GIGABYTE X870E AORUS PRO X3D ICE

GIGABYTEGaming motherboard

X870E AORUS PRO X3D ICE

Released September 2025.2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Listed since 2025-09-16. Last checked 16 October 2026.

CPU socket
AM5
Chipset
AMD X870E
Form factor
ATX
M.2 slots
4

63 of 78 fields known.

Compare with another motherboardDownload JSONDownload CSVGet it from the API

At a glance

Ports

  • 2 USB-C USB4
  • 2 USB-C USB 3.2 Gen 2
  • 5 USB-A USB 3.2 Gen 2
  • 3 USB-A USB 3.2 Gen 1
  • HDMI 2.1
  • Ethernet (RJ45)
  • 2 3.5 mm audio
  • Optical S/PDIF
  • USB-C header
  • 2 USB 3 header (19-pin)
  • 2 USB 2.0 header (9-pin)

All specs

SourceCalculated

General

Series
AORUS1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Manual cover: X870E AORUS PRO X3D ICE. AORUS is the GIGABYTE brand line in the name.
Model numbers
X870E AORUS PRO X3D ICE, X870E A PRO X ICE1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Cover and Box Contents: X870E AORUS PRO X3D ICE or X870E AORUS PRO X3D. The ICE is the white edition of the same board. The retailer code X870E A PRO X ICE comes from the Geizhals offers and other retailers.2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Offers use the code X870E A PRO X ICE.8Retailer pagecomparateur-gamer.fr/prix/gigabyte-x870e-aorus-pro-x3d-ice-4719331876487Read 15 October 2026Reference X870E A PRO X ICE.
GTIN / EAN
4719331876487, 8895230531648Retailer pagecomparateur-gamer.fr/prix/gigabyte-x870e-aorus-pro-x3d-ice-4719331876487Read 15 October 2026EAN 4719331876487. The page title and the alltron.ch and shopro.lt listings give the same code.9Retailer pagecomputeralliance.com.auRead 15 October 2026The page lists the UPC/GTIN 889523053164 for the X870E AORUS PRO X3D ICE.
Announced
Not available
Status
Available2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Listed with 31 offers from German and Austrian shops, from 355.56 EUR, in the snapshot of 2026-08-31 and on 2026-10-15.
Predecessor
Not available
Successor
Not available
Launch price (US)
Not available
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Gaming7Retailer pageldlc.com/en/product/PB00716772.htmlRead 15 October 2026Use: gaming. The product box in the photo reads GAMING MOTHERBOARD.
Board revision
Not available

Platform

CPU socket
AM51Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: AMD Socket AM5.
Chipset
AMD X870E1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: AMD X870E.
Supported processors
AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: AMD Ryzen 9000, 8000 and 7000 Series Processors. The manual points to GIGABYTE's website for the latest CPU support list. Read on 2026-10-15. BIOS updates can add series later.
CPU overclocking
Yes11Press articleguru3d.com/review/colorful-igame-x870e-vulcan-w-oc-v14-review/page-2Read 15 October 2026The AMD X870E chipset overview on page 2 says X870E also allows CPU and DDR5 memory overclocking. This is the chipset maker's feature as Guru3D reports it, in a review of another X870E board.

Board

Front and side, drawn to scale.

Form factor
ATX1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: ATX Form Factor, 30.5cm x 24.4cm.
Board dimensions
Width244Height305mm(9.6 × 12 in)1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 30.5cm x 24.4cm.3Reviewkitguru.net/components/motherboard/leo-waldock/gigabyte-x870e-aorus-pro-x3d-ice-reviewRead 15 October 2026Spec table: ATX, 305 x 244 mm.
PCB layers
83Reviewkitguru.net/components/motherboard/leo-waldock/gigabyte-x870e-aorus-pro-x3d-ice-reviewRead 15 October 2026Key features: 8-layer PCB with back-drilling.4Reviewprofesionalreview.com/2025/10/02/x870e-aorus-pro-x3d-ice-review/ampRead 15 October 20268-layer server-grade PCB with double-thickness copper.5Reviewfunkykit.com/reviews/motherboards/gigabyte-x870e-aorus-pro-x3d-ice-motherboard-reviewRead 15 October 2026Page 1: 8-layer, 2 oz copper, server-grade PCB.
Back-connect design
No1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026The layout and connector pages (sections 1-1 and 2-8) show the usual front-side connectors. The board is not a back-connect design.
RGB lighting on the board
Yes2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Lighting: 2 zones, on the chipset heatsink and the I/O cover.

