PC parts / Graphics cards
ASRockGraphics card
Intel Arc A750 Challenger SE 8GB OC
Released July 2024.1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Sales start 2024-07-12 in Japan at an expected 37,800 yen with tax. ASCII.jp wrote on 2024-07-13 that the card had gone on sale. ASRock's own page says the card may not be sold worldwide. Last checked 15 October 2026.
- GPU
- Intel Arc A750
- VRAM
- 8GB
- Length
- 267mm
- Board power
- 225W
55 of 100 fields known.
At a glance
Ports
- HDMI 2.0b
- 3 DisplayPort 2.0 UHBR10
General
- Series
- Challenger1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Product name Intel Arc A750 Challenger SE 8GB OC. Challenger is ASRock's line and SE marks this edition.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Key features: Model Intel Arc A750 Challenger SE 8GB OC. The description names the card as an ASRock Challenger.
- Model numbers
- A750 CL SE 8GO, 90-GA5AZZ-00UANF1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Model number A750 CL SE 8GO. The Amazon item number and Geeknetic MPN 90-GA5AZZ-00UANF are the ASRock part number of the same card.11Spec databasegeeknetic.es/comparador-precios/vga-asrock-a750-challenger-se-8gb-oc-intel-a750-8gb-gddr6-256bit-3dp-mas-1hdmi-2-ventiladores-a750-cl-se-8go/comprarRead 15 October 2026MPN 90-GA5AZZ-00UANF on the page whose address carries A750 CL SE 8GO.
- GTIN / EAN
- 471048394681311Spec databasegeeknetic.es/comparador-precios/vga-asrock-a750-challenger-se-8gb-oc-intel-a750-8gb-gddr6-256bit-3dp-mas-1hdmi-2-ventiladores-a750-cl-se-8go/comprarRead 15 October 2026EAN 4710483946813 with MPN 90-GA5AZZ-00UANF. Computer Orbit's product feed gives the same barcode for SKU A750 CL SE 8GO.12Retailer pagecomputerorbit.com/products/asrock-intel-arc-a750-challenger-se-oc-8gb-graphics-card.jsonRead 15 October 2026Product feed: SKU A750 CL SE 8GO, barcode 4710483946813.
- Status
- Not available
- Predecessor
- Not available
- Successor
- Not available
- Launch price (US)
- Not available
- Launch price (EU)
- Not available
- Markets
- Not available
- Colours
- Not available
- GPU
- Intel Arc A7502Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Key features: Model Intel Arc A750 Challenger SE 8GB OC. The description says it is powered by the Intel Arc A750 graphics engine.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026
- Reference launch price (US)
- $2894Reviewtomshardware.com/reviews/intel-arc-a750-limited-edition-reviewRead 15 October 2026Specifications table: Launch Price $289 for the Arc A750, launch October 2022. Intel cut the price later.5Reviewkitguru.net/components/graphic-cards/dominic-moass/intel-arc-a750-limited-edition-reviewRead 15 October 2026Review of 2022-10-05: the A750 Limited Edition is priced at $289. Intel said the Limited Edition would sell at the announced price.
GPU
- GPU architecture
- Xe HPG3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Microarchitecture Xe HPG. Code name Alchemist.
- GPU die
- ACM-G104Reviewtomshardware.com/reviews/intel-arc-a750-limited-edition-reviewRead 15 October 2026Specifications table: Architecture ACM-G10.5Reviewkitguru.net/components/graphic-cards/dominic-moass/intel-arc-a750-limited-edition-reviewRead 15 October 2026Page 1: both SKUs are built on Intel's ACM-G10 silicon.6Reviewpcper.com/2023/08/intel-arc-a750-limited-edition-graphics-card-reviewRead 15 October 2026Lineup table: GPU DG2-512, Intel's earlier name for the same die that KitGuru and Tom's Hardware call ACM-G10.
- Process
- TSMC N63Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Lithography TSMC N6.4Reviewtomshardware.com/reviews/intel-arc-a750-limited-edition-reviewRead 15 October 2026Specifications table: Process Technology TSMC N6.
