PC parts / Motherboards

GIGABYTE B850 AORUS ELITE WIFI7 ICE

GIGABYTEGaming motherboard

B850 AORUS ELITE WIFI7 ICE

Released January 2025.2Reviewalktech.co/articles/unboxing-overview-gigabyte-b850-aorus-elite-wifi7-ice-am5-motherboardRead 16 October 2026Unboxing and overview of the ICE model dated 2025-01-06, the B850 launch day, with an editor's note added in April 2025. Last checked 16 October 2026.

CPU socket
AM5
Chipset
AMD B850
Form factor
ATX
M.2 slots
3

62 of 78 fields known.

Compare with another motherboardDownload JSONDownload CSVGet it from the API

At a glance

Ports

  • USB-C USB 3.2 Gen 2
  • 2 USB-A USB 3.2 Gen 2
  • 5 USB-A USB 3.2 Gen 1
  • 4 USB-A USB 2.0
  • DisplayPort 1.4
  • Ethernet (RJ45)
  • 2 3.5 mm audio
  • Optical S/PDIF
  • USB-C header
  • USB 3 header (19-pin)
  • 2 USB 2.0 header (9-pin)

All specs

SourceCalculated

General

Series
AORUS1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026AORUS is the GIGABYTE brand line in the name.
Model numbers
B850 AORUS ELITE WIFI7 ICE, B850 A ELITE WF7 ICE1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026The manual cover lists B850 AORUS ELITE WIFI7 ICE (B850 A ELITE WF7 ICE). GIGABYTE publishes no separate part number.6Retailer pageamazon.co.uk/dp/B0DQM7H82VRead 16 October 2026Manufacturer Part Number B850 A ELITE WF7 ICE.
GTIN / EAN
4719331866099, 8895230459475Retailer pageamazon.com/dp/B0DQLKRXKWRead 16 October 2026Amazon US item details list UPC 889523045947 and Mfr Part Number B850 AORUS ELITE WIFI7 ICE. The EAN 4719331866099 is from Amazon UK, Amazon DE and LDLC.6Retailer pageamazon.co.uk/dp/B0DQM7H82VRead 16 October 2026Amazon UK item details: Global Trade Identification Number 04719331866099.
Announced
Not available
Status
Available5Retailer pageamazon.com/dp/B0DQLKRXKWRead 16 October 2026In stock on 2026-10-16, ranked 1 in Computer Motherboards. The page lists a 5 year manufacturer warranty, which is not the base term.
Predecessor
Not available
Successor
Not available
Launch price (US)
$229.999Reviewthefpsreview.com/2025/01/06/gigabyte-b850-aorus-elite-wifi7-motherboard-reviewRead 16 October 2026Review of the B850 AORUS ELITE WIFI7 at the launch, 2025-01-06: a B850 AORUS ELITE WIFI7 ICE model for the same $229.99 price tag but in a white theme. US dollars, excl. sales tax. A TweakTown review lists $239 for the ICE, but the page returned 403 and was not read.
Launch price (EU)
Not available
Markets
Not available
Colours
Not available
Segment
Gaming3Reviewhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-iceRead 16 October 2026The review of 2025-02-26 calls it a board for gamers (carte a destination des joueurs). GIGABYTE sells it under the AORUS gaming brand.
Board revision
Not available

Platform

CPU socket
AM51Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026
Chipset
AMD B8501Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026
Supported processors
AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: Ryzen 9000, 8000 and 7000 Series. The manual refers to the maker's website for the latest CPU support list. Read on 2026-10-16.
CPU overclocking
Yes10Maker product pageamd.com/en/products/processors/chipsets/am5.htmlRead 16 October 2026AMD chipset specifications table, B850 column: Ryzen processor overclocking enabled: Yes. This is the chipset maker's feature, not a board spec.

Board

Front and side, drawn to scale.

Form factor
ATX1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026
Board dimensions
Width244Height305mm(9.6 × 12 in)1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: ATX form factor, 30.5 cm x 24.4 cm.
PCB layers
64Measurementhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-ice/4Read 16 October 2026The VRM test page says this board has a 6-layer PCB.
Back-connect design
No1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026The section 2-8 connector layout shows the usual front-side connectors. The board is not a Stealth or back-connect design.
RGB lighting on the board
Not available

Power delivery

Power stage layout
14+2+23Reviewhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-iceRead 16 October 2026The review states 14+2+2 power phases (Vcore+SoC) with OnSemi 55A DrMOS MOSFETs. Sellers and Alktech write 60A for the stages, so the stage rating is not stored.5Retailer pageamazon.com/dp/B0DQLKRXKWRead 16 October 2026Bullet: Power Design 14+2+2.6Retailer pageamazon.co.uk/dp/B0DQM7H82VRead 16 October 2026Title and first bullet: Twin 14+2+2 Phases Digital VRM with DrMOS.
CPU core (Vcore) power stages
143Reviewhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-iceRead 16 October 202614 Vcore stages. The first number of the maker's layout is 14.
Vcore power stage rating
Not available
VRM controller
Richtek RT3678BE3Reviewhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-iceRead 16 October 2026A Richtek RT3678BE controller configured as 7+7 phases. Single review of the ICE board.
CPU power connectors
8+4 pin1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: 1 x 8-pin ATX 12V and 1 x 4-pin ATX 12V. The 24-pin ATX connector is the only other power connector listed.
Extra slot power connector
No1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026The section 2-2 internal connector list has no extra slot power connector.

