

Power and thermals

Base power (TDP)
105W1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Default TDP 105W.
Max turbo power
Not available
Configurable power range
Not available
Max operating temperature
90°C1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Max. Operating Temperature (Tjmax) 90C.

Memory

Memory support
Memory typeModule typeModulesMax speed (MT/s)
DDR4UDIMM2x1R3,200
DDR4UDIMM2x2R3,200
DDR4UDIMM4x1R2,933
DDR4UDIMM4x2R2,667
Source1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Max Memory Speed rows: 2x1R DDR4-3200, 2x2R DDR4-3200, 4x1R DDR4-2933, 4x2R DDR4-2667. System Memory Subtype is UDIMM.
Max memory speed (official)
3,200MT/s
Memory channels
21Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
Memory bandwidth (claimed)
Not available
Max memory
128GB1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
ECC memory support
Yes1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Page says ECC Support: Yes (Requires mobo support).

Platform

Socket or package
AM41Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026
Compatible chipsets
AMD X570, AMD B550, AMD A520, AMD X470, AMD B4501Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Supporting Chipsets row, in AMD's order.
CPU PCIe lanes
PCIe generationLanes
420
Source1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026PCI Express Version is PCIe 4.0. Native PCIe Lanes (Total/Usable) is 24 and 20. The 20 usable lanes are stored.
CPU PCIe lanes in total
20
Highest PCIe generation
4
Native USB ports
StandardCount
USB 3.2 Gen 2 (10 Gbps)4
Source1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Native USB 3.2 Gen 2 (10Gbps) 4. The page lists 0 for Native USB 3.2 Gen 1 and 0 for Native USB 2.0, so those rows are not stored. It also lists 2 native SATA ports, which the schema has no field for.
Native USB4 or Thunderbolt
No

Integrated graphics

Integrated graphics
No1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026Graphics Model: Discrete Graphics Card Required.
Integrated GPU
Not available
GPU cores
Not available
Max GPU clock
Not available
Max displays
Not available
DisplayPort version
Not available
HDMI version
Not available
Hardware video encode
Not available
Hardware video decode
Not available

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

Cooler in the box
No1Maker product pageamd.com/en/products/processors/desktops/ryzen/5000-series/amd-ryzen-7-5800xt.htmlRead 14 October 2026AMD's page has no Thermal Solution row. A footnote on the Product ID Boxed and MPK rows says that select Ryzen 7000 and 5000 boxed models no longer include a cooler since 8/1/2025, because the AMD SR4 cooler reached end of life. Club386 lists the Ryzen 7 5800XT as getting no cooler. The base value is for the current WOF and WOZ boxes. The original BOX version has a variant row with the Wraith Prism.
Included cooler
Not available

Warranty

Manufacturer warranty (source market)
3years6Maker product pageamd.com/en/resources/support-articles/warranty/PIB.htmlRead 14 October 2026AMD Processor in a Box (PIB) 3-Year Limited Warranty for boxed processors bought new at retail. A tray processor is handled by the seller, not AMD. Global.

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Variants

Each variant lists only what differs from the specs above.

Model numberGTINLaunch price (US)Cooler in the boxIncluded cooler
100-100001582BOX730143316576$249YesAMD Wraith Prism
100-100001582WOFNot availableNot availableSame as baseNot available
100-100001582WOZNot availableNot availableSame as baseNot available
100-000001582Not availableNot availableSame as baseNot available

Sources

We read 6 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 14 October 2026Backs 31 fields
  2. Read 14 October 2026Backs 1 field
  3. Read 14 October 2026Backs 1 field
  4. Read 14 October 2026Backs 1 field
  5. Read 14 October 2026Backs 1 field
  6. Read 14 October 2026Backs 1 field

See a wrong value? Tell us and name the field.