Power delivery

Power stage layout
18+2+22Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026VRM row: 18+2+2, 20 virtual CPU phases (2x9+2) and 11 real CPU phases (9+2). Geizhals reads 80 A PMC41410 power stages and the XDPE192C3B controller. Those two values match the older X870E AORUS PRO ICE and disagree with KitGuru and Profesional Review, so they are not stored.3Reviewkitguru.net/components/motherboard/leo-waldock/gigabyte-x870e-aorus-pro-x3d-ice-reviewRead 15 October 2026Spec table: 18x Vcore and 2x SoC power stages plus 2x 60A OnSemi DrMOS for the rest.4Reviewprofesionalreview.com/2025/10/02/x870e-aorus-pro-x3d-ice-review/ampRead 15 October 2026The review writes 18+2+2.5Reviewfunkykit.com/reviews/motherboards/gigabyte-x870e-aorus-pro-x3d-ice-motherboard-reviewRead 15 October 2026Page 1: the product description says 18+2+2 Twin Digital VRM Design.
CPU core (Vcore) power stages
182Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026VRM row: 18x power stages for VCORE.3Reviewkitguru.net/components/motherboard/leo-waldock/gigabyte-x870e-aorus-pro-x3d-ice-reviewRead 15 October 2026Spec table: 18x Infineon PMC41430 for Vcore. The table says 110A. The maker's own figure is not available, so the rating is not stored.4Reviewprofesionalreview.com/2025/10/02/x870e-aorus-pro-x3d-ice-review/ampRead 15 October 202618 phases for Vcore as 9+9 in parallel, with Infineon PMC41430 stages, 2 for VSoC and 2 for VMisc.
Vcore power stage rating
Not available
VRM controller
Infineon XDPE192C3D3Reviewkitguru.net/components/motherboard/leo-waldock/gigabyte-x870e-aorus-pro-x3d-ice-reviewRead 15 October 2026Spec table: 12-phase Infineon XDPE192C3D controller. Profesional Review names the same chip. Geizhals writes XDPE192C3B.4Reviewprofesionalreview.com/2025/10/02/x870e-aorus-pro-x3d-ice-review/ampRead 15 October 2026Main controller Infineon XDPE192C3D, with a RT3672EE next to the socket.
CPU power connectors
8+8 pin1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 2 x 8-pin ATX 12V power connectors and the 24-pin ATX connector.
Extra slot power connector
No1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2 lists 1 x PCIe power connector. The connector page (F20G_12V) says it only powers the front panel USB Type-C header for up to 65W PD 3.0 and QC 4+ fast charging, so it is not a slot power connector.

Memory

Memory type
DDR51Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 4 x DDR5 DIMM sockets.
Memory slots
41Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 4 x DDR5 DIMM sockets.
Max memory
256GB1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: up to 256 GB (64 GB single DIMM capacity).
Max memory speed (overclocked)
9,000MT/s2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Data rate: DDR5-5200 (Ryzen 7000/8000G), DDR5-5600 (Ryzen 9000), maximum DDR5-9000 OC.3Reviewkitguru.net/components/motherboard/leo-waldock/gigabyte-x870e-aorus-pro-x3d-ice-reviewRead 15 October 2026Spec table: up to DDR5-9000 (O.C.).5Reviewfunkykit.com/reviews/motherboards/gigabyte-x870e-aorus-pro-x3d-ice-motherboard-reviewRead 15 October 2026Page 1: EXPO memory up to DDR5-9000 OC.6Retailer pageeu.computerorbit.com/products/gigabyte-x870e-aorus-pro-x3d-ice-atx-am5-motherboardRead 15 October 2026Supported memory clock of up to 9000 MHz.
ECC memory
No1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules. No ECC mode is listed. The manual lists only DDR5 5200 and 4800 MT/s.
CUDIMM support
Not available

Expansion slots

Expansion slots
Physical slotElectrical lanesPCIe generationConnected toCount
PCIe x16165CPU1
PCIe x1644Chipset1
PCIe x1623Chipset1
Source1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: PCIEX16 from the CPU. Ryzen 9000 and 7000 run it at PCIe 5.0 x16, Ryzen 8000 Phoenix 1 at PCIe 4.0 x8 and Phoenix 2 at PCIe 4.0 x4. PCIEX4 and PCIEX2 are x16-length slots from the chipset, PCIe 4.0 at x4 and PCIe 3.0 at x2. The CPU slot values are the Ryzen 9000 values.
Full-length PCIe slots
3
Fastest PCIe x16 slot generation
5

