Gaming / Keyboards

KeychronGaming keyboard

K3 HE

Released March 2026.2 Last checked 15 October 2026.

Form factor: 75 %
Switch sensing technology: Magnetic (Hall effect)
Connections: USB (wired), 2.4 GHz, Bluetooth
Max polling rate: 1,000Hz

91 of 164 fields known.

Compare with another keyboard Download JSON Download CSV Get it from the API

At a glance

Weight
575g1
Lower than 78% of other keyboards. Lower is better.

All specs

SourceCalculatedHide missing

General

Series: K HE1
Model numbers: K3H-F1, K3H-F1-BO, K3H-F1-DE, K3H-F1-UK, K3H-Q11
GTIN / EAN: 4894979045614, 4894979067913, 4894979067906, 4894979066121, 48949790456212
Announced: February 20267
Status: Available1
Predecessor: Not available
Successor: Not available
Launch price (US): $119.991 5
Launch price (EU): Not available
Markets: Not available
Colours: Black, White1
Segment: Gaming1
Sold as: Complete1

Layout

Form factor: 75 %1
Layout standard: ANSI, ISO1
Regional layouts: ANSI, ISO-Nordic, ISO-German, ISO-UK1
Keys in regional layout: 843
Key legends for: macOS, Windows1
Numpad: No1
Function row: Yes1
Dedicated arrow keys: Yes1
Navigation keys: Compact1
Key stagger: Row-staggered1
Bottom row: Not available
Low profile: Yes1

Switches

Switch sensing technology: Magnetic (Hall effect)1
Switch feel: Linear6
Switch maker: Keychron1
Switch models: Keychron Ultra-Fast Lime Low-Profile Magnetic Switch1
Switch stem: Not available
Actuation force: Not available
Bottom-out force: Not available
Tactile bump force: Not available
Actuation point: Not available
Total travel: Not available
Rated keystrokes: Not available
Factory-lubed switches: Yes1
Adjustable actuation: Yes1
Actuation range: Min0.2Max2.9mm1
Actuation step: 0.1mm1
Per-key actuation: Yes1
Rapid trigger: Yes1
Minimum rapid trigger movement: 0.1mm1
Multi-action keys: Yes1
SOCD handling: Yes1
Analog input: Yes1
Hot-swap sockets: Magnetic1
Compatible switches: Keychron Ultra-Fast Lime Low-Profile magnetic switch only1
Stabilizers: Plate-mounted1
Factory-lubed stabilizers: Not available

Keycaps

Keycap material: PBT1
Legend method: Doubleshot1
Keycap profile: Low profile1
Keycap thickness: Not available
Shine-through legends: No1

Performance

Polling rate per connection: Connection Polling rate (Hz) Receiver or adapter
USB (wired) 1,000 Not available
2.4 GHz 1,000 Included Type-A 2.4 GHz receiver
Bluetooth 125 Not available
Source1
Max polling rate: 1,000Hz
Polling rate (wired): 1,000Hz
Polling rate (2.4 GHz): 1,000Hz
Polling rate (Bluetooth): 125Hz
Scan rate: Not available
Input latency (claimed): Not available
Key rollover per connection: Connection Rollover
USB (wired) NKRO
2.4 GHz NKRO
Bluetooth NKRO
Source1
Anti-ghosting: Not available
Adjustable debounce: Not available
Minimum debounce: Not available

Connection	Polling rate (Hz)	Receiver or adapter
USB (wired)	1,000	Not available
2.4 GHz	1,000	Included Type-A 2.4 GHz receiver
Bluetooth	125	Not available

Connection	Rollover
USB (wired)	NKRO
2.4 GHz	NKRO
Bluetooth	NKRO

Measured

We could not find any of these 7 fields. Show them

Latency per connection (measured): Not available
Actuation point (measured): Not available
Total travel (measured): Not available
Operating force (measured): Not available
Typing noise (measured): Not available
Battery life (measured): Not available
Weight (measured): Not available