Memory

Memory type
DDR51Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026
Memory slots
41Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026
Max memory
256GB1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity).
Max memory speed (overclocked)
8,200MT/s3Reviewhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-iceRead 16 October 2026The review gives up to 256 GB and DDR5-8200 depending on the configuration. It names no CPU family. The launch manual lists only 5200/4800/4400.6Retailer pageamazon.co.uk/dp/B0DQM7H82VRead 16 October 2026Title: up to 8200MHz DDR5 (OC). The listing names no CPU family.
ECC memory
No1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: support for non-ECC unbuffered DIMM only.
CUDIMM support
Not available

Expansion slots

Expansion slots
Physical slotElectrical lanesPCIe generationConnected toCount
PCIe x16165CPU1
PCIe x1613Chipset2
Source1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: PCIEX16 is in the CPU and runs PCIe 5.0 x16 with Ryzen 9000 and 7000 (PCIe 4.0 x8 with Ryzen 8000 Phoenix 1 and x4 with Phoenix 2). PCIEX1_1 and PCIEX1_2 are x16-length slots from the chipset that run PCIe 3.0 at x1. The Wi-Fi socket is not stored.
Full-length PCIe slots
3
Fastest PCIe x16 slot generation
5

Storage

M.2 storage slots
SlotPCIe generationPCIe lanesConnected toLongest driveTakes SATA drivesHeatsink
M2A_CPU54CPUM.2 22110NoYes
M2B_CPU44CPUM.2 22110NoYes
M2C_SB44ChipsetM.2 22110NoYes
Source1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2 and 2-8 item 10: M2A_CPU takes PCIe 5.0 x4/x2 with Ryzen 9000 and 7000, M2B_CPU takes PCIe 4.0 x4/x2 and M2C_SB is on the chipset at PCIe 4.0 x4/x2. All three list 25110/22110/2580/2280, so 22110 is stored. The 2-8 table marks M.2 SATA SSDs as not supported on all three. Ryzen 8000 Phoenix CPUs slow M2A_CPU to PCIe 4.0 and Phoenix 2 slows M2B_CPU to x2. The motherboard heatsink covers all three slots (see the Alktech review).
M.2 slots
3
PCIe 5.0 M.2 slots
1
SATA ports
41Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: 4 x SATA 6Gb/s connectors.

Rear ports

Rear ports
TypeVersionCountMax link rate (Gbps)
USB-CUSB 3.2 Gen 2110
USB-AUSB 3.2 Gen 2210
USB-AUSB 3.2 Gen 155
USB-AUSB 2.040.48
DisplayPortDisplayPort 1.41Not available
Ethernet (RJ45)Not available12.5
3.5 mm audioNot available2Not available
Optical S/PDIFNot available1Not available
Source1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2 back panel list: 1 USB-C (USB 3.2 Gen 2), 2 USB 3.2 Gen 2 Type-A (red), 5 USB 3.2 Gen 1, 4 USB 2.0/1.1, 1 DisplayPort (1.4, actual support varies by CPU), 1 RJ-45 (2.5 GbE), 2 audio jacks and 1 optical S/PDIF out. USB 2.0 is stored as 0.48 Gbps. The HDMI port in the connector list is the internal F_HDMI header for a Sensor Panel Link screen and is not a rear port. The Q-Flash Plus button and two antenna connectors are not ports.
Rear USB ports
12
Rear USB-C ports
1
Fastest rear USB port
10Gbps
Thunderbolt
Not available

Internal connectors

Internal USB headers
HeaderMax data rate (Gbps)HeadersFront ports served
USB-C header2011
USB 3 header (19-pin)512
USB 2.0 header (9-pin)0.4824
Source1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2 and 2-8: FU3C_20G (USB Type-C header, USB 3.2 Gen 2x2, one port), FU3A_5G (USB 3.2 Gen 1, two ports), FUSB_1 and FUSB_2 (USB 2.0, two ports each).
Front USB-C header speed
20Gbps
Fan headers
61Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: CPU_FAN, CPU_OPT (CPU fan/pump), SYS_FAN1 to SYS_FAN3 and FAN4_PUMP (system fan/pump) are six 4-pin headers.
ARGB headers
31Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: 3 x addressable RGB Gen2 LED strip headers (ARGB_V2_1 to ARGB_V2_3).
RGB headers
11Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: 1 x RGB LED strip header (LED_C, 12 V).

