PC parts / CPUs

Intel Core i5-13420H

IntelLaptop CPU

Core i5-13420H

Released January 2023.5Press releaseintel.com/content/www/us/en/newsroom/resources/13th-gen-core.htmlRead 14 October 2026ARK Launch Date Q1'23 and the January 2023 launch deck. Laptop shipping dates for this chip were not checked. Last checked 14 October 2026.

Cores
8
Max boost clock
4.6GHz
L3 cache
12MB
Socket or package
BGA1744

38 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Core 13th Gen H5Press releaseintel.com/content/www/us/en/newsroom/resources/13th-gen-core.htmlRead 14 October 2026Intel's deck names the H-series of the 13th Gen Intel Core mobile processors. ARK lists the Product Collection as 13th Generation Intel Core i5 Processors. Stored as Core 13th Gen H.
Model numbers
FJ80715052035002Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/ordering.htmlRead 14 October 2026Ordering code FJ8071505203500, spec code SRMHX, Tray, stepping J0, package FC-BGA16F. ARK lists no boxed product.
GTIN / EAN
Not available
Announced
3 January 20235Press releaseintel.com/content/www/us/en/newsroom/resources/13th-gen-core.htmlRead 14 October 2026Intel press kit: on 3 January 2023 Intel introduced 32 new mobile processors for all laptop segments. The launch deck of that day lists the i5-13420H in the H-series table.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Marketing Status: Launched. Launch Date: Q1'23. Product Collection: 13th Generation Intel Core i5 Processors. Vertical Segment: Mobile. The ordering tab shows no discontinuance notice.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Vertical Segment row reads Mobile.
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Instruction Set: 64-bit. Intel's 64-bit processors are x86-64.
Codename
Raptor Lake1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Code Name row reads Products formerly Raptor Lake. Reviewers describe the chip as Alder Lake silicon with a Raptor Lake name. Intel's name is stored.
CPU process (as published)
Intel 71Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Lithography row: Intel 7.
CPU process node
10nm1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Intel 7 is stored as 10 nm, the nm class of Intel 7. Intel prints no nm figure.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Instruction Set Extensions lists Intel SSE4.1, SSE4.2 and AVX2 only.

Cores and clocks

Core configuration
Core typeCountBase clock (GHz)Max clock (GHz)
Performance42.14.6
Efficiency41.53.4
Source1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Total Cores 8. # of Performance-cores 4 with Performance-core Max Turbo 4.60 GHz. # of Efficient-cores 4 with Efficient-core Max Turbo 3.40 GHz. The base clocks are not on ARK and come from Intel's launch deck. ARK names no core architecture, so core_name is left out.3Maker spec sheet (PDF)download.intel.com/newsroom/2023/client-computing/Intel-13th-Gen-Core-Mobile-Press-Deck.pdfRead 14 October 2026H-series table for enthusiast laptops: i5-13420H, 8C 12T, 4P 4E, 12 MB L3, max turbo 4.6 GHz and 3.4 GHz, base frequency 2.1 GHz and 1.5 GHz, 48 EU, graphics 1.4 GHz, memory 5200, 45 W base power. The table lists 95 W maximum turbo power, which differs from ARK.4Spec databaseen.wikipedia.org/wiki/Raptor_LakeRead 14 October 2026Raptor Lake-H table: i5-13420H with 4 P-cores at 2.1 GHz base and 4.6 GHz turbo and 4 E-cores at 1.5 GHz base and 3.4 GHz turbo, 12 MB cache. Agrees with Intel's launch deck.
Cores
8
Cores labelled performance
4
Cores labelled efficiency
4
Threads
121Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Total Threads 12. The 4 P-cores have Hyper-Threading and the 4 E-cores do not.
Max boost clock
4.6GHz1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Max Turbo Frequency 4.60 GHz, the same as the Performance-core Max Turbo Frequency.
Unlocked for overclocking
No6Maker product pageintel.com/content/www/us/en/support/articles/000038213/processors/intel-core-processors.htmlRead 14 October 2026Intel: overclocking is supported only for unlocked Core processors, identified by a K or X in the processor number. The i5-13420H has neither, and ARK lists no overclocking feature, so it is stored as locked.

Cache

L2 cache
Not available
L3 cache
12MB1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 202612 MB Intel Smart Cache. ARK has no Total L2 Cache row for this chip.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026AMD technology. ARK lists only the 12 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
45W1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Processor Base Power 45 W.
Max turbo power
115W1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Maximum Turbo Power 115 W on ARK. Intel's January 2023 launch deck lists 95 W for this chip, so the two Intel documents disagree. ARK is the current maker page and is stored.
Configurable power range
Minimum35W1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Minimum Assured Power 35 W. ARK has no Maximum Assured Power row, so max_w is left out.
Max operating temperature
100°C1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Max Operating Temperature 100 C. TJUNCTION is also 100 C.

Memory

Memory support
Memory typeMax speed (MT/s)
DDR55,200
DDR43,200
LPDDR55,200
LPDDR5X5,200
LPDDR4X4,267
Source1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Memory Types: Up to DDR5 5200 MT/s, up to DDR4 3200 MT/s, up to LPDDR5/x 5200 MT/s and up to LPDDR4x 4267 MT/s. LPDDR5/x is stored as one lpddr5 row and one lpddr5x row at 5200. ARK names no module type, rank or configuration, so those keys are left out.
Max memory speed (official)
5,200MT/s
Memory channels
21Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Max # of Memory Channels: 2.
Memory bandwidth (claimed)
Not available
Max memory
96GB1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Max Memory Size (dependent on memory type): 96 GB.
ECC memory support
No1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026ECC Memory Supported: No.

Platform

Socket or package
BGA17441Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Sockets Supported: FCBGA1744. Stored without the FC prefix.
Compatible chipsets
Not available
CPU PCIe lanes
Not available
CPU PCIe lanes in total
Not available
Highest PCIe generation
Not available
Native USB ports
Standard
Thunderbolt 4
Source1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Intel Thunderbolt 4: Yes. Intel gives no port count, so the row has no count. ARK also lists 28 maximum PCI Express lanes with a Gen 5 processor and Gen 3 chipset, without a split, so the PCIe lane table is left out.
Native USB4 or Thunderbolt
Yes

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026
Integrated GPU
Intel UHD Graphics for 13th Gen Intel Processors1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026GPU Name: Intel UHD Graphics for 13th Gen Intel Processors. The graphics rows list 48 Execution Units and no Xe-core count, so the GPU core count is left out.
GPU cores
Not available
Max GPU clock
1,400MHz1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Graphics Max Dynamic Frequency 1.40 GHz.
Max displays
41Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026# of Displays Supported: 4.
DisplayPort version
1.4a1Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1.
HDMI version
2.11Maker product pageintel.com/content/www/us/en/products/sku/232173/intel-core-i513420h-processor-12m-cache-up-to-4-60-ghz/specifications.htmlRead 14 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1. ARK has no encode or decode codec rows, so the video codec fields are left out.
Hardware video encode
Not available
Hardware video decode
Not available

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Variants

Each variant lists only what differs from the specs above.

Model number
FJ8071505203500

Sources

We read 6 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 14 October 2026Backs 29 fields
  2. Read 14 October 2026Backs 2 fields
  3. Read 14 October 2026Backs 1 field
  4. Read 14 October 2026Backs 1 field
  5. Read 14 October 2026Backs 3 fields
  6. Read 14 October 2026Backs 1 field
