Motherboards / Compare

ASRock Z890 LiveMixer WiFi vs ASRock Z890 Riptide WiFi

A

Product A: ASRock

Z890 LiveMixer WiFi

62 of 78 known

Change ASRock Z890 LiveMixer WiFi

Compare the ASRock Z890 Riptide WiFi with

Search motherboards

B

Product B: ASRock

Z890 Riptide WiFi

65 of 78 known

Change ASRock Z890 Riptide WiFi

Compare the ASRock Z890 LiveMixer WiFi with

Search motherboards

All 78 fields

Every value links to where we found it.

Only differences

AASRock Z890 LiveMixer WiFi

BASRock Z890 Riptide WiFi

General

3 of 9 differ

Series

LiveMixer1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026The manual names the board Z890 LiveMixer WiFi. LiveMixer is the ASRock line for content creators.

Phantom Gaming7Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026The review title calls the board ASRock Phantom Gaming Z890 RIPTIDE WiFi.

Model numbersiMaker identifiers for this exact model and its listed variants. Excludes sibling models and other generations.

Z890 LiveMixer WiFi, 90-MXBPE0-A0UAYZ3Retailer pageevetech.co.za/asrock-z890-livemixer-intel-motherboard/best-deal/23134Read 15 October 2026Model No: ASROCK 90-MXBPE0-A0UAYZ.4Retailer pageparadigit.ie/asrock-z890-livemixer-wifi/21654355/productRead 15 October 2026Product number manufacturer: 90-MXBPE0-A0UAYZ.8Spec databasehinta.fi/4950255/asrock-z890-livemixer-wifi/tiedotRead 15 October 2026Manufacturer product codes: 90-MXBPE0-A0UAYZ and Z890 LIVEMIXER WIFI.

Z890 Riptide WiFi, 90-MXBPB0-A0UAYZ1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Cover and specification chapter name the board Z890 Riptide WiFi. The Z890M Riptide WiFi is a separate micro ATX board.5Retailer pagescan.co.uk/products/asrock-z890-riptide-wifi-intel-z890-s-1851-ddr5-pcie-50-5x-m2-25gbe-wifi7-tb4-atxRead 15 October 2026Model number 90-MXBPB0-A0UAYZ.

GTIN / EAN

47104839497158Spec databasehinta.fi/4950255/asrock-z890-livemixer-wifi/tiedotRead 15 October 2026GTIN / EAN: 4710483949715. The EAN is also on alltron.ch and custompc.com.cy.9Retailer pagecustompc.com.cy/components/motherboards/intel-motherboards/asrock-z890-livemixer-wifi-intel-z890-mainboard-socket-lga-1851-intel-z890-atx-ddr5Read 15 October 2026Product feed: gtin13 4710483949715.

47104839496473Retailer pageshop.sumanet.cz/z890-riptide-wifi-asrock-mb-sc-lga1851-z890-riptide-wifi-intel-z890-4xddr5-1xhdmi-2xthunderbolt-wi-fiRead 15 October 2026GTIN (EAN) 4710483949647.5Retailer pagescan.co.uk/products/asrock-z890-riptide-wifi-intel-z890-s-1851-ddr5-pcie-50-5x-m2-25gbe-wifi7-tb4-atxRead 15 October 2026GTIN 4710483949647. Komputronik and Comfeel list the same EAN.6Retailer pagekomputronik.pl/product/931314/plyta-glowna-asrock-z890-riptide-wifi.htmlRead 15 October 2026EAN 4710483949647, manufacturer code Z890 Riptide WiFi.

AnnouncediThe maker's first announcement of this model. This is separate from first retail availability.

Not available

Not available

Status

Available8Spec databasehinta.fi/4950255/asrock-z890-livemixer-wifi/tiedotRead 15 October 2026Listed at 250.90 EUR with shops on 2026-10-15.

Available5Retailer pagescan.co.uk/products/asrock-z890-riptide-wifi-intel-z890-s-1851-ddr5-pcie-50-5x-m2-25gbe-wifi7-tb4-atxRead 15 October 2026Scan UK lists the board in stock with delivery on 2026-10-16.

PredecessoriThe model this one directly replaced, in the same line, tier and size, as the maker or a trusted review names it.

Not available

Not available

SuccessoriThe model that directly replaced this one, in the same line, tier and size. A revision such as a Slim or OLED model does not count when a next generation exists.

Not available

Not available

Launch price (US)iThe maker's US launch MSRP for the stated configuration, excluding tax. Current store prices and later discounts do not qualify.

$239.9911Press articlewccftech.com/intel-z890-motherboards-available-pre-order-prices-starting-199-us-asus-asrock-gigabyte-msi/ampRead 15 October 2026Article of 2024-10-10 lists ASRock Z890 LiveMixer WiFi at 239.99 USD in US retail pre-order listings, for the Core Ultra 200S launch. It is a US retail listing and not an ASRock statement of MSRP. Tax is not included in a US price.

$299.999Press articlewccftech.com/intel-z890-motherboards-available-pre-order-prices-starting-199-us-asus-asrock-gigabyte-msi/ampRead 15 October 2026Article of 2024-10-10 lists ASRock Z890 Riptide WiFi at 299.99 USD in US retail pre-order listings (Newegg), separate from the Z890M Riptide WiFi. It is a US retail listing and not an ASRock statement of MSRP. Tax is not included in a US price. The FPS Review writes $299 and pcinq about $300.

Launch price (EU)iThe maker's euro launch price for the stated configuration, including VAT as published. Current store prices and later discounts do not qualify.

Not available

Not available

MarketsiISO country or region codes where this exact model or variant is sold. A source page's language does not establish availability.