Networking

Ethernet controllers
Realtek RTL81257Retailer pageldlc.com/en/product/PB00660675.htmlRead 16 October 2026LDLC spec table for the ICE: LAN chip Realtek RTL8125. Materiel.net prints the same. The Alktech review names RTL8125D, so the suffix is dropped.8Retailer pagemateriel.net/produit/202412050073.htmlRead 16 October 2026Spec table: Realtek RTL8125.
Ethernet ports
1
Ethernet speed
2.5Gbps
Wi-Fi included
Yes1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: a wireless communication module with two 2T2R antenna connectors on the back panel.
Wi-Fi standard
Wi-Fi 71Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: Realtek Wi-Fi 7 RTL8922AE, 802.11a/b/g/n/ac/ax/be.
Wi-Fi bands
2.4 GHz, 5 GHz, 6 GHz1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: 2.4/5/6 GHz carrier frequency bands. Wi-Fi 7 6 GHz channel availability depends on the country.
Max Wi-Fi channel width
160MHz1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: support for the 11be 160 MHz wireless standard. Alktech says the module does not support 320 MHz.
Wi-Fi module
Realtek RTL8922AE1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: Realtek Wi-Fi 7 RTL8922AE. The regulatory table of wireless module approvals lists B850 A ELITE WF7 ICE and B850 A ELITE WF7 with Realtek RTL8922AE, with no split by board revision.
Bluetooth
5.41Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: BLUETOOTH 5.4.

Audio

We could not find any of these 2 fields. Show them
Audio codec
Not available
DAC chip
Not available

Features

BIOS flashback
Yes1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Q-Flash Plus button on the rear panel (section 2-6).
Clear CMOS button (rear)
No1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2 and 2-8: Clear CMOS is a jumper (CLR_CMOS). The only rear panel button is Q-Flash Plus.
POST code display
No1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-7: four status LEDs (CPU, DRAM, VGA, BOOT). No two-digit display.
Power button on the board
Yes1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-7: two quick buttons, power and reset, on the board for an open-case environment.
Dual BIOS
No1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 2-2: BIOS is 1 x 256 Mbit flash. Dual BIOS is not stated.
Pre-installed I/O shield
Yes2Reviewalktech.co/articles/unboxing-overview-gigabyte-b850-aorus-elite-wifi7-ice-am5-motherboardRead 16 October 2026The review describes an integrated I/O shield design in white with parallelogram-shaped ventilation openings. The manual's box contents have no loose I/O shield.
Tool-free features
Tool-free M.2 latch, Tool-free M.2 heatsink, PCIe slot release, Push-on antenna connector2Reviewalktech.co/articles/unboxing-overview-gigabyte-b850-aorus-elite-wifi7-ice-am5-motherboardRead 16 October 2026M.2 EZ-Latch Click makes removing and installing the M.2 heatsink easy and tool-less. M.2 EZ-Latch Plus applies to all three M.2 slots. The PCIe 5.0 x16 slot has PCIe EZ-Latch Plus. The Wi-Fi antennas use WIFI EZ-Plug per the Amazon listings. The review also sees RGB LEDs under the chipset heatsink, which is a single small light that does not count as board lighting.3Reviewhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-iceRead 16 October 2026M.2 EZ-Latch Plus and M.2 EZ-Latch Click for the SSDs and the heatsink, and an EZ-Latch Plus button that releases the PCIe slot latch.6Retailer pageamazon.co.uk/dp/B0DQM7H82VRead 16 October 2026Bullets: PCIe Gen5 x16 with PCIe UD Slot and EZ-Latch Plus, M.2 Gen5 with EZ-Latch Plus, and Wi-Fi 7 with WIFI EZ-Plug and Directional Antenna.

Measured

VRM temperature under CPU load
40.4°C4Measurementhardwarecooking.fr/test-gigabyte-b850-aorus-elite-wifi7-ice/4Read 16 October 2026Ryzen 7 9700X, Prime95 for one hour, stock settings, HardwareCooking test system. A thermal camera on the front of the board reads 40.4 C at stock and 38.6 C with PBO. HWiNFO reads a 39 C VRM peak at stock and 41 C with PBO. The camera reading is stored. The cooler, ambient temperature and CPU package power are not stated.
Power draw idle
Not available
Power draw CPU stress
Not available

In the box

In the box
User's Manual, Quick Installation Guide, 1 x antenna, 2 x SATA cables, 1 x G Connector, 1 x M.2 thermal pad, 2 x packs of M.2 thick/thin rubber pads1Owner's manualtrovaprezzi.it/manuali/gigabyte_aorus_b850_elite_wifi7_ice.pdfRead 16 October 2026Section 1-3. The list is for reference and the manual says the actual items depend on the package. Alktech also lists a metal AORUS case badge in the box.

Warranty

Manufacturer warranty (source market)
3years6Retailer pageamazon.co.uk/dp/B0DQM7H82VRead 16 October 2026Product Warranty 3 years on the UK listing. The Amazon US page and Walmart say 5 years, which needs registration in North America, so 3 is stored as the base term.

Compare with

Pick a motherboard to see both side by side. Differences are marked yellow.

More motherboard comparisons

Variants

Each variant lists only what differs from the specs above.

Board revisionAudio codec
rev. 1.0Realtek ALC897
rev. 1.1Realtek ALC1220