- Transistors
- 21.7billion4Reviewtomshardware.com/reviews/intel-arc-a750-limited-edition-reviewRead 15 October 2026Specifications table: Transistors 21.7 billion for the Arc A750. The A750 uses the full ACM-G10 die.6Reviewpcper.com/2023/08/intel-arc-a750-limited-edition-graphics-card-reviewRead 15 October 2026Lineup table: transistor count 21.7B.
- Die size
- 406mm²4Reviewtomshardware.com/reviews/intel-arc-a750-limited-edition-reviewRead 15 October 2026Specifications table: die size 406 mm2.6Reviewpcper.com/2023/08/intel-arc-a750-limited-edition-graphics-card-reviewRead 15 October 2026Lineup table: die size 406 mm2.
- Compute units
- 283Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Xe-cores 28, render slices 7.5Reviewkitguru.net/components/graphic-cards/dominic-moass/intel-arc-a750-limited-edition-reviewRead 15 October 2026Page 1: the A750 ships with 28 Xe cores.
- Shader cores
- 3,5844Reviewtomshardware.com/reviews/intel-arc-a750-limited-edition-reviewRead 15 October 2026Specifications table: GPU Shaders 3584 for the Arc A750. Chip-level figure. Intel publishes no shader count.5Reviewkitguru.net/components/graphic-cards/dominic-moass/intel-arc-a750-limited-edition-reviewRead 15 October 2026Page 1: 28 Xe cores with 16 vector engines each and 8 FP32 ALUs each, a total of 3584.6Reviewpcper.com/2023/08/intel-arc-a750-limited-edition-graphics-card-reviewRead 15 October 2026Lineup table: shading units 3584.
- Ray tracing cores
- 283Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Ray tracing units 28.
- AI cores
- 4481Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026448 Intel XMX engines.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026XMX engines 448.
- ROPs
- 1125Reviewkitguru.net/components/graphic-cards/dominic-moass/intel-arc-a750-limited-edition-reviewRead 15 October 2026Page 1: 224 TMUs and 112 ROPs. Tom's Hardware lists 128 ROPs for the A750, which is the A770 figure and does not fit 7 render slices. PCPer also gives 112.6Reviewpcper.com/2023/08/intel-arc-a750-limited-edition-graphics-card-reviewRead 15 October 2026Lineup table: ROPs 112 for the Arc A750.
- Infinity Cache (L3)
- Not available
- FP32 compute (claimed)
- Not available
- AI performance (claimed)
Precision Throughput (TOPS) INT8 229
Clocks
- Base clock
- Not available
- Game clock
- 2,200MHz1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Engine clock 2,200 MHz. ASRock calls it the Engine Clock, its name for the Graphics Clock on Intel cards, so it is the game clock. Intel's own Graphics Clock is 2050 MHz. Club386 wrote 2,220 MHz from the same release, while the release, Igor's Lab, ASCII.jp and the retail copy of ASRock's tab all say 2200.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Key features: Engine Clock 2200 MHz. Core Clock row: Base Clock 2200 MHz, the same figure.
- Boost clock
- Not available
- Boost clock in OC mode
- Not available
- Reference boost clock
- Not available
Memory
- VRAM
- 8GB1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Video memory GDDR6 8 GB.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Video Memory Specifications: size 8GB.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Memory size 8 GB.
- VRAM type
- GDDR61Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Video memory GDDR6 8 GB.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Video Memory Specifications: type GDDR6.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Memory type GDDR6.
- Memory bus width
- 256bits1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Memory bus width 256 bit.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Memory Interface 256-bit.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Memory interface 256-bit.
- Memory speed
- 16Gbps1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Memory speed 16 Gbps.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Memory Clock 16 Gbps.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Memory speed 16 Gbps.
Connectivity
- PCIe generation
- 41Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Bus interface PCI Express 4.0 (x16).2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026BUS Type PCI Express 4.0 x16.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026PCI Express up to PCIe 4.0 x16.
- PCIe lanes
- 161Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Bus interface PCI Express 4.0 (x16).2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026BUS Type PCI Express 4.0 x16.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026PCI Express up to PCIe 4.0 x16.