Not available

Not available

ColoursiThe maker's own colour names

Not available

Not available

SegmentiThe maker's own product category, e.g. ASUS ProArt is Creator. It is not assigned from price or features. Maker lines that are not gaming, creator or workstation lines, such as ASUS PRIME, MSI PRO and ASRock Pro, are mainstream.

Creator2Retailer pageldlc.com/en/product/PB00649733.htmlRead 15 October 2026The overview says the board is part of ASRock's LiveMixer range, designed for the needs of content creators.4Retailer pageparadigit.ie/asrock-z890-livemixer-wifi/21654355/productRead 15 October 2026Copy of ASRock's text: the LiveMixer series is crafted with the needs of modern content creators in mind.

Gaming7Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026Phantom Gaming is ASRock's gaming line, and the review calls the Riptide more gaming-centric.

Board revisioniThe maker's revision name, e.g. rev. 1.1, for variant rows of revisions that keep the board's name and model number. Leave it out when the maker names no revision.

Not available

Not available

Platform

0 of 4 differ

CPU socketiSocket name without spaces, e.g. AM5 or LGA1851.

LGA18511Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: Intel Core Ultra Processors (Series 2) (LGA1851RL-ILM).

LGA18511Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026

ChipsetiChipset with its brand and without the word chipset, e.g. AMD B850, AMD X870E or Intel Z890. Same form as desktop PCs and as compatible chipsets on CPUs.

Intel Z8901Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: Intel Z890.

Intel Z8901Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026

Supported processorsiProcessor series the maker lists for the board, one item per series in the chip maker's name. BIOS updates can add series later.

Intel Core Ultra (Series 2)1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2, CPU: Supports Intel Core Ultra Processors (Series 2). Read on 2026-10-15. BIOS updates can add series later.

Intel Core Ultra (Series 2)1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Specifications, page 2: Intel Core Ultra Processors (Series 2) in the LGA1851RL-ILM socket.

CPU overclockingiThe board allows multiplier overclocking of an unlocked CPU. Memory overclocking alone does not count.

Yes12Maker product pageintel.com/content/www/us/en/products/sku/237777/intel-z890-chipset/specifications.htmlRead 15 October 2026Intel Z890 chipset specifications: Supports Overclocking: IA, BCLK, Memory. This is the chip maker's chipset feature, not a board spec.

Yes10Maker product pageintel.com/content/www/us/en/products/sku/237777/intel-z890-chipset/specifications.htmlRead 15 October 2026Intel's Z890 chipset page lists Supports Overclocking: IA, BCLK, Memory. The page blocks agents, so the row was read in a search result. This is the chip maker's page, not the board maker's. Intel's 800 series chipset brief marks IA and BCLK overclocking Yes for Z890 only.

Board

2 of 5 differ

Form factoriThe maker's stated board standard. Other covers sizes such as XL-ATX or Mini-DTX.

ATX1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2 and the title of chapter 2: ATX Form Factor.

ATX1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Specifications, page 2: ATX form factor, 2oz copper PCB.

Board dimensionsiSize of the board itself. Height runs along the rear I/O edge, as the board stands in a tower case. ATX is 244 mm wide and 305 mm high. Micro ATX is 244 mm high and up to 244 mm wide. A size with a cover that reaches past the board, as NZXT prints, is not used when the maker also states the board size.

Width244Height305mm(9.6 × 12 in)2Retailer pageldlc.com/en/product/PB00649733.htmlRead 15 October 2026Specifications: motherboard format ATX, length 305 mm, width 244 mm.

Width244Height305mm(9.6 × 12 in)3Retailer pageshop.sumanet.cz/z890-riptide-wifi-asrock-mb-sc-lga1851-z890-riptide-wifi-intel-z890-4xddr5-1xhdmi-2xthunderbolt-wi-fiRead 15 October 2026ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm. Komputronik lists 244 mm wide and 305 mm high.5Retailer pagescan.co.uk/products/asrock-z890-riptide-wifi-intel-z890-s-1851-ddr5-pcie-50-5x-m2-25gbe-wifi7-tb4-atxRead 15 October 2026ATX, 305 x 244 mm.6Retailer pagekomputronik.pl/product/931314/plyta-glowna-asrock-z890-riptide-wifi.htmlRead 15 October 2026Width 244 mm and height 305 mm.

PCB layersiCopper layers in the circuit board as published.

Not available

87Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026The PCB is constructed to include 2 oz copper in a total of 8 layers.

Back-connect designiPower, fan and front-panel connectors sit on the back of the board to hide the cables, e.g. ASUS BTF, MSI Project Zero or GIGABYTE Stealth. It needs a case made for it.

No1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026The section 1.3 layout and the connector list show the usual front-side power, fan and USB connectors.

No1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026The layout on page 8 shows the usual front-side power, fan and USB connectors. The board is not a back-connect design.

RGB lighting on the boardiLEDs on the board itself. Headers for external lighting are counted under Internal connectors. True only when the maker's spec or feature list names lighting on the board. A single small LED that a reviewer sees does not count.

Not available

Yes7Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026RGB LEDs along the bottom border of the secondary heatsink and the right chipset margin, controlled by Polychrome Sync in the UEFI or in software.

Power delivery

1 of 6 differ

Power stage layoutiAs the maker publishes it, e.g. 18+2+2. The first number is the CPU core (Vcore) rail. Makers group the other rails differently, so compare the first number. Doubled or teamed stages are written as the maker prints them, such as MSI's 12+2+1 Duet Rail. A review's count of real phases goes in the source note.