Storage

M.2 storage slots
SlotPCIe generationPCIe lanesConnected toLongest driveTakes SATA drivesHeatsinkShares lanes with
M2A_CPU54CPUM.2 22110NoYesNot available
M2B_CPU54CPUM.2 22110NoYesThe ASMedia USB4 controller. Both run at x2 when a device is in M2B_CPU
M2C_SB44ChipsetM.2 22110NoYesNot available
M2D_SB44ChipsetM.2 22110NoYesNot available
Source1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2, Ryzen 9000 values. M2A_CPU takes 25110, 22110, 2580 and 2280 at PCIe 5.0 x4 or x2. M2B_CPU takes 22110 and 2280 at PCIe 5.0 x4 or x2 and shares bandwidth with the ASMedia USB4 controller. With Ryzen 8000 it is unavailable. M2C_SB and M2D_SB take 22110 and 2280 at PCIe 4.0 x4 or x2 from the chipset. 22110 is stored for 25110 and 22110 slots. The manual lists PCIe SSDs only, so no slot takes SATA. The M.2 steps in section 2-8 remove a motherboard heatsink for every slot, and one heatsink covers M2C_SB and M2D_SB.
M.2 slots
4
PCIe 5.0 M.2 slots
2
SATA ports
41Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 4 x SATA 6Gb/s connectors.

Rear ports

Rear ports
TypeVersionCountMax link rate (Gbps)Thunderbolt or USB4DP Alt Mode
USB-CUSB4240USB4Yes
USB-CUSB 3.2 Gen 2210Not availableNot available
USB-AUSB 3.2 Gen 2510Not availableNot available
USB-AUSB 3.2 Gen 135Not availableNot available
HDMIHDMI 2.11Not availableNot availableNot available
Ethernet (RJ45)Not available15Not availableNot available
3.5 mm audioNot available2Not availableNot availableNot available
Optical S/PDIFNot available1Not availableNot availableNot available
Source1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2 and 2-6: 2 USB4 Type-C ports (DisplayPort 1.4, 40 Gbps per Geizhals), 2 USB 3.2 Gen 2 Type-C, 5 USB 3.2 Gen 2 Type-A (red), 3 USB 3.2 Gen 1, 1 HDMI (HDMI 2.1, CPU with graphics only), 1 RJ-45 up to 5 Gbps, 2 audio jacks and 1 optical S/PDIF out. The 3 USB 3.2 Gen 1 ports are not named Type-A in the manual. All Type-C ports are listed separately, so the 3 USB 3.2 Gen 1 ports are Type-A, which Geizhals and KitGuru also state. The ports are not Thunderbolt. The reset, power, clear CMOS and Q-Flash Plus buttons and the two antenna connectors are not ports. The manual gives no USB power output for the rear ports.2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 20262x USB4 with DisplayPort 1.4 (40 Gb/s), 2x USB-C 10 Gb/s, 5x USB-A 10 Gb/s and 3x USB-A 5 Gb/s.
Rear USB ports
12
Rear USB-C ports
4
Fastest rear USB port
40Gbps
Thunderbolt
No

Internal connectors

Internal USB headers
HeaderMax data rate (Gbps)HeadersFront ports servedPower out (W)
USB-C header201165
USB 3 header (19-pin)524Not available
USB 2.0 header (9-pin)0.4824Not available
Source1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 1 USB Type-C header with USB 3.2 Gen 2x2 (20 Gbps, up to 65W PD 3.0 and QC 4+ with the PCIe power connector), 2 USB 3.2 Gen 1 headers (4 ports) and 2 USB 2.0/1.1 headers (4 ports).
Front USB-C header speed
20Gbps
Fan headers
81Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 1 CPU fan, 1 CPU fan/pump, 4 system fan and 2 system fan/pump headers make 8.
ARGB headers
31Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 3 x addressable RGB Gen2 LED strip headers.
RGB headers
11Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 1 x RGB LED strip header.