Connectivity

Connections: USB (wired), 2.4 GHz, Bluetooth1
Wireless technology: Not available
Bluetooth: 5.21
Bluetooth device slots: 31
Devices it can switch between: Not available
Device switching: Keys3
Receiver connector: USB-A1
Receiver storage in keyboard: Not available
Receiver shared with other devices: Not available
Wireless range: 10m3
Detachable cable: Yes3
Port on keyboard: USB-C1
Cable plug: USB-C6
Cable: Braided6
Cable length: Not available
USB passthrough: Not available
Works with: Windows, macOS, Linux1
Consoles: Not available

Battery

Battery type: Li-Po1
Number of batteries: Not available
Battery capacity: 2,600mAh1
User-replaceable battery: Not available
Battery life per mode (claimed): Hours (h)
55
Source1
Longest battery life (claimed): 55h
Battery life, lighting off: Not available
Battery life, lighting on: Not available
Battery life, backlight on (claimed): Not available
Battery life, backlight off (claimed): Not available
Charging port: USB-C1
Full charge time: 228min3
Quick charge: Not available
Use while charging: Yes3
Solar charging: Not available
Battery indicator: LED3

Hours (h)
55

Build

Case material: Aluminum and wood frame with ABS plastic bottom case1
Plate material: Aluminium1
Mount style: Tray1
Flex cuts in PCB: Not available
Sound dampening: Case foam, Silicone bottom, Foam, position not stated, Other1
Typing angles: 2°, 4.5°, 7.5°1
Spill resistant: Not available
IP rating: Not available

Lighting

Backlight: RGB per key1
LED position: North-facing1
Lighting zones: Not available
Brightness levels: Not available
Side or underglow lighting: Not available
Lighting sensors: Not available
Lighting sync: Not available

Controls

Media keys: Fn layer3
Separate media buttons: Not available
Volume control: Not available
Knobs: 03
Programmable knob: Not available
Knob press: Not available
Separate macro keys: Not available
Built-in screen: Not available
Touchpad: Not available
Fingerprint reader: Not available
OS mode switch: Switch3
Windows key lock: Not available

Software

Software: Keychron Launcher1
Software runs on: Web1
Open firmware: QMK1
Onboard memory: Not available
Onboard profiles: Not available
Macros: Yes1
Macros stored onboard: Not available
Key remapping: Yes1
Layers: 43
User firmware updates: Yes3

Ergonomics

Wrist rest: None3
Wrist rest material: Not available
Tenting: Not available
Tenting angles: Not available

Dimensions and weight

Front and side, drawn to scale.

Dimensions: Width318.62Depth126Height25.4Front height22mm(12.5 × 5 × 1 × 0.9 in)1
Dimensions with wrist rest: Not available
Keyboard weight: 575g(1.3 lb)1
Weight including wrist rest: Not available
Box dimensions: Not available
Box weight: Not available

Certifications

We could not find any of these 2 fields. Show them

Platform certifications: Not available
Other certifications: Not available

In the box

In the box: 1x Fully Assembled Keyboard, 1x Type-C Cable, 1x Type-A to Type-C Adapter, 1x Type-A 2.4GHz Receiver, 1x Extension Adapter For Receiver, 1x Keycap & Switch Puller, 1x Screwdriver3
Cables included: Type Count
Type-C cable 1
Source3
Spare switches: Not available

Type	Count
Type-C cable	1

Warranty

Manufacturer warranty (source market): 1year4

Compare with

Pick a keyboard to see both side by side. Differences are marked yellow.

More keyboard comparisons

Variants

Each variant lists only what differs from the specs above.

Model number	GTIN	Colours	Layout standard	Regional layouts	Keys in regional layout
K3H-F1	4894979045614	Black	ANSI	ANSI	84
K3H-Q1	4894979045621	White	ANSI	ANSI	84
K3H-F1-BO	4894979067913	Black	ISO	ISO-Nordic	Not available
K3H-F1-DE	4894979067906	Black	ISO	ISO-German	Not available
K3H-F1-UK	4894979066121	Black	ISO	ISO-UK	Not available