18+1+1+1+12Retailer pageldlc.com/en/product/PB00649733.htmlRead 15 October 2026Copy of ASRock's feature text: 18+1+1+1+1-phase 80A SPS power supply for VCore+GT+SA.3Retailer pageevetech.co.za/asrock-z890-livemixer-intel-motherboard/best-deal/23134Read 15 October 2026Features and FAQ: 18+1+1+1+1 power phase with SPS Dr.MOS stages.4Retailer pageparadigit.ie/asrock-z890-livemixer-wifi/21654355/productRead 15 October 2026Copy of ASRock's text: 18+1+1+1+1 Power Phase Design with SPS (Smart Power Stage) Dr.MOS.6Retailer pagemultitronic.fi/en/products/4408928Read 15 October 2026Copy of ASRock's text: 18+1+1+1+1 Power Phase Design with SPS Dr.MOS.7Spec databasemaxmybuild.com/motherboards/asrock-z890-livemixer-wifiRead 15 October 2026Phase config: 2x9+1+1+1+1 with 80A SPS. This is the same layout as ASRock's 18+1+1+1+1.10Press articleascii.jp/elem/000/004/230/4230242/2Read 15 October 2026Text (Japanese): an 18+1+1 phase circuit with 80A SPS. The article writes 18+1+1, while ASRock's text and the retailers write 18+1+1+1+1.

18+1+1+1+13Retailer pageshop.sumanet.cz/z890-riptide-wifi-asrock-mb-sc-lga1851-z890-riptide-wifi-intel-z890-4xddr5-1xhdmi-2xthunderbolt-wi-fiRead 15 October 2026Copy of ASRock's text: 18+1+1+1+1 Power Phase, 80A SPS for VCore+GT+SA with Enlarged Heatsink Armor. The Z890M Riptide WiFi has 16+1+1+1+1. The FPS Review writes 18+1+1.4Retailer pagefirstshop.hu/asrock-z890-riptide-wifi-p225719Read 15 October 202618+1+1+1+1 Power Phase, 80A SPS for VCore+GT+SA with Enlarged Heatsink Armor.

CPU core (Vcore) power stagesiPower stages on the Vcore rail. Makers call them phases or power stages. A doubled design has more stages than controller phases. Use the first number of the maker's layout, such as 14 for MSI's 14+2+1 Duet Rail. A review's different count goes in the source note.

182Retailer pageldlc.com/en/product/PB00649733.htmlRead 15 October 2026The same text names 18 phases with 80A SPS for VCore, GT and SA.7Spec databasemaxmybuild.com/motherboards/asrock-z890-livemixer-wifiRead 15 October 20262x9 means 9 phases doubled into 18 Vcore power stages.

183Retailer pageshop.sumanet.cz/z890-riptide-wifi-asrock-mb-sc-lga1851-z890-riptide-wifi-intel-z890-4xddr5-1xhdmi-2xthunderbolt-wi-fiRead 15 October 2026The same text names 18 phases with 80A SPS for VCore, GT and SA. pcinq confirms 18 core MOSFETs in 9 controller phases.8Reviewpcinq.com/asrock-z890-riptide-wifi-reviewRead 15 October 202620 (18+1+1+1+1) phases. The 18 CPU-core MOSFETs are paired so they use nine controller phases, MP87681 parts.

Vcore power stage ratingiCurrent rating of each Vcore power stage. Only a figure the maker or a copy of the maker's text states. A review's reading of the chip markings is not enough.

80A2Retailer pageldlc.com/en/product/PB00649733.htmlRead 15 October 202680A SPS for VCore+GT+SA.3Retailer pageevetech.co.za/asrock-z890-livemixer-intel-motherboard/best-deal/23134Read 15 October 2026Features: 18+1+1+1+1 phase VRM design and 80A Smart Power Stages for VCore, GT and SA.7Spec databasemaxmybuild.com/motherboards/asrock-z890-livemixer-wifiRead 15 October 2026VRM stages: 80A SPS.10Press articleascii.jp/elem/000/004/230/4230242/2Read 15 October 202680A SPS.

80A3Retailer pageshop.sumanet.cz/z890-riptide-wifi-asrock-mb-sc-lga1851-z890-riptide-wifi-intel-z890-4xddr5-1xhdmi-2xthunderbolt-wi-fiRead 15 October 202680A SPS for VCore+GT+SA, from ASRock's text. pcinq writes MP87681 parts supposedly rated for 80A.8Reviewpcinq.com/asrock-z890-riptide-wifi-reviewRead 15 October 2026The MP87681 parts are supposedly rated for 80A each. ASRock's text also says 80A SPS.

VRM controlleriPWM controller chip with maker, e.g. MPS MP2857. One name: the maker's when published, otherwise the one name a review uses. No parentheses. Other names go in the source note. Use the part number without the date code in the chip marking.

Not available

MPS MP29005-A8Reviewpcinq.com/asrock-z890-riptide-wifi-reviewRead 15 October 2026The MP29005-A that controls them is undocumented. The review names the maker as Monolithic Power Systems, stored as MPS.

CPU power connectorsiEPS 12 V connectors for the CPU as pin counts, e.g. 8+8 pin, 8+4 pin or 8 pin.

8+8 pin1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) and a 24 pin ATX connector.10Press articleascii.jp/elem/000/004/230/4230242/2Read 15 October 2026The CPU 12V connector is 8-pin x 2.

8+8 pin1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 5: 2 x 8 pin 12V power connectors (Hi-Density Power Connector, ATX12V1 and ATX12V2) and the 24-pin ATX connector.

Extra slot power connectoriA PCIe or other power connector on the board that feeds the expansion slots. The 24-pin and CPU connectors do not count. A connector the maker ties only to a front USB-C header does not count.

No1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026The section 1.2 connector list has no extra slot power connector.

No1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026The connector list on page 5 has no extra slot power connector.

Memory

0 of 6 differ

Memory type

DDR51Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: Dual Channel DDR5 memory technology.

DDR51Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 2: dual channel DDR5, 4 x DDR5 DIMM slots.

Memory slotsiDIMM slots on the board.

41Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 4 x DDR5 DIMM slots.

41Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026

Max memoryiMaximum total capacity the maker states for the board. The maker's product page wins over an older manual, since a BIOS update can raise the value.

256GB1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: max. capacity of system memory 256GB.

256GB1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 2: max. capacity of system memory 256GB.

Max memory speed (overclocked)iHighest overclocked speed the maker lists for one module per channel, with the newest CPU family the board is sold for, e.g. Ryzen 9000 or Core Ultra 200S. Ryzen 8000 values are never used. The source note names the family and the other module setups. It is not the CPU's official speed. A JEDEC-only list such as 5600/4800 is not this value. When the maker lists a manual overclock and a memory profile speed, the higher one is stored. The maker's product page wins over an older manual, since a BIOS update can raise the value. A table that names the CPU family wins over a headline speed that names none.

9,466MT/s1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: DDR5 non-ECC, un-buffered memory up to 9466+(OC). The memory support list is on ASRock's site. LDLC's feed also lists DDR5 9466 as the top speed, while its summary text and a Ukrainian shop say 9066+.2Retailer pageldlc.com/en/product/PB00649733.htmlRead 15 October 2026Memory frequency list tops out at DDR5 9466 MHz, while the summary says up to 9066 MHz.5Spec databasepcspecchart.com/pc_parts/motherboard/254Read 15 October 2026Vendor copy of ASRock's text: non-ECC, un-buffered memory up to 9466MHz+(OC).8Spec databasehinta.fi/4950255/asrock-z890-livemixer-wifi/tiedotRead 15 October 2026Supported memory clock speed (max): 9466 MHz.

9,466MT/s1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 2: DDR5 non-ECC, un-buffered memory up to 9466+(OC). Intel Core Ultra (Series 2) is the only CPU family of the board. Firstshop's copy of ASRock's text and The FPS Review say 9466. Sumanet, Scan, Arvutitark and MaxMyBuild write 9066 or 9000+, which is an older figure. The FPS Review conclusion writes 9644, which is a doubt.4Retailer pagefirstshop.hu/asrock-z890-riptide-wifi-p225719Read 15 October 2026Copy of ASRock's text: Supports DDR5 non-ECC, un-buffered memory up to 9466MHz+(OC), 1DPC 1R up to 9466+ MHz (OC), 5600 MHz natively. Intel Core Ultra (Series 2) is the only CPU family.7Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026Features section: DDR5 up to 9466 MT/s (overclocked). The conclusion writes 9644 MT/s, which is not used.

ECC memoryiThe board runs unbuffered ECC modules with ECC active. A board that runs ECC modules in non-ECC mode does not count. DDR5 on-die ECC does not count. A maker list of ECC and non-ECC unbuffered memory with no non-ECC mode qualifier counts as true, as on ASUS and ASRock AM5 boards. A note that ECC mode depends on the CPU, as ASUS writes for AM4 boards, still counts as true.

No1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: supports DDR5 non-ECC, un-buffered memory.

No1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 2: supports DDR5 non-ECC, un-buffered memory.

CUDIMM supportiThe board runs clocked unbuffered DIMMs (CUDIMM) with the clock driver active. Clock driver bypass mode only does not count. A plain "Supports CUDIMM" with no bypass limit, as ASRock and ASUS write it, counts as true.

Yes5Spec databasepcspecchart.com/pc_parts/motherboard/254Read 15 October 2026The page's vendor copy of ASRock's specification says: Supports Clocked Unbuffered DIMM (CUDIMM), with no clock driver bypass limit. The older 72-page manual does not list CUDIMM, so ASRock's newer specification text is used.

Yes3Retailer pageshop.sumanet.cz/z890-riptide-wifi-asrock-mb-sc-lga1851-z890-riptide-wifi-intel-z890-4xddr5-1xhdmi-2xthunderbolt-wi-fiRead 15 October 2026Copy of ASRock's text: Supports Clocked Unbuffered DIMM (CUDIMM), with no clock driver bypass limit. The December 2024 manual does not list CUDIMM, so ASRock's newer specification text is used. Firstshop and The FPS Review say the same.4Retailer pagefirstshop.hu/asrock-z890-riptide-wifi-p225719Read 15 October 2026Supports Clocked Unbuffered DIMM (CUDIMM).7Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026Clocked Unbuffered DIMM (CUDIMM) is also supported.

Expansion slots

2 of 3 differ

Expansion slotsiPhysical card slots. Storage M.2 slots are listed under Storage. The M.2 slot of a pre-installed Wi-Fi module is not listed. A full-length slot wired for x4 is PCIe x16 with 4 lanes.

AASRock Z890 LiveMixer WiFi

Physical slot	Electrical lanes	PCIe generation	Connected to	Count
PCIe x16	16	5	CPU	1
PCIe x16	4	4	Chipset	2

Source1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: PCIE1 from the CPU is a PCIe 5.0 x16 slot that supports x16 mode (riser cards can split it into x8/x8 or x8/x4/x4). PCIE2 and PCIE3 on the chipset are PCIe 4.0 x16 slots that support x4 mode. The block diagram shows each with Gen4 x4. The Key E socket for the Wi-Fi module is not listed.

BASRock Z890 Riptide WiFi

Physical slot	Electrical lanes	PCIe generation	Connected to	Count
PCIe x16	16	5	CPU	1
PCIe x16	4	4	Chipset	1
PCIe x1	1	4	Chipset	1

Source1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 2: PCIE1 is PCIe 5.0 x16 from the CPU. PCIE2 is a PCIe 4.0 x16-length slot from the chipset at x4. PCIE3 is a PCIe 4.0 x1 slot from the chipset. PCIE1 also supports riser cards to split one x16 slot into x8/x8 or x8/x4/x4. The M.2 Key E socket for a Wi-Fi module (CNVio) is not listed.

