AMD Ryzen 7 7730U

AMDLaptop CPU

Ryzen 7 7730U

Released January 2023.1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Launch Date Q1 2023 on the AMD page. AMD's CES release of 4 January 2023 said systems with the Ryzen 7030 Series would come from HP, Acer, Lenovo and Asus beginning in January 2023. The first retail month is not proven. January 2023 is stored. Last checked 15 October 2026.

Cores
8
Max boost clock
4.5GHz
L3 cache
16MB
Socket or package
FP6

37 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

At a glance

All specs

SourceCalculated

General

Series
Ryzen 7000 Series1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Series row: Ryzen 7000 Series. AMD's CES release calls the line Ryzen 7030 Series.
Model numbers
100-0000009421Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Product ID Tray 100-000000942. AMD lists no boxed product.
GTIN / EAN
Not available
Announced
4 January 20232Press releaseamd.com/en/newsroom/press-releases/2023-1-4-amd-extends-its-leadership-with-the-introduction-o.htmlRead 15 October 2026AMD press release dated 4 January 2023 (CES 2023) introduces the Ryzen 7030 Series processors for mobile and lists the Ryzen 7 7730U with 8C/16T, up to 4.5 GHz and 2.0 GHz, 20 MB cache and 15W. It gives no price.
Status
Available1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Product is listed and current on AMD's page, with Regional Availability Global, China, NA, EMEA, APJ and LATAM.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Form Factor lists Laptops and Desktops. AMD laptop chips that also list Desktops stay laptop.
Instruction set
x86-641Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Instruction Set row: x86-64.
Codename
Barcelo R1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Former Codename row reads Barcelo R.
CPU process (as published)
TSMC 7nm FinFET1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Processor Technology for CPU Cores: TSMC 7nm FinFET. Package Die Count is 1.
CPU process node
7nm1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026TSMC 7nm FinFET is stored as 7 nm.
AVX-512
No1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Supported Extensions lists AVX and AVX2 and leaves out AVX512. The list is complete, so the value is false.

Cores and clocks

Core configuration
CountCoreBase clock (GHz)Max clock (GHz)
8Zen 324.5
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026AMD names no core roles. Processor Architecture is Zen 3 and # of CPU Cores is 8. Base Clock 2 GHz is AMD's average effective base frequency of all cores. Max. Boost Clock Up to 4.5 GHz is the highest single-core clock.
Cores
8
Cores labelled performance
Not available
Cores labelled efficiency
Not available
Threads
161Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Multithreading (SMT) Yes, # of Threads 16.
Max boost clock
4.5GHz1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Max. Boost Clock: Up to 4.5 GHz.
Unlocked for overclocking
No1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Unlocked for Overclocking: No.

Cache

L2 cache
4MB1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026L2 Cache 4 MB. L1 is 512 KB.
L3 cache
16MB1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026L3 Cache 16 MB. AMD's CES table lists 20 MB, which is L2 plus L3.
AMD 3D V-Cache
No1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026AMD lists 16 MB L3 and no stacked cache or 3D V-Cache technology.

Power and thermals

Base power (TDP)
15W1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Default TDP 15W. AMD's page lists no configurable TDP, so none is stored.
Max turbo power
Not available
Configurable power range
Not available
Max operating temperature
95°C1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Max. Operating Temperature (Tjmax) 95C.

Memory

Memory support
Memory typeModule typeModulesMax speed (MT/s)
DDR4UDIMM2x1R3,200
LPDDR4XSolderedNot available4,267
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026System Memory Type: DDR4. System Memory Subtype: UDIMM. The Max Memory Speed row is labelled 2x1R and reads DDR4-3200 and LPDDR4X-4267, so the DDR4 row keeps that label. AMD names UDIMM as the only module type for this laptop chip and no AMD row names SO-DIMM, so UDIMM is stored as AMD writes it. LPDDR4X is soldered to the board and has no module configuration.
Max memory speed (official)
4,267MT/s
Memory channels
21Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Memory Channels: 2.
Memory bandwidth (claimed)
Not available
Max memory
64GB1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Max. Memory 64 GB.
ECC memory support
Yes1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Page says ECC Support: Yes (Requires mobo support).

Platform

Socket or package
FP61Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026CPU Socket row reads FP6.
Compatible chipsets
Not available
CPU PCIe lanes
PCIe generationLanes
316
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026PCI Express Version is PCIe 3.0. Native PCIe Lanes (Total/Usable) is 20 and 16. The 16 usable lanes are stored.
CPU PCIe lanes in total
16
Highest PCIe generation
3
Native USB ports
StandardCount
USB 3.2 Gen 2 (10 Gbps)2
USB 2.04
Source1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Native USB 3.2 Gen 2 (10Gbps) 2 and Native USB 2.0 (480Mbps) 4. The page lists no USB4 row.
Native USB4 or Thunderbolt
No

Integrated graphics

Integrated graphics
Yes1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026
Integrated GPU
AMD Radeon Graphics1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Graphics Model: AMD Radeon Graphics.
GPU cores
81Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Graphics Core Count 8.
Max GPU clock
2,000MHz1Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026Graphics Frequency 2000 MHz.
Max displays
Not available
DisplayPort version
2.01Maker product pageamd.com/en/products/processors/laptop/ryzen/7000-series/amd-ryzen-7-7730u.htmlRead 15 October 2026DisplayPort Version 2.0, with the extensions Adaptive-Sync, HBR3 and HDR Metadata. AMD states no UHBR rate. The page's DisplayPort Max Refresh Rates (SDR) top out at 3840x2160 at 60 Hz. The page lists no HDMI version, no maximum display count and no video codec rows.
HDMI version
Not available
Hardware video encode
Not available
Hardware video decode
Not available

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Sources

We read 2 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 15 October 2026Backs 32 fields
  2. Read 15 October 2026Backs 1 field

See a wrong value? Tell us and name the field.