Networking

Ethernet controllers
Realtek RTL81264Reviewprofesionalreview.com/2025/10/02/x870e-aorus-pro-x3d-ice-review/ampRead 15 October 2026Network: Realtek RTL8126 (5 GbE).6Retailer pageeu.computerorbit.com/products/gigabyte-x870e-aorus-pro-x3d-ice-atx-am5-motherboardRead 15 October 2026LAN: Realtek RTL8126, 2.5GbE, 5GbE and GbE. The manual says only Realtek 5GbE LAN chip. Paradigit lists the same chip.
Ethernet ports
1
Ethernet speed
5Gbps
Wi-Fi included
Yes1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2 and the block diagram: an M.2 WIFI socket carries the Wi-Fi module.
Wi-Fi standard
Wi-Fi 71Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 802.11a, b, g, n, ac, ax and be.
Wi-Fi bands
2.4 GHz, 5 GHz, 6 GHz1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: 2.4/5/6 GHz carrier frequency bands. The 6 GHz band depends on country regulations.
Max Wi-Fi channel width
320MHz1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: support for the 11be 320MHz wireless standard.
Wi-Fi module
Qualcomm QCNCM8651Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: Qualcomm Wi-Fi 7 QCNCM865.3Reviewkitguru.net/components/motherboard/leo-waldock/gigabyte-x870e-aorus-pro-x3d-ice-reviewRead 15 October 2026Spec table: Qualcomm QCNCM865.
Bluetooth
5.41Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: BLUETOOTH 5.4. GIGABYTE says the version may change with updates. A retailer feature list says 5.3 and its spec table says 5.4.

Audio

Audio codec
Realtek ALC12201Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: Realtek ALC1220 CODEC.
DAC chip
Not available

Features

BIOS flashback
Yes1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-6: Q-Flash Plus button and a red Q-Flash Plus USB port on the back panel. It updates the BIOS with the system off.
Clear CMOS button (rear)
Yes1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-6: a Clear CMOS button on the back panel.
POST code display
Yes1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 1-1 layout shows DB_PORT, with the note that debug code information is in the Debug LED Codes pages (section 5-2), which list two-digit codes. Geizhals lists a segment display and the product photo shows a two-digit display near the memory slots.2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Features: diagnostic LED indicators and a diagnostic segment display.
Power button on the board
Yes1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-6: a power button and a reset button on the back panel, for use in an open case.
Dual BIOS
No1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-2: BIOS is 1 x 512 Mbit flash. Dual BIOS is not stated.
Pre-installed I/O shield
Yes2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Features: integrierte I/O-Blende.
Tool-free features
Tool-free M.2 latch, Tool-free M.2 heatsink, PCIe slot release, Push-on antenna connector1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 2-8: M.2 EZ-Latch Plus (screwless M.2 SSD clip), M.2 EZ-Latch Click (screwless heatsink) and a PCIe EZ-Latch Plus release for the graphics card slot. Geizhals lists Quick Connect antenna connectors, which is GIGABYTE's WIFI EZ-Plug.2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Features: 4x M.2 passive heatsinks and Quick Connect antenna connectors.

Measured

VRM temperature under CPU load
54°C4Reviewprofesionalreview.com/2025/10/02/x870e-aorus-pro-x3d-ice-review/ampRead 15 October 2026Ryzen 9 7950X at stock without voltage changes (PPT 230 W), Corsair H150i ELITE LCD cooler, 32 GB G.Skill Trident Z5 NEO DDR5-6000, RTX 4080, Corsair RM1000 PSU. The review runs a CPU stress test at stock and reads surfaces with a thermal camera and sensors with HWiNFO. The stress tool, duration and ambient temperature are not stated. Full stock VRM sensors read 54 C and 54 C and the exterior camera read 54 C. At idle the sensors read 44 C and 46 C. The sensor reading is stored.
Power draw idle
Not available
Power draw CPU stress
Not available

In the box

In the box
User's Manual, Quick Installation Guide, One antenna, Two SATA cables, One noise detection cable, One G Connector, DDR Wind Blade, Two packs of M.2 thick/thin rubber pads1Owner's manualgzhls.at/blob/ldb/d/c/f/7/9ec63cd304ff9ffa46e4f9df07e3a1461ecb.pdfRead 15 October 2026Section 1-3. The list is for reference and the manual says the actual items depend on the package. It covers the ICE and the black model.

Warranty

Manufacturer warranty (source market)
3years2Spec databasegeizhals.de/gigabyte-x870e-aorus-pro-x3d-ice-a3592416.htmlRead 15 October 2026Garantie 3 Jahre.