Full-length PCIe slotsiCounts full-length slots, whatever their lane count.

3=CalculatedFrom Expansion slots

2=CalculatedFrom Expansion slots

Fastest PCIe x16 slot generationiHighest PCIe generation of a full-length slot. This is normally the graphics card slot.

5=CalculatedFrom Expansion slots

5=CalculatedFrom Expansion slots

Storage

2 of 4 differ

M.2 storage slotsiOne row per M key storage slot on the board, front or back. Slots on an included add-in card are not listed. Values are with the CPU family that gives the board its full connectivity. A slot listed for 25110 counts as M.2 22110. A slot listed for 2260 counts as M.2 2280.

AASRock Z890 LiveMixer WiFi

Slot	PCIe generation	PCIe lanes	Connected to	Longest drive	Takes SATA drives	Heatsink
M2_1	5	4	CPU	M.2 2280	No	Yes
M2_2	4	4	CPU	M.2 2280	No	No
M2_3	4	4	Chipset	M.2 2280	No	Yes
M2_4	4	4	Chipset	M.2 2280	Yes	Yes

Source1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2 and the block diagram: M2_1 from the CPU, PCIe Gen5 x4, type 2280. M2_2 from the CPU, PCIe Gen4 x4, type 2280. M2_3 on the chipset, PCIe Gen4 x4, types 2230/2242/2260/2280. M2_4 on the chipset, PCIe Gen4 x4 and SATA3, type 2280. Sections 2.15 to 2.18: M2_1, M2_3 and M2_4 have a heatsink released with a push button. The M2_2 guide shows no heatsink. No lane sharing is stated in the manual.7Spec databasemaxmybuild.com/motherboards/asrock-z890-livemixer-wifiRead 15 October 2026M.2 heatsinks: slots 1, 3 and 4. This agrees with the manual.

BASRock Z890 Riptide WiFi

Slot	PCIe generation	PCIe lanes	Connected to	Longest drive	Takes SATA drives	Heatsink
M2_1	5	4	CPU	M.2 2280	No	Yes
M2_2	4	4	CPU	M.2 2280	No	Yes
M2_3	4	4	Chipset	M.2 2280	No	Yes
M2_4	4	4	Chipset	M.2 2280	No	Yes
M2_5	4	4	Chipset	M.2 2280	Yes	Yes

Source1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 4: M2_1 (Blazing M.2, CPU) 2280 PCIe Gen5x4. M2_2 (Hyper M.2, CPU) 2280 PCIe Gen4x4. M2_3 and M2_4 (Hyper M.2, chipset) 2280 PCIe Gen4x4. M2_5 (chipset) 2230/2242/2260/2280 in SATA3 and PCIe Gen4x4 modes, so only M2_5 has sata true. Sections 2.15 to 2.17 show an M.2 heatsink with a release button on all five sockets, so heatsink is true for each. The manual states no lane sharing.

M.2 slots

4=CalculatedFrom M.2 storage slots

5=CalculatedFrom M.2 storage slots

PCIe 5.0 M.2 slots

1=CalculatedFrom M.2 storage slots

1=CalculatedFrom M.2 storage slots

SATA portsiSATA 6Gb/s connectors on the board. SlimSAS connectors and M.2 slots that take SATA drives do not count.

41Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 4 x SATA3 6.0 Gb/s connectors.

41Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 4: 4 x SATA3 6.0 Gb/s connectors. M2_5 is not counted.

Rear ports

2 of 5 differ

Rear portsiPhysical connectors on the rear I/O panel. Wi-Fi antenna connectors and buttons are not ports. 3.5 mm audio counts analog jacks of any role. A video input, such as the DisplayPort In of a Thunderbolt board, is Other.

AASRock Z890 LiveMixer WiFi

Type	Version	Count	Max link rate (Gbps)	Thunderbolt or USB4	Power out (W)	DP Alt Mode
USB-C	USB4	2	40	Thunderbolt 4	15	Yes
USB-A	USB 3.2 Gen 2	2	10	Not available	Not available	Not available
USB-A	USB 3.2 Gen 1	10	5	Not available	Not available	Not available
HDMI	HDMI 2.1	1	Not available	Not available	Not available	Not available
Ethernet (RJ45)	Not available	1	2.5	Not available	Not available	Not available
3.5 mm audio	Not available	2	Not available	Not available	Not available	Not available
Optical S/PDIF	Not available	1	Not available	Not available	Not available	Not available

Source1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2 and 1.4: 2 x Thunderbolt 4 Type-C (40 Gb/s for USB4 and for Thunderbolt, USB PD 3.0 up to 5V@3A (15W)), 2 x USB 3.2 Gen2 Type-A, 10 x USB 3.2 Gen1, 1 x HDMI, 1 x RJ-45 (2.5G LAN), 1 x line out jack, 1 x microphone input jack, 1 x optical S/PDIF out, 2 antenna ports and 1 BIOS Flashback button. The manual says only the CPU's embedded graphics can drive a display through the Thunderbolt ports. HDMI is 2.1 TMDS/FRL 8G compatible, up to 4K 120Hz. No rear USB 2.0 ports are listed.

