PC parts / CPUs

Intel Core 7 240H

IntelLaptop CPU

Core 7 240H

Released December 2024.3Press articlegeektopia.es/es/technology/2024/12/18/noticias/intel-anuncia-nuevos-procesadores-core-200h-para-portatiles-refritos-de-los-raptor-lake.htmlRead 14 October 2026ARK Launch Date Q4'24 and the 18 December 2024 listing. The first laptops with the chip came in early 2025. Laptop shipping dates for this chip were not checked. Last checked 14 October 2026.

Cores
10
Max boost clock
5.2GHz
L3 cache
24MB
Socket or package
BGA1744

39 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Core 200H3Press articlegeektopia.es/es/technology/2024/12/18/noticias/intel-anuncia-nuevos-procesadores-core-200h-para-portatiles-refritos-de-los-raptor-lake.htmlRead 14 October 2026The article names the group Core 200H, in Intel's Core Series 2. ARK's Product Collection reads Intel Core processors (Series 2).
Model numbers
FJ8071506058501, FJ80715061676012Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/ordering.htmlRead 14 October 2026Ordering codes FJ8071506058501 (spec code Q5ML) and FJ8071506167601 (spec code SRQ6T), both Tray, stepping J0, package FC-BGA16F. ARK lists no boxed product.
GTIN / EAN
Not available
Announced
18 December 20243Press articlegeektopia.es/es/technology/2024/12/18/noticias/intel-anuncia-nuevos-procesadores-core-200h-para-portatiles-refritos-de-los-raptor-lake.htmlRead 14 October 2026Geektopia, 18 December 2024, via VideoCardz: Intel released the Core 200H processors for laptops without waiting for CES 2025. Intel gave no press release and listed them on its site. The article lists the Core 7 240H as 6P+4E with up to 5.2 GHz and 24 MB cache.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Marketing Status: Launched. Launch Date: Q4'24. Product Collection: Intel Core processors (Series 2). Vertical Segment: Mobile.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Vertical Segment row reads Mobile.
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Instruction Set: 64-bit, with Intel 64 listed as Yes. Intel's 64-bit processors are x86-64.
Codename
Raptor Lake1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Code Name row reads Products formerly Raptor Lake. Press calls it a Raptor Lake-H refresh and a rebadge of the Core i7-13620H.
CPU process (as published)
Intel 71Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Lithography row: Intel 7.
CPU process node
10nm1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Intel 7 is stored as 10 nm, the nm class of Intel 7. Intel prints no nm figure.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Instruction Set Extensions lists Intel SSE4.1, SSE4.2 and AVX2 only.

Cores and clocks

Core configuration
Core typeCountBase clock (GHz)Max clock (GHz)
Performance62.55.2
Efficiency41.84
Source1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026# of Performance-cores 6 with base 2.5 GHz and Max Turbo 5.2 GHz. # of Efficient-cores 4 with base 1.8 GHz and Max Turbo 4 GHz. Low Power Efficient-cores 0. Total cores 10. ARK names no core architecture. Press calls the P-cores both Raptor Cove and Golden Cove, so core_name is left out.
Cores
10
Cores labelled performance
6
Cores labelled efficiency
4
Threads
161Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Total Threads 16. Intel Hyper-Threading Technology is Yes.
Max boost clock
5.2GHz1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Max Turbo Frequency 5.2 GHz, the same as the Performance-core Max Turbo Frequency.
Unlocked for overclocking
Not available

Cache

L2 cache
Not available
L3 cache
24MB1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 202624 MB Intel Smart Cache. The Total L2 Cache row is empty on ARK.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026AMD technology. ARK lists only the 24 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
45W1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Processor Base Power 45 W.
Max turbo power
115W1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Maximum Turbo Power 115 W.
Configurable power range
Minimum35W1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Minimum Assured Power 35 W. ARK has no Maximum Assured Power row, so max_w is left out.
Max operating temperature
100°C1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Max Operating Temperature 100 C.

Memory

Memory support
Memory typeMax speed (MT/s)
DDR56,400
DDR43,200
LPDDR56,400
LPDDR5X6,400
LPDDR4X4,267
Source1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Memory Types: Up to DDR5 6400 MT/s, up to DDR4 3200 MT/s, up to LPDDR5/X 6400 MT/s and up to LPDDR4X 4267 MT/s. LPDDR5/X is stored as one lpddr5 row and one lpddr5x row at 6400. ARK names no module type, rank or configuration, so those keys are left out. Notebookcheck's launch coverage says DDR5 SODIMM stops at 5600, which ARK does not state.
Max memory speed (official)
6,400MT/s
Memory channels
21Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Max # of Memory Channels: 2.
Memory bandwidth (claimed)
Not available
Max memory
96GB1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Max Memory Size (dependent on memory type): 96 GB.
ECC memory support
No1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026ECC Memory Supported: No.

Platform

Socket or package
BGA17441Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Sockets Supported: FCBGA1744. Stored without the FC prefix.
Compatible chipsets
Not available
CPU PCIe lanes
Not available
CPU PCIe lanes in total
Not available
Highest PCIe generation
Not available
Native USB ports
Standard
Thunderbolt 4
Source1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Intel Thunderbolt 4: Yes. Intel gives no port count, so the row has no count.
Native USB4 or Thunderbolt
Yes

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026
Integrated GPU
Intel Graphics1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026GPU Name: Intel Graphics. The graphics row lists 64 Execution Units and no Xe-core count.
GPU cores
Not available
Max GPU clock
1,550MHz1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Graphics Max Dynamic Frequency 1.55 GHz.
Max displays
41Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026# of Displays Supported: 4.
DisplayPort version
1.4a1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1.
HDMI version
2.11Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1.
Hardware video encode
H.264, H.265 (HEVC)1Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026Encode/Decode rows: H.264 Yes, H.265 (HEVC) Yes, AV1 Decode Only. AV1 is therefore not an encode codec here.
Hardware video decode
H.264, H.265 (HEVC), AV11Maker product pageintel.com/content/www/us/en/products/sku/241653/intel-core-7-processor-240h-24m-cache-up-to-5-20-ghz/specifications.htmlRead 14 October 2026H.264 and H.265 (HEVC) are listed as Yes and AV1 as Decode Only. ARK has no VP9 row, so VP9 is left out.

NPU

We could not find any of these 2 fields. Show them
NPU performance
Not available
Total AI performance
Not available

Measured performance

We could not find any of these 7 fields. Show them
Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
Not available
Geekbench 6 multi-core
Not available
Game frame rates
Not available

Measured power and temperature

We could not find any of these 5 fields. Show them
CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
Not available
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Variants

Each variant lists only what differs from the specs above.

Model number
FJ8071506058501
FJ8071506167601

Sources

We read 3 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 14 October 2026Backs 31 fields
  2. Read 14 October 2026Backs 2 fields
  3. Read 14 October 2026Backs 3 fields

See a wrong value? Tell us and name the field.
