PC parts / CPUs

Intel Core 5 210H

IntelLaptop CPU

Core 5 210H

Released December 2024.6Press articlegeeknetic.es/Noticia/33414/Intel-desvela-los-procesadores-Core-200H-basados-en-la-pasada-arquitectura-Raptor-Lake.htmlRead 15 October 2026ARK Launch Date Q4'24 and the December 2024 listing on Intel's site. Laptop shipping dates for systems with this chip were not checked. Last checked 15 October 2026.

Cores
8
Max boost clock
4.8GHz
L3 cache
12MB
Socket or package
BGA1744

45 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Core 200H6Press articlegeeknetic.es/Noticia/33414/Intel-desvela-los-procesadores-Core-200H-basados-en-la-pasada-arquitectura-Raptor-Lake.htmlRead 15 October 2026The article names the group Intel 200H, laptop chips based on Raptor Lake Refresh. ARK's Product Collection reads Intel Core processors (Series 2). Stored as Core 200H, as on the Core 7 240H.
Model numbers
FJ8071506058701, FJ80715061674012Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/ordering.htmlRead 15 October 2026Ordering codes FJ8071506058701 (spec code Q5MN) and FJ8071506167401 (spec code SRQ6R), both Tray, stepping J0, package FC-BGA16F. ARK lists no boxed product.
GTIN / EAN
Not available
Announced
December 20246Press articlegeeknetic.es/Noticia/33414/Intel-desvela-los-procesadores-Core-200H-basados-en-la-pasada-arquitectura-Raptor-Lake.htmlRead 15 October 2026Geeknetic, 19 December 2024: Intel published the Intel 200H processors on its website with no prior announcement. The article names the Core 5 210H among the five chips. No press release exists, so only the month is stored.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Marketing Status: Launched. Launch Date: Q4'24. Product Collection: Intel Core processors (Series 2). Vertical Segment: Mobile.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Vertical Segment row reads Mobile.
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Instruction Set: 64-bit, with Intel 64 listed as Yes. Intel's 64-bit processors are x86-64.
Codename
Raptor Lake1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Code Name row reads Products formerly Raptor Lake. Press calls the Core 200H group a Raptor Lake Refresh rebadge.
CPU process (as published)
Intel 71Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Lithography row: Intel 7.
CPU process node
10nm1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Intel 7 is stored as 10 nm, the nm class of Intel 7. Intel prints no nm figure.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Instruction Set Extensions lists Intel SSE4.1, SSE4.2 and AVX2 only.

Cores and clocks

Core configuration
Core typeCountBase clock (GHz)Max clock (GHz)
Performance42.24.8
Efficiency41.63.6
Source1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026# of Performance-cores 4 with base 2.2 GHz and Max Turbo 4.8 GHz. # of Efficient-cores 4 with base 1.6 GHz and Max Turbo 3.6 GHz. Low Power Efficient-cores 0. Total cores 8. ARK names no core architecture, so core_name is left out.
Cores
8
Cores labelled performance
4
Cores labelled efficiency
4
Threads
121Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Total Threads 12. Hyper-Threading is Yes, so the four performance cores run two threads each.
Max boost clock
4.8GHz1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Max Turbo Frequency 4.8 GHz, the same as the Performance-core Max Turbo Frequency.
Unlocked for overclocking
No1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026ARK lists no overclocking feature and the processor number has no K or X, which Intel's support article ties to unlocked chips. Stored as locked.5Maker product pageintel.com/content/www/us/en/support/articles/000038213/processors/intel-core-processors.htmlRead 15 October 2026Intel: overclocking is supported only for unlocked Core processors, identified by a K or X in the processor number. The 210H has neither.