BASRock Z890 Riptide WiFi

Type	Version	Count	Max link rate (Gbps)	Thunderbolt or USB4	Power out (W)	DP Alt Mode
USB-C	USB4	2	40	Thunderbolt 4	15	Yes
USB-A	USB 3.2 Gen 2	2	10	Not available	Not available	Not available
USB-A	USB 3.2 Gen 1	4	5	Not available	Not available	Not available
USB-A	USB 2.0	2	0.48	Not available	Not available	Not available
HDMI	HDMI 2.1	1	Not available	Not available	Not available	Not available
Ethernet (RJ45)	Not available	1	2.5	Not available	Not available	Not available
3.5 mm audio	Not available	2	Not available	Not available	Not available	Not available
Optical S/PDIF	Not available	1	Not available	Not available	Not available	Not available

Source1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Pages 4 and 9: 1 HDMI (2.1 TMDS/FRL, 4K 120Hz), 2 Thunderbolt 4 Type-C (40 Gb/s for USB4 protocol and for Thunderbolt protocol, supports USB PD 3.0 up to 5V@3A, 15W), 2 USB 3.2 Gen2 Type-A (10 Gb/s), 4 USB 3.2 Gen1, 2 USB 2.0, 1 RJ-45 2.5G LAN, line out and microphone jacks, 1 optical S/PDIF out. The four USB 3.2 Gen1 ports are not named Type-A in the manual, and are stored as Type-A as for other boards. The Thunderbolt ports show video through the CPU's graphics only. The BIOS Flashback button and the two antenna ports are not ports.

Rear USB ports

14=CalculatedFrom Rear ports

10=CalculatedFrom Rear ports

Rear USB-C portsiIncludes Thunderbolt and USB4 ports.

2=CalculatedFrom Rear ports

2=CalculatedFrom Rear ports

Fastest rear USB port

40Gbps=CalculatedFrom Rear ports

40Gbps=CalculatedFrom Rear ports

ThunderboltiThunderbolt on the rear panel. A header for an add-in card does not count.

Yes=CalculatedFrom Rear ports

Yes=CalculatedFrom Rear ports

Internal connectors

0 of 5 differ

Internal USB headersiHeaders for front-panel USB ports. The header count may be left out when the maker states only the front ports served.

AASRock Z890 LiveMixer WiFi

Header	Max data rate (Gbps)	Headers	Front ports served
USB-C header	20	1	1
USB 3 header (19-pin)	5	2	4
USB 2.0 header (9-pin)	0.48	2	4

Source1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 1 front panel Type-C USB 3.2 Gen2x2 header (20 Gb/s), 2 USB 3.2 Gen1 headers (4 ports) and 2 USB 2.0 headers (4 ports). No power output is stated for the Type-C header.

BASRock Z890 Riptide WiFi

Header	Max data rate (Gbps)	Headers	Front ports served
USB-C header	20	1	1
USB 3 header (19-pin)	5	2	4
USB 2.0 header (9-pin)	0.48	2	4

Source1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 5: 2 USB 2.0 headers for 4 ports, 2 USB 3.2 Gen1 headers for 4 ports and 1 front panel Type-C USB 3.2 Gen2x2 header (20 Gb/s).

Front USB-C header speed

20Gbps=CalculatedFrom Internal USB headers

20Gbps=CalculatedFrom Internal USB headers

Fan headersiAll fan and pump headers on the board, including CPU, CPU optional, AIO pump and chassis fan headers. Combination connectors that carry fan power together with other lines, such as MSI EZ Conn, do not count. A header that drives several fans, such as GIGABYTE 3_FANS, counts once. Headers on a hub that ships with the board and plugs into it, such as MSI's EZ CONTROL HUB, count. The source note splits board and hub.

81Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 2 CPU fan connectors, 5 chassis fan connectors and 1 AIO pump fan connector make 8, as the block diagram says FAN x8.

81Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 5 and the block diagram: 2 CPU fan, 4 chassis fan, 1 AIO pump and 1 water pump connectors, all 4-pin. The block diagram says FAN x8.

ARGB headersi3-pin 5 V addressable RGB headers. Combination connectors do not count. Headers on a hub that ships with the board and plugs into it, such as MSI's EZ CONTROL HUB, count. The source note splits board and hub.

31Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 3 x Addressable LED Headers (ADDR_LED1 to 3).

31Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 5: 3 x addressable LED headers (ADDR_LED1 to ADDR_LED3).

RGB headersi4-pin 12 V RGB headers. Headers on a hub that ships with the board and plugs into it, such as MSI's EZ CONTROL HUB, count. The source note splits board and hub.

11Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 1 x RGB LED Header (RGB_LED1, 12V).

11Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 5: 1 x RGB LED header (RGB_LED1, 12V, up to 3A).

Networking

1 of 9 differ

Ethernet controllersiOne item per Ethernet chip, as maker plus chip family without suffix letters, e.g. Realtek RTL8126 or Realtek RTL8125. Suffixes and revisions go in the source note. Leave it empty when no maker document or review names the chip. A Killer chip is written with Intel as its maker, such as Intel Killer E3100G.

Realtek RTL81251Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 2.5 Gigabit LAN, Dragon RTL8125BG. Stored as the chip family RTL8125.

Intel Killer E3100G1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 3: 2.5 Gigabit LAN, Killer E3100G. Killer chips are Intel's, so it is written Intel Killer E3100G.

Ethernet ports

1=CalculatedFrom Rear ports

1=CalculatedFrom Rear ports

Ethernet speediFastest Ethernet port.

2.5Gbps=CalculatedFrom Rear ports

2.5Gbps=CalculatedFrom Rear ports

Wi-Fi includediA Wi-Fi module comes installed. A board sold with and without Wi-Fi is two products.

Yes1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2 and 1.6: an 802.11be Wi-Fi 7 + BT module comes with the board, and 2 antennas are in the box.

Yes1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 3 and section 1.6: an 802.11be 2x2 Wi-Fi 7 module on the Key E socket, with an antenna in the box.

Wi-Fi standard

Wi-Fi 71Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 802.11be 2x2 Wi-Fi 7 module, 802.11a/b/g/n/ac/ax/axe/be.

Wi-Fi 71Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 3: 802.11be 2x2 Wi-Fi 7 module, IEEE 802.11a/b/g/n/ac/ax/axe/be.

Wi-Fi bandsiBands the installed module supports.