- Display outputs
Type Version Count Max bandwidth (Gbps) HDMI 2.0b 1 Not available DisplayPort 2.0 UHBR10 3 40 Source1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Output interfaces HDMI 2.0b x1 and DisplayPort 2.0 x3. The UHBR10 class comes from ASRock's spec tab copy.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Interface: 3 x DisplayPort 2.0 up to UHBR 10 and 1 x HDMI 2.0b. Startech's copy of the ASRock specification tab. asrock.com blocks agents, so the maker tab was read through this copy.- Display outputs in total
- 4
- HDMI ports
- 1
- DisplayPort ports
- 3
- Highest HDMI version
- 2.0b
- Highest DisplayPort version
- 2.0 UHBR10
- Fastest DisplayPort link
- 40Gbps
- Max displays
- 42Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Multi Display 4.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Displays supported 4.
- Max output resolution
- Resolution7680 × 4320 pxRefresh rate60 Hz2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Resolution 7680 x 4320 Max. ASRock gives no refresh rate. The 60 Hz is Intel's DisplayPort figure at 8K.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026Max resolution (DP) 7680 x 4320 at 60 Hz. Max resolution (HDMI) 4096 x 2160 at 60 Hz. The DisplayPort mode is the highest and is stored.
- HDCP version
- Not available
Video engine
- Hardware video encode
- H.264, H.265 (HEVC), AV13Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026H.264, H.265 (HEVC) and AV1 encode/decode: Yes.
- Hardware video decode
- H.264, H.265 (HEVC), VP9, AV13Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026H.264, H.265 (HEVC) and AV1 encode/decode: Yes. VP9 is not on the Intel page and comes from iFixit.7Spec databaseifixit.com/Device/Intel_Arc_A750Read 15 October 2026Specifications, Hardware En/Decoders: H.264, H.265, AV1, VP9. The Intel page does not list VP9. iFixit lists it together with the other codecs, so VP9 is stored for decode only.
Graphics features
- DirectX
- 12 Ultimate2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026DirectX 12 Ultimate.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026DirectX 12 Ultimate.
- OpenGL
- 4.62Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026OpenGL 4.6.3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026OpenGL up to 4.6.
- Frame generation
- Not available
Power
- Board power
- Not available
- Reference board power
- 225W3Maker product pageintel.com/content/www/us/en/products/sku/227954/intel-arc-a750-graphics/specifications.htmlRead 15 October 2026TBP 225 W.
- PSU wattage (card maker)
- 650W2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Recommended PSU 650W.9Press articleigorslab.de/en/asrock-introduces-its-two-intel-arc-a750-and-arc-a770-challenger-se-cardsRead 15 October 2026ASRock recommends a 650 W power supply for the A750 Challenger SE.
- Power connector
- 2 x 8-pin PCIe1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Auxiliary power connector 8-pin x2.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Connectors 2 x 8-pin.8Press articleclub386.com/asrock-launches-overclocked-arc-a770-and-a750-graphics-cardsRead 15 October 2026Power from two eight-pin connectors.9Press articleigorslab.de/en/asrock-introduces-its-two-intel-arc-a750-and-arc-a770-challenger-se-cardsRead 15 October 2026Power connectors 2 x 8-pin.
Cooling
- Cooler type
- Open air2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Others: Dual Fan Design, Striped Axial Fan, Ultra-fit Heatpipe, 0dB Silent Cooling.8Press articleclub386.com/asrock-launches-overclocked-arc-a770-and-a750-graphics-cardsRead 15 October 2026Striped Axial fans over four heat pipes and a fin stack that extends beyond the PCB.
- Fans
- 22Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Others: Dual Fan Design.11Spec databasegeeknetic.es/comparador-precios/vga-asrock-a750-challenger-se-8gb-oc-intel-a750-8gb-gddr6-256bit-3dp-mas-1hdmi-2-ventiladores-a750-cl-se-8go/comprarRead 15 October 2026Cooling: active, 2 fans.
- Radiator size
- Not available
- Fan stop at low load
- Yes2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Others: 0dB Silent Cooling. No temperature threshold is stated.8Press articleclub386.com/asrock-launches-overclocked-arc-a770-and-a750-graphics-cardsRead 15 October 2026Striped Axial fans with a 0dB mode.10Press articleweekly.ascii.jp/elem/000/004/209/4209848Read 15 October 2026Dual fans in a semi-fanless design.