Cache

L2 cache
7MB3Maker spec sheet (PDF)cdrdv2-public.intel.com/743844/743844-015.pdfRead 15 October 2026Section on hybrid cache: for the H Refresh line each P-core has 1.25 MB L2 and each group of 4 E-cores shares 2 MB L2. 4 P-cores at 1.25 MB plus one 2 MB E-core group is 7 MB. cpubenchmark.net lists the same figures for the 210H.4Spec databasecpubenchmark.net/cpu.phpRead 15 October 2026Page for the Intel Core 5 210H: L2 4 x 1280 KB on the performance cores and 1 x 2048 KB for the efficient-core cluster, which is 7 MB. L3 12 MB.
L3 cache
12MB1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 202612 MB Intel Smart Cache. The Total L2 Cache row is not on ARK.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026AMD technology. ARK lists only the 12 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
45W1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Processor Base Power 45 W.
Max turbo power
115W1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Maximum Turbo Power 115 W.
Configurable power range
Minimum35W1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Minimum Assured Power 35 W. ARK has no Maximum Assured Power row, so max_w is left out.
Max operating temperature
100°C1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Max Operating Temperature 100 C.

Memory

Memory support
Memory typeMax speed (MT/s)
DDR55,200
DDR43,200
LPDDR55,200
LPDDR5X5,200
LPDDR4X4,267
Source1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Memory Types: Up to DDR5 5200 MT/s, up to DDR4 3200 MT/s, up to LPDDR5/X 5200 MT/s and up to LPDDR4X 4267 MT/s. LPDDR5/X is stored as one lpddr5 row and one lpddr5x row at 5200. ARK names no module type, rank or configuration, so those keys are left out. Press coverage of the Core 200H group mentions DDR5-5600 SO-DIMM for some models. ARK states 5200 for this chip.
Max memory speed (official)
5,200MT/s
Memory channels
21Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Max # of Memory Channels: 2.
Memory bandwidth (claimed)
Not available
Max memory
96GB1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Max Memory Size (dependent on memory type): 96 GB.
ECC memory support
No1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026ECC Memory Supported: No.

Platform

Socket or package
BGA17441Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Sockets Supported: FCBGA1744. Stored without the FC prefix.
Compatible chipsets
Not available
CPU PCIe lanes
PCIe generationLanes
58
48
Source3Maker spec sheet (PDF)cdrdv2-public.intel.com/743844/743844-015.pdfRead 15 October 2026Section 7.1.1: the H and H Refresh processor line has one 8-lane (x8) port supporting PCIe gen 5.0 or below on certain SKUs and two 4-lane (x4) ports supporting gen 4.0 or below. ARK lists Microprocessor PCIe Revision Gen 5 for the 210H and Max # of PCI Express Lanes 28, which includes the 12 Gen 3 lanes of the chipset die in the package. Only the processor's own 8 Gen 5 and 8 Gen 4 lanes are stored.
CPU PCIe lanes in total
16
Highest PCIe generation
5
Native USB ports
Standard
Thunderbolt 4
Source1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Intel Thunderbolt 4: Yes. Intel gives no port count, so the row has no count.
Native USB4 or Thunderbolt
Yes

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026
Integrated GPU
Intel Graphics1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026GPU Name: Intel Graphics. The graphics row lists 48 Execution Units and no Xe-core count, so igpu_core_count is left out.
GPU cores
Not available
Max GPU clock
1,400MHz1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Graphics Max Dynamic Frequency 1.4 GHz.
Max displays
41Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026# of Displays Supported: 4.
DisplayPort version
1.4a1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1.
HDMI version
2.11Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1.
Hardware video encode
H.264, H.265 (HEVC)1Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026Encode/Decode rows: H.264 Yes, H.265 (HEVC) Yes, AV1 Decode Only. AV1 is therefore not an encode codec here.
Hardware video decode
H.264, H.265 (HEVC), AV11Maker product pageintel.com/content/www/us/en/products/sku/241652/intel-core-5-processor-210h-12m-cache-up-to-4-80-ghz/specifications.htmlRead 15 October 2026H.264 and H.265 (HEVC) are listed as Yes and AV1 as Decode Only. ARK has no VP9 row, so VP9 is left out.

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Variants

Each variant lists only what differs from the specs above.

Model number
FJ8071506058701
FJ8071506167401

Sources

We read 6 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 15 October 2026Backs 32 fields
  2. Read 15 October 2026Backs 2 fields
  3. Read 15 October 2026Backs 3 fields
  4. Read 15 October 2026Backs 1 field
  5. Read 15 October 2026Backs 1 field
  6. Read 15 October 2026Backs 3 fields

See a wrong value? Tell us and name the field.