2.4 GHz, 5 GHz, 6 GHz1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 2.4GHz/5GHz/6GHz frequency band. 6GHz depends on each country's regulations.

2.4 GHz, 5 GHz, 6 GHz1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 3: 2.4GHz/5GHz/6GHz frequency band. The 6 GHz band depends on country regulations.

Max Wi-Fi channel widthiWidest channel the installed module supports, e.g. 320 or 160. It follows the Wi-Fi module, so a board revision can change it.

320MHz1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: supports 320MHz channel bandwidth with the 6GHz frequency band.

320MHz1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 3: supports 320MHz channel bandwidth with the 6GHz frequency band.

Wi-Fi moduleiChip as published. A board revision can change the chip. One name: the maker's when published, otherwise the one name a review uses. No parentheses. Other names go in the source note. Use the chip's part number with its maker when any source gives it, such as Qualcomm QCNCM865 for a module also written NCM865. A platform name such as FastConnect 7800 is used only when no part number is published.

Intel BE2001Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.5 block diagram: M.2_WIFI1 (BE200), on CNVi. The text of section 1.6 and 1.2 names no chip.

Intel BE2007Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026Wireless is Wi-Fi 7 from an Intel BE200 chip on an M.2 Key E socket.8Reviewpcinq.com/asrock-z890-riptide-wifi-reviewRead 15 October 2026Intel BE200 Wi-Fi 7 / BT 5.4 combo.

BluetoothiVersion of the Bluetooth radio on the Wi-Fi module.

5.41Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Sections 1.2 and 1.6: Bluetooth 5.4.

5.41Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 3 and section 1.6: Bluetooth 5.4.

Audio

0 of 2 differ

Audio codeciMaker and model, e.g. Realtek ALC4080. A board revision can change the codec.

Realtek ALC12201Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2: 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec). The block diagram also says ALC1220 (2+1 jack audio).

Realtek ALC12201Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 3: 7.1 CH HD Audio (Realtek ALC1220 Audio Codec), Nahimic Audio.

DAC chipiA separate DAC chip next to the codec, e.g. ESS ES9219. Maker plus part number as the maker writes it, with suffix letters, e.g. ESS ES9219Q. A marketing name that stands for a part number is written as the part number, so ESS SABRE9219 is ESS ES9219 and the maker wording goes in the source note. Leave it empty on boards with only a codec.

Not available

Not available

Features

0 of 7 differ

BIOS flashbackiA button that updates the BIOS from a USB drive without a CPU or memory installed. Maker names include BIOS FlashBack, Flash BIOS Button and Q-Flash Plus.

Yes1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 2.13: the BIOS Flashback Button (BIOS_FB1) is on the rear panel.

Yes1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 4 and section 2.13: 1 x BIOS Flashback button, the only smart switch.

Clear CMOS button (rear)iA button on the rear panel that resets the BIOS settings. A jumper or header does not count. A board whose only clear CMOS button sits on the board itself is false.

No1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 2.13 says the board has one smart switch, the BIOS Flashback Button. Clear CMOS is a jumper (CLRMOS1).5Spec databasepcspecchart.com/pc_parts/motherboard/254Read 15 October 2026Buttons row: BIOS flashback yes, Clear CMOS no.

No1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Page 8 lists a Clear CMOS jumper (CLRMOS1). The only rear panel button is BIOS Flashback.

POST code displayiA two-digit display that shows boot codes, e.g. ASUS Q-Code or ASRock Dr. Debug. Single status LEDs do not count. Taken from the maker's spec or manual only. A review spec table is not enough.

No1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 2.14: the Post Status Checker is four single LEDs for CPU, DRAM, VGA and storage. There is no code display.

No1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Section 2.14: the Post Status Checker is four colour LEDs for CPU, DRAM, VGA and BOOT, not a two-digit display.

Power button on the boardiA power or start button on the board itself, for use outside a case. A button with another label counts when the maker says it can turn the PC on, such as GIGABYTE's quick button labelled RESET. A button on the rear I/O panel counts. A button on a module that ships fitted to the board, such as MSI's EZ BRIDGE, counts.

No1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 2.13: the only smart switch is the BIOS Flashback Button. No power or start button is listed.5Spec databasepcspecchart.com/pc_parts/motherboard/254Read 15 October 2026Buttons row: smart button no, onboard start/reset no.

No1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Section 2.13 says the only smart switch is the BIOS Flashback button. The layout lists no power or reset button.

Dual BIOSiTwo BIOS chips, so the board can start from the second chip after a failed update. Two flash chips alone do not count.

No1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.2 BIOS Feature: AMI UEFI Legal BIOS. The block diagram shows one 256Mb flash ROM. No second BIOS is listed.

No1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Section 1.2 BIOS Feature: AMI UEFI Legal BIOS. The block diagram shows one 256Mb flash ROM.

Pre-installed I/O shieldiThe rear I/O shield is fixed to the board.

Yes6Retailer pagemultitronic.fi/en/products/4408928Read 15 October 2026Copy of ASRock's feature text: Flexible Integrated I/O Shield. It says the shield is pre-mounted and adjustable when installing. A loose shield is not in the box list.

Yes3Retailer pageshop.sumanet.cz/z890-riptide-wifi-asrock-mb-sc-lga1851-z890-riptide-wifi-intel-z890-4xddr5-1xhdmi-2xthunderbolt-wi-fiRead 15 October 2026Copy of ASRock's feature text: Flexible Integrated I/O Shield. The manual's box list has no loose I/O shield.4Retailer pagefirstshop.hu/asrock-z890-riptide-wifi-p225719Read 15 October 2026Flexible Integrated I/O Shield.

Tool-free featuresiM.2 latch holds a drive without a screw. M.2 heatsink comes off without a tool. PCIe slot release is a button or lever that frees the graphics card. Push-on antenna connector fits the Wi-Fi antenna without screwing.

