PC parts / CPUs

Intel Core Ultra 9 275HX

IntelLaptop CPU

Core Ultra 9 275HX

Released March 2025.6Press articletomshardware.com/laptops/gaming-laptops/nvidia-confirms-rtx-50-series-laptops-will-be-available-for-pre-order-starting-february-25Read 14 October 2026Tom's Hardware, February 2025: RTX 50 laptops go up for pre-order on 25 February with retail launch in March, and it names laptops with the Core Ultra 9 275HX, the Asus ROG Strix Scar 18 at 4199 USD and the HP Omen Max 16 at 2699 USD. ARK lists Launch Date Q1'25 and Intel's CES release said systems come in the first half of 2025. Last checked 14 October 2026.

Cores
24
Max boost clock
5.4GHz
L3 cache
36MB
Socket or package
BGA2114

49 of 74 fields known.

Compare with another CPUDownload JSONDownload CSVGet it from the API

All specs

SourceCalculated

General

Series
Core Ultra 200HX3Press releaseintel.com/content/www/us/en/newsroom/news/2025-ces-client-computing-news.htmlRead 14 October 2026Intel calls the family the Core Ultra 200HX series. Its overclocking text says select 200HX SKUs get overclocking and XMP support for DDR5 SODIMM overclocking. It does not say which SKUs, so cpu_unlocked is left out.
Model numbers
AC80768064D0, AC80768067E22Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/ordering.htmlRead 14 October 2026Ordering codes AC80768064D0 (spec code Q6S9) and AC80768067E2 (spec code SRVFK), both Tray, stepping B0. ARK lists no boxed product.
GTIN / EAN
Not available
Announced
6 January 20253Press releaseintel.com/content/www/us/en/newsroom/news/2025-ces-client-computing-news.htmlRead 14 October 2026Intel newsroom release dated 6 January 2025 (CES, Las Vegas) introduces the Core Ultra 200HX and H series mobile processors. It names no 275HX and gives no price.
Status
Available1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Marketing Status: Launched. Launch Date: Q1'25. Vertical Segment: Mobile.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Laptop1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Vertical Segment row reads Mobile.
Instruction set
x86-641Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Instruction Set: 64-bit.
Codename
Arrow Lake1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Code Name row reads Products formerly Arrow Lake.
CPU process (as published)
TSMC N3B1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026CPU Lithography row: TSMC N3B.
CPU process node
3nm1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026TSMC N3B is stored as 3 nm, as on the other Arrow Lake products. Intel prints no nm figure.
AVX-512
No1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Instruction Set Extensions lists Intel SSE4.1, SSE4.2 and AVX2 only.

Cores and clocks

Core configuration
Core typeCountCoreBase clock (GHz)Max clock (GHz)
Performance8Lion Cove2.75.4
Efficiency16Skymont2.14.6
Source1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026# of Performance-cores 8 with base 2.7 GHz and Max Turbo 5.4 GHz. # of Efficient-cores 16 with base 2.1 GHz and Max Turbo 4.6 GHz. Low-power Efficient-cores 0. Core names are not on ARK and come from the Tom's Hardware launch article.4Press articletomshardware.com/pc-components/cpus/intel-launches-arrow-lake-mobile-family-with-core-ultra-200hx-and-200h-processorsRead 14 October 2026Tom's Hardware, 6 January 2025: the 200HX chips use the Lion Cove P-core and Skymont E-core microarchitectures. Its table lists the 275HX with 24 cores (8+16), 5.4 GHz P-core turbo and 55 W base and 160 W turbo power. The table's E-core base clock of 1.9 GHz differs from ARK's 2.1 GHz, so ARK is used.
Cores
24
Cores labelled performance
8
Cores labelled efficiency
16
Threads
241Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Total Threads 24. Intel Hyper-Threading Technology is No. Club386 writes 32 threads in its laptop reviews, which does not match ARK.
Max boost clock
5.4GHz1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Max Turbo Frequency 5.4 GHz, the same as the Performance-core Max Turbo Frequency.
Unlocked for overclocking
Not available

Cache

L2 cache
40MB1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Total L2 Cache 40 MB.
L3 cache
36MB1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 202636 MB Intel Smart Cache.
AMD 3D V-Cache
No1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026AMD technology. ARK lists only the 36 MB Smart Cache and no stacked cache.

Power and thermals

Base power (TDP)
55W1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Processor Base Power 55 W.
Max turbo power
160W1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Maximum Turbo Power 160 W.
Configurable power range
Minimum45W1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Minimum Assured Power 45 W. ARK has no Maximum Assured Power row, so max_w is left out.
Max operating temperature
105°C1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Max Operating Temperature 105 C.

Memory

Memory support
Memory typeModule typeMax speed (MT/s)
DDR5SO-DIMM6,400
Source1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Memory Types: Up to DDR5 6400 MT/s. ARK states no module type, rank or LPDDR option for this chip. The SODIMM module type comes from Intel's CES 2025 release and Wccftech. No module configuration is stated, so config is left out.5Press articlewccftech.com/intel-core-ultra-200hx-core-ultra-200h-arrow-lake-cpus-debut-high-end-gaming-premium-laptops/ampRead 14 October 2026Wccftech, January 2025, from Intel's briefing: the 200HX CPUs support standard DDR5-6400 SO-DIMMs, or OEMs can use LPDDR5X or LP5/5x CAMM2. ARK lists only DDR5 for this chip, so only the DDR5 SODIMM row is stored.
Max memory speed (official)
6,400MT/s
Memory channels
21Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Max # of Memory Channels: 2.
Memory bandwidth (claimed)
Not available
Max memory
256GB1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Max Memory Size (dependent on memory type): 256 GB. Tom's Hardware's launch table (from Intel slides, January 2025) lists 96 GB for DDR5 on the HX chips and Wccftech writes 192 GB. ARK is the maker's current page and is used.
ECC memory support
No1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026ECC Memory Supported: No.