- Dual BIOS
- Not available
Dimensions and weight
- Length
- 267mm1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Dimensions length 267 mm, width 130 mm. The release also writes thickness 68 mm, which conflicts with the 48 mm of the spec tab copy and the 2.4 slots in ASCII.jp, so thickness is taken from those.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Dimensions 267 x 130 x 48 mm. ASRock writes no axis names. Length is the longest side and thickness the shortest.8Press articleclub386.com/asrock-launches-overclocked-arc-a770-and-a750-graphics-cardsRead 15 October 2026267 x 130 x 68 mm. The 68 mm repeats the Japanese release and is not used.9Press articleigorslab.de/en/asrock-introduces-its-two-intel-arc-a750-and-arc-a770-challenger-se-cardsRead 15 October 2026Dimensions 267 x 130 x 48 mm.
- Height
- 130mm1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Dimensions width 130 mm. ASRock calls the card height its width.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Second value of 267 x 130 x 48 mm.8Press articleclub386.com/asrock-launches-overclocked-arc-a770-and-a750-graphics-cardsRead 15 October 2026Second value of 267 x 130 x 68 mm.9Press articleigorslab.de/en/asrock-introduces-its-two-intel-arc-a750-and-arc-a770-challenger-se-cardsRead 15 October 2026Second value of 267 x 130 x 48 mm.
- Thickness
- 48mm2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Third value of 267 x 130 x 48 mm. This agrees with 2.4 slots in ASCII.jp and with Igor's Lab. The ASRock Japan release says 68 mm, which is not used.9Press articleigorslab.de/en/asrock-introduces-its-two-intel-arc-a750-and-arc-a770-challenger-se-cardsRead 15 October 2026Dimensions 267 x 130 x 48 mm.10Press articleweekly.ascii.jp/elem/000/004/209/4209848Read 15 October 2026The card is 2.4 slots thick, which is about 48 mm and fits 48 mm, not 68 mm.
- Slot width
- Not available
- Low profile
- Not available
- NVIDIA SFF-Ready
- Not available
- Weight
- 820g(1.8 lb)1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026Weight 820 g.2Retailer pagestartech.com.bd/asrock-intel-arc-a750-challenger-se-8gb-oc-graphics-cardRead 15 October 2026Others: Weight 820g.8Press articleclub386.com/asrock-launches-overclocked-arc-a770-and-a750-graphics-cardsRead 15 October 2026820 g.
- Package weight
- Not available
Lighting and software
We could not find any of these 3 fields. Show them
- RGB lighting
- Not available
- Lighting sync
- Not available
- Software
- Not available
Measured performance
We could not find any of these 6 fields. Show them
- GPU clock while gaming (measured)
- Not available
- 3DMark Time Spy graphics
- Not available
- 3DMark Steel Nomad
- Not available
- 3DMark Port Royal
- Not available
- 3DMark Speed Way
- Not available
- Game frame rates
- Not available
Measured noise and temperature
We could not find any of these 5 fields. Show them
- Fan noise per load
- Not available
- Fan noise while gaming
- Not available
- GPU temperature while gaming
- Not available
- Hot spot temperature while gaming
- Not available
- Memory temperature while gaming
- Not available
Measured power
We could not find any of these 2 fields. Show them
- Card power at idle (measured)
- Not available
- GPU power while gaming (measured)
- Not available
In the box
We could not find any of these 3 fields. Show them
- In the box
- Not available
- Power adapter cable included
- Not available
- Support bracket included
- Not available
Links
- Product page
- www.asrock.com/Graphics-Card/Intel/Intel%20Arc%20A750%20Challenger%20SE%208GB%20OC/index.us.asp1Press releasegdm.or.jp/pressrelease/2024/0705/546054Read 15 October 2026The release links the Japanese version of this ASRock page (index.jp.asp). asrock.com sits behind a bot check, so the page was not read.
- Spec sheet
- Not available
- Manual
- Not available
- EPREL registration number
- Not available
Warranty
We could not find any of these 1 fields. Show them
- Manufacturer warranty (source market)
- Not available
Compare with
Pick a graphics card to see both side by side. Differences are marked yellow.
Sources
We read 12 sources for this graphics card. The numbers match the markers in the sheet.
- Press releasegdm.or.jp/pressrelease/2024/0705/546054
- Spec databaseifixit.com/Device/Intel_Arc_A750
- Press articleweekly.ascii.jp/elem/000/004/209/4209848
See a wrong value? Tell us and name the field.