Tool-free M.2 latch, Tool-free M.2 heatsink1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Sections 2.15 to 2.18: M.2 SSDs lock with a nut lock turned by hand (screwless M.2 SSD design), and the heatsink on M2_1, M2_3 and M2_4 comes off with a push button. M2_3 needs a screwdriver only to move the standoff for short drives. The antennas screw on, so no push-on antenna option is set. No PCIe slot release is listed.4Retailer pageparadigit.ie/asrock-z890-livemixer-wifi/21654355/productRead 15 October 2026Copy of ASRock's text: M.2 heatsink toolless design, an M.2 heatsink quick release mechanism, and an M.2 SSD toolless design.10Press articleascii.jp/elem/000/004/230/4230242/2Read 15 October 2026The M.2 heatsink comes off by sliding a round knob, with no screws and no tools, and the M.2 SSD is fixed without screws.

Tool-free M.2 latch, Tool-free M.2 heatsink1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Sections 2.15 to 2.17: each M.2 SSD is secured by turning a nut lock clockwise, with no screw, and each M.2 heatsink is released with a button. M2_5 also uses standoffs for shorter drives. pcinq calls the heat spreaders latch-operated and tool-free.8Reviewpcinq.com/asrock-z890-riptide-wifi-reviewRead 15 October 2026Two latch-operated M.2 heat spreaders that let users install, remove or swap all five drives without a screwdriver. The upper one also has a bottom sink for PCIe 5.0 drives.

Measured

1 of 3 differ

VRM temperature under CPU loadiHighest VRM temperature a reviewer measured during a sustained all-core CPU stress test at stock settings. Compare only results from the same reviewer and CPU. The reviewer's probe reading when given, otherwise the board sensor. The sensor and the CPU package power during the test go in the source note.

Not available

33°C7Reviewthefpsreview.com/2024/12/18/asrock-phantom-gaming-z890-riptide-wifi-motherboard-reviewRead 15 October 2026Core Ultra 5 245K, Cinebench R23 multi-core for 20 minutes. During testing the CPU Core read 57 C and the MOS read 33 C. The reviewer found HWInfo64's MOS reading in error compared with the BIOS reading, and the sensor behind the 33 C is not named. The cooler, CPU power and ambient temperature are not stated. A doubt, since 33 C is low.

Power draw idleiWhole test system at the wall at idle, measured by a reviewer. Compare only results from the same reviewer and CPU. A chart of CPU and board power without a wall meter does not count.

Not available

Not available

Power draw CPU stressiWhole test system at the wall at the peak of a CPU stress test, measured by a reviewer. The graphics card is not loaded. Compare only results from the same reviewer and CPU. A chart of CPU and board power without a wall meter does not count.

Not available

Not available

In the box

1 of 1 differ

In the boxiItems as the maker lists them.

2 x SATA data cables, 2 x ASRock WiFi 2.4/5/6 GHz antennas, 1 x Thermistor cable1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026Section 1.1: ASRock Z890 LiveMixer WiFi motherboard, 2 x SATA data cables, 2 x ASRock WiFi 2.4/5/6 GHz antennas and 1 x thermistor cable. The manual marks the cables, antennas and thermistor cable as optional.

2 x Serial ATA (SATA) data cables, 1 x ASRock WiFi 2.4/5/6 GHz antenna, 1 x ARGB splitter cable, 1 x Thermistor cable1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026Section 1.1: 2 SATA data cables, 1 ASRock WiFi 2.4/5/6 GHz antenna, 1 ARGB splitter cable and 1 thermistor cable. The manual marks each item Optional, which means the items depend on the package.

Links

Not compared

Product page

www.asrock.com/mb/Intel/Z890%20LiveMixer%20WiFi/index.asp13Maker product pageasrock.com/mb/Intel/Z890%20LiveMixer%20WiFi/index.aspRead 15 October 2026The link comes from the task and web search results. asrock.com answers agents with a bot check, so the page was not read and no value comes from it.

pg.asrock.com/mb/Intel/Z890%20Riptide%20WiFi/index.asp2Maker product pagepg.asrock.com/mb/Intel/Z890%20Riptide%20WiFi/index.aspRead 15 October 2026The URL comes from the job evidence. ASRock's site returns a bot check to agents, so the page was not opened. The specification text was read from the user manual, retailer copies of ASRock's text and reviews.

Spec sheet

Not available

Not available

Manual

download.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdf1Owner's manualdownload.asrock.com/Manual/Z890%20LiveMixer%20WiFi.pdfRead 15 October 2026ASRock Z890 LiveMixer WiFi manual, 72 pages, English, from download.asrock.com. The maker's product page is behind a bot check and was not opened.

download.asrock.com/Manual/Z890%20Riptide%20WiFi.pdf1Owner's manualdownload.asrock.com/Manual/Z890%20Riptide%20WiFi.pdfRead 15 October 2026ASRock Z890 Riptide WiFi User Manual, 69 pages, English PDF on download.asrock.com, last modified 2024-12-16.

EPREL registration numberiId in the EU energy label database. Each size or model of a series has its own id, so it is per variant.

Not available

Not available

Warranty

1 of 1 differ

Manufacturer warranty (source market)iThe maker's warranty period for the exact SKU or configuration and market named in the source note. It applies only to that stated market, not every regional variant. Statutory consumer rights are excluded. The base term is stored. An extension that needs registration goes in the source note.

3years3Retailer pageevetech.co.za/asrock-z890-livemixer-intel-motherboard/best-deal/23134Read 15 October 20263 Years Local Warranty on this South African retailer's page. ASRock's manual gives no term, and LDLC lists a 2-year seller warranty for France.

Not available

Both are also in the API. Back to all motherboards.