Platform

Socket or package
BGA21141Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Sockets Supported: FCBGA2114. Stored without the FC prefix.
Compatible chipsets
Not available
CPU PCIe lanes
PCIe generationLanes
520
44
Source1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Max # of PCI Express Lanes is 24 and PCI Express Revision is 5.0 and 4.0, with configurations 1x16+2x4, 2x8+2x4 and 1x8+4x4. ARK gives no per-generation split. The split of 20 Gen 5 and 4 Gen 4 comes from the 4 Gen 5 and 4 Gen 4 SSD lanes in the launch coverage (Wccftech, Notebookcheck) plus the 16 graphics lanes, which sum to 24.5Press articlewccftech.com/intel-core-ultra-200hx-core-ultra-200h-arrow-lake-cpus-debut-high-end-gaming-premium-laptops/ampRead 14 October 2026All Intel Core Ultra 200HX CPUs feature 4 PCIe Gen5 and 4 PCIe Gen4 lanes for SSDs. With ARK's 24 total lanes, the remaining 16 are the graphics lanes, which run at Gen 5.
CPU PCIe lanes in total
24
Highest PCIe generation
5
Native USB ports
Standard
Thunderbolt 4
Source1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Intel Thunderbolt 4: Yes. Intel gives no port count, so the row has no count.
Native USB4 or Thunderbolt
Yes

Integrated graphics

Integrated graphics
Yes1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026
Integrated GPU
Intel Graphics1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026GPU Name: Intel Graphics.
GPU cores
41Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Xe-cores: 4.
Max GPU clock
1,900MHz1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Graphics Max Dynamic Frequency 1.9 GHz. Graphics Base Frequency is 300 MHz.
Max displays
41Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026# of Displays Supported: 4.
DisplayPort version
2.1 UHBR201Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Graphics Output: eDP 1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL.
HDMI version
2.1 FRL1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Graphics Output: eDP 1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL.
Hardware video encode
H.264, H.265 (HEVC), AV11Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026H.264, H.265 (HEVC) and AV1 encode and decode are all listed as Yes.
Hardware video decode
H.264, H.265 (HEVC), AV11Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026H.264, H.265 (HEVC) and AV1 are listed. ARK has no VP9 row, so VP9 is left out.

NPU

NPU performance
13TOPS1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026NPU Peak TOPS (Int8): 13.
Total AI performance
36TOPS1Maker product pageintel.com/content/www/us/en/products/sku/242293/intel-core-ultra-9-processor-275hx-36m-cache-up-to-5-40-ghz/specifications.htmlRead 14 October 2026Overall Peak TOPS (Int8): 36. GPU Peak TOPS (Int8) is 8.

Measured performance

Cinebench 2024 single-core
Not available
Cinebench 2024 multi-core
Not available
Cinebench 2026 single-thread
Not available
Cinebench 2026 multi-core
Not available
Geekbench 6 single-core
2,852points7Reviewclub386.com/gigabyte-aorus-master-18-am8h-reviewRead 14 October 2026Club386 review of 5 May 2025. Tested in the Gigabyte Aorus Master 18 BZH (RTX 5090 Mobile, 32 GB DDR5-4800) in its out-of-the-box Balance Mode power profile, with settings unchanged. Gigabyte gives the 275HX up to 95 W. Geekbench 6 ST 2,852. The review does not mention Intel Binary Optimization. The result is for this laptop and its 95 W limit. Other laptops set other limits, so the result differs from laptop to laptop.
Geekbench 6 multi-core
18,112points7Reviewclub386.com/gigabyte-aorus-master-18-am8h-reviewRead 14 October 2026Same laptop and Balance Mode, up to 95 W. Geekbench 6 MT 18,112. The review compares it with the Core i9-14900HX in the Geekbench 6 database.
Game frame rates
Not available

Measured power and temperature

CPU power in multi-thread load (measured)
Not available
CPU power while gaming (measured)
Not available
CPU power at idle (measured)
Not available
CPU temperature in stress test
88°C7Reviewclub386.com/gigabyte-aorus-master-18-am8h-reviewRead 14 October 2026Vitals table, Load column: CPU temperature 88 C under Cinebench 2024, in the same laptop and Balance Mode with the laptop's own cooling and the Performance fan profile. Idle was 50 C. The review gives no room temperature.
All-core clock in stress test
Not available

In the box

We could not find any of these 2 fields. Show them
Cooler in the box
Not available
Included cooler
Not available

Warranty

We could not find any of these 1 fields. Show them
Manufacturer warranty (source market)
Not available

Compare with

Pick a CPU to see both side by side. Differences are marked yellow.

More CPU comparisons

Variants

Each variant lists only what differs from the specs above.

Model number
AC80768064D0
AC80768067E2

Sources

We read 7 sources for this CPU. The numbers match the markers in the sheet.

  1. Read 14 October 2026Backs 36 fields
  2. Read 14 October 2026Backs 2 fields
  3. Read 14 October 2026Backs 2 fields
  4. Read 14 October 2026Backs 1 field
  5. Read 14 October 2026Backs 2 fields
  6. Read 14 October 2026Backs 1 field
  7. Read 14 October 2026Backs 3 fields

See a wrong value? Tell us and name the field.
